Dell PowerEdge R830

The Dell PowerEdge R830 packs four sockets into a 2U rack chassis, running up to four Intel Xeon E5-4600 v4 processors with up to 22 cores each. It offers 48 DDR4 DIMM slots (up to 3TB with 64GB modules at up to 2400 MT/s), up to 16x 2.5" SAS/SATA drives, seven PCIe 3.0 slots and a choice of 1GbE or 10GbE network daughter cards. With hot-plug redundant power, six hot-swap fans and iDRAC8, it is suited to dense virtualization and scale-out four-socket workloads. Fully configurable.

Looking to compare generations? See the Gen 14 Dell PowerEdge R740, or compare Gen 13 models: Dell PowerEdge R930 and Dell PowerEdge R730xd.

Thanks for the request. We'll get back to you with in 24 hours.

  • Form Factor: 2U Rack
  • Processors: Up to 4x Intel Xeon E5-4600 v4 (up to 22 cores)
  • Memory: 48x DDR4 RDIMM/LRDIMM slots, up to 3TB
  • Memory Speed: Up to 2400 MT/s
  • Storage: Up to 16x 2.5" SAS/SATA
  • Expansion: 7x PCIe 3.0 slots
  • GPU Support: Not listed by Dell
  • Networking: NDC: 4x 1GbE, or 2x 10GbE + 2x 1GbE
  • Management: iDRAC8 with Lifecycle Controller
  • Cooling: Air, 6 hot-swap fans
  • Power: Redundant 750W, 1100W or 1600W PSUs

Thanks for the request. We'll get back to you with in 24 hours.

Configure this  R830 →

Customize & Get Pricing

Configure your Dell PowerEdge R830 with the exact specs you need

Configure This Server

Dell PowerEdge R830 vs R840: Specs & Key Differences

Feature PowerEdge R830 PowerEdge R840
Processors Up to 4x Intel Xeon E5-4600 v4 (up to 22 cores) Up to 4x 2nd Gen Intel Xeon Scalable (up to 28 cores)
Memory 48x DDR4 DIMM slots, up to 3TB
Up to 2400 MT/s		 48x DDR4 DIMM slots, up to 6TB
Up to 2933 MT/s
Persistent Memory Not supported Up to 12x NVDIMM or 24x Intel Optane PMem
Storage Up to 16x 2.5" SAS/SATA Up to 24x 2.5" (up to 24 NVMe) + 2x rear 2.5"
PCIe 7x PCIe 3.0 Up to 6x PCIe Gen3
GPU Support Not listed by Dell Up to 2x DW GPU or 2x FPGA
Networking NDC: 4x 1GbE, or 2x 10GbE + 2x 1GbE NDC: 4x 1GbE, 4x 10GbE, 2x 10GbE + 2x 1GbE or 2x 25GbE
Management iDRAC8 with Lifecycle Controller iDRAC9
Power 750W, 1100W or 1600W 750W to 2400W
Form Factor 2U Rack 2U Rack

Frequently Asked Questions

Up to four Intel Xeon E5-4600 v4 processors with as many as 22 cores each, on the Intel C612 chipset.

Its 48 DDR4 DIMM sockets accept 8GB to 64GB RDIMMs or LRDIMMs, for up to 3TB per Dell's spec sheet, at up to 2400 MT/s.

Up to sixteen 2.5-inch drives, including SATA or SAS SSDs, 10K and 15K SAS HDDs and 7.2K nearline SAS, with PERC H330, H730 or H730P. Please specify your capacity needs when you submit your quote configuration.

The R830 gives you four sockets in a 2U chassis with E5-4600 v4 processors, which is denser and more economical. The 4U R930 uses E7 v4 processors and scales to 96 DIMM slots, 12TB of memory and 24 drives.

The Gen 14 R840 moves to Xeon Scalable with up to 28 cores, doubles memory to 6TB at 2933 MT/s, adds persistent memory, up to 24 NVMe drives, GPU or FPGA support, 25GbE and iDRAC9. Dell's R840 spec sheet was used for the R840 column.
