Dell PowerEdge R520

The Dell PowerEdge R520 is a 2U two-socket rack server built for storage-heavy work at a sensible cost. It runs up to two Intel Xeon E5-2400 or E5-2400 v2 processors with up to 10 cores each, 12 DDR3 DIMM slots for up to 384GB at 1600 MT/s, and up to eight 3.5" hot-plug drives. With up to four PCIe slots, dual 1GbE, a choice of cabled or hot-plug redundant power and iDRAC7, it suits file, backup and database duty. Fully configurable.

Looking to compare generations? See its Gen 13 successor, the Dell PowerEdge R530, or compare Gen 12 models: Dell PowerEdge R720xd and Dell PowerEdge R420.

Thanks for the request. We'll get back to you with in 24 hours.

  • Form Factor: 2U Rack
  • Processors: Up to 2x Intel Xeon E5-2400/E5-2400 v2
  • Memory: 12x DDR3 DIMM slots, up to 384GB
  • Memory Speed: Up to 1600 MT/s
  • Storage: Up to 8x 3.5" hot-plug
  • Expansion: Up to 4x PCIe (3x Gen3, 1x Gen2) + PERC slot
  • GPU Support: Not listed by Dell
  • Networking: 2x 1GbE LOM
  • Management: iDRAC7 with Lifecycle Controller
  • Cooling: Air, up to 6 fans
  • Power: 550W cabled, or 495W to 1100W hot-plug PSUs

Thanks for the request. We'll get back to you with in 24 hours.

Configure this  R520 →

Customize & Get Pricing

Configure your Dell PowerEdge R520 with the exact specs you need

Configure This Server

Dell PowerEdge R520 vs R530: Specs & Key Differences

Feature PowerEdge R520 PowerEdge R530
Processors Up to 2x Intel Xeon E5-2400/E5-2400 v2 (up to 10 cores) Up to 2x Intel Xeon E5-2600 v3/v4 (up to 18 cores)
Memory 12x DDR3 DIMM slots, up to 384GB 12x DDR4 DIMM slots, up to 384GB
Memory Speed Up to 1600 MT/s Up to 2400 MT/s
Storage Up to 8x 3.5" Up to 8x 3.5"
Storage Controllers PERC S110, H310, H710, H710P
External H810		 PERC S130, H330, H730, H730P
External H830
PCIe Up to 4 (3x Gen3, 1x Gen2) Up to 5 (3x Gen3, 2x Gen2)
Networking 2x 1GbE LOM 4x 1GbE LOM
Management iDRAC7 with Lifecycle Controller iDRAC8 with Lifecycle Controller
Power 550W cabled; 495W, 750W, 1100W hot-plug; 1100W DC 450W cabled; 495W, 750W, 1100W hot-plug; 1100W -48V DC
Form Factor 2U Rack 2U Rack

Frequently Asked Questions

One or two Intel Xeon E5-2400 or E5-2400 v2 processors, with 4 to 10 cores per socket, on the Intel C602 chipset.

It has 12 DDR3 DIMM sockets for registered or unbuffered modules, up to 384GB at speeds up to 1600 MT/s.

Up to eight 3.5-inch hot-plug SAS, nearline SAS or SATA drives, with 2.5-inch SAS drives and SSDs also supported, using PERC S110, H310, H710 or H710P. Please specify your capacity needs when you submit your quote configuration.

A non-redundant cabled 550W supply, or hot-plug redundant 495W, 750W (Platinum or Titanium) or 1100W AC units, plus an 1100W DC option. Redundant supplies and a second processor add extra fans for fault-tolerant cooling.

The Gen 13 R530 keeps the same 2U, eight 3.5-inch drive design and 12 DIMM slots, but moves to Xeon E5-2600 v3/v4 processors, DDR4-2400 memory, four 1GbE ports, a fifth PCIe slot and iDRAC8.
