Dell PowerEdge R720

The Dell PowerEdge R720 is a 2U dual-socket rack server built on Intel Xeon E5-2600 and E5-2600 v2 processors with up to 12 cores per CPU. It offers 24 DDR3 DIMM slots (up to 768GB), up to 7 PCIe 3.0 slots, support for up to two GPU accelerators, and flexible storage with up to 16x 2.5" or 8x 3.5" hot-plug drives. The predecessor to the R730, it remains a dependable, low-cost refurbished platform for virtualization, databases, VDI and HPC. Fully configurable.

Looking to compare generations? Move up to the Dell PowerEdge R730, Dell PowerEdge R740 or Dell PowerEdge R750.

Thanks for the request. We'll get back to you with in 24 hours.

  • Form Factor: 2U Rack
  • Processors: Up to 2x Intel Xeon E5-2600/E5-2600 v2
  • Memory: 24x DDR3 DIMM slots, up to 768GB
  • Memory Speed: Up to 1866 MT/s
  • Storage: Up to 16x 2.5" or 8x 3.5" hot-plug
  • Expansion: Up to 7x PCIe 3.0 slots
  • GPU Support: Up to 2x 300W double-width
  • Networking: rNDC, up to 4x 10GbE
  • Management: iDRAC7
  • Cooling: 6x redundant hot-plug fans
  • Power: Redundant PSUs, 495W to 1100W

Thanks for the request. We'll get back to you with in 24 hours.

Configure this  R720 →

Customize & Get Pricing

Configure your Dell PowerEdge R720 with the exact specs you need

Configure This Server

Dell PowerEdge R720 vs R730: Specs & Key Differences

Feature PowerEdge R720 PowerEdge R730
Processors Intel Xeon E5-2600/E5-2600 v2 (up to 12 cores) Intel Xeon E5-2600 v3/v4 (up to 22 cores)
Memory 24x DDR3 DIMM slots, up to 768GB
Up to 1866 MT/s		 24x DDR4 DIMM slots, up to 3TB
Up to 2400 MT/s
PCIe Up to 7x PCIe 3.0 slots Up to 7x PCIe 3.0 slots
GPU Support Up to 2x 300W DW or 4x 150W SW Up to 2x 300W DW or 4x 150W SW
Storage Up to 16x 2.5" or 8x 3.5" Up to 16x 2.5" or 8x 3.5"
Networking rNDC rNDC
Management iDRAC7 iDRAC8
Form Factor 2U Rack 2U Rack

Frequently Asked Questions

We custom-configure the R720 with 8 x 3.5-inch, 8 x 2.5-inch or 16 x 2.5-inch SAS/SATA hot-plug drives (HDD or SSD). The 2.5-inch chassis can also take up to four front-access Express Flash PCIe SSDs (8 x 2.5-inch + 4 x Express Flash), and an optional internal dual SD module is available for mirrored hypervisor boot. Please specify your capacity and performance requirements when submitting your quote configuration.

The R720 runs Intel Xeon E5-2600 or E5-2600 v2 processors with up to 12 cores, 24 DDR3 DIMM slots at up to 1866 MT/s (768GB max) and iDRAC7. The R730 moves to Xeon E5-2600 v3/v4 with up to 22 cores, DDR4 at up to 2400 MT/s (3TB max) and iDRAC8. Both offer up to 7 PCIe 3.0 slots in 2U, and the R720 remains a low-cost choice for proven workloads.

The R720 has 24 DDR3 DIMM slots supporting UDIMMs, RDIMMs and LRDIMMs at up to 1866 MT/s with E5-2600 v2 processors. It holds up to 768GB with 32GB RDIMMs or LRDIMMs in a dual-processor configuration.

The R720 supports up to two double-wide 300W GPUs or four single-wide 150W GPUs for compute workloads. GPU configurations require two processors (115W or less), redundant 1100W power supplies and the GPU enablement kit; two double-wide GPUs also need the optional riser 3.

It supports dual Intel Xeon E5-2600/E5-2600 v2 processors (up to 12 cores each with v2), 24 DDR3 DIMM slots (up to 768GB RAM) and up to 7 PCIe 3.0 expansion slots in a 2U chassis.
