Dell PowerEdge R7725

The Dell PowerEdge R7725 is a 2U dual-socket rack server powered by two 5th Gen AMD EPYC 9005 Series processors with up to 192 cores each. It supports 24 DDR5 DIMM slots (up to 6TB, speeds up to 6400 MT/s), up to eight PCIe Gen5 slots, two optional OCP 3.0 NICs, up to two 450W double-width or six single-width GPUs and up to 40x EDSFF E3.S Gen5 NVMe, 24x 2.5-inch or 12x 3.5-inch drives, with air or Direct Liquid Cooling. Managed by iDRAC10, it is built for virtualization, VDI and high-performance computing. Fully configurable.

Looking to compare generations? See the Gen 16 Dell PowerEdge R760, or compare Gen 17 models: Dell PowerEdge R7715 and Dell PowerEdge R770.

Thanks for the request. We'll get back to you with in 24 hours.

  • Form Factor: 2U Rack
  • Processors: Up to 2x AMD EPYC 9005
  • Memory: 24x DDR5 DIMM slots, up to 6TB
  • Memory Speed: Up to 6400 MT/s
  • Storage: Up to 40x E3.S, 24x 2.5" or 12x 3.5"
  • Expansion: Up to 8x PCIe Gen5 slots
  • GPU Support: Up to 2x 450W double-width or 6x 75W single-width
  • Networking: Up to 2x OCP 3.0
  • Management: iDRAC10
  • Cooling: Air or Direct Liquid Cooling
  • Power: Redundant PSUs, 800W to 3200W

Thanks for the request. We'll get back to you with in 24 hours.

Configure this  R7725 →

Customize & Get Pricing

Configure your Dell PowerEdge R7725 with the exact specs you need

Configure This Server

Dell PowerEdge R7725 vs R7625: Specs & Key Differences

Feature PowerEdge R7725 PowerEdge R7625
Processors 2x AMD EPYC 9005 (up to 192 cores each) 2x AMD EPYC 9004 (up to 128 cores each)
Memory 24x DDR5 DIMM slots, up to 6TB
Up to 6400 MT/s		 24x DDR5 DIMM slots, up to 6TB
Up to 4800 MT/s
PCIe Up to 8x PCIe Gen5 slots Up to 8x PCIe Gen5/Gen4 slots
GPU Support Up to 2x 450W DW or 6x 75W SW Up to 2x 300W DW or 6x 75W SW
Storage Up to 40x E3.S, 24x 2.5" or 12x 3.5" Up to 32x E3.S, 24x 2.5" or 12x 3.5"
Rear up to 4x 2.5" or 4x E3.S
Networking Up to 2x OCP 3.0 2x 1GbE LOM + 1x OCP 3.0
Management iDRAC10 iDRAC9
Cooling Air or DLC Air or optional DLC
Power 800W to 3200W 800W to 3200W
Form Factor 2U Rack 2U Rack

Frequently Asked Questions

The R7725 is a dual-socket 2U server that takes two 5th Gen AMD EPYC 9005 Series processors with up to 192 Zen 5 cores each. Some high-TDP processor SKUs and configurations require Direct Liquid Cooling.

It has 24 DDR5 RDIMM slots, 12 per processor at one DIMM per channel, running at up to 6400 MT/s. Maximum capacity is up to 6TB. Only registered ECC DDR5 DIMMs are supported.

The R7725 supports up to two 450W double-width GPUs or up to six 75W single-width GPUs. It is cooled by up to six hot-plug fans, with Direct Liquid Cooling (DLC) available for the highest-power processors.

Front options include 12x 3.5-inch SAS/SATA; 8x 2.5-inch universal; 16 or 24x 2.5-inch SAS/SATA; 16x 2.5-inch SAS/SATA plus 8x U.2 NVMe; or 8, 16, 32 or 40 EDSFF E3.S Gen5 NVMe drives. Boot is handled by BOSS-N1. Please specify your capacity needs when you submit your quote configuration.

The R7725 moves from two EPYC 9004 CPUs with up to 128 cores each to two EPYC 9005 CPUs with up to 192 cores each. Memory speed rises from 4800 to 6400 MT/s on the same 24 DDR5 slots, double-width GPU support grows from 300W to 450W cards, E3.S capacity grows from 32 to 40 drives, and management moves from iDRAC9 to iDRAC10.
