Quick Specs
2U rack server
Processor | Max: 22 Cores2 x Intel Xeon E5-2600v3 or v4
Memory | Max: 3TB24 ECC DDR4 RDIMM/LRDIMM 2400Mhz
Storage | Max: 64TB LFF | 29TB SFF8x 3.5" SAS/SATA (HDD/SDD)
The R730 does not support Express Flash drives
S130 (SW RAID)
H330, H730, H730P, H830, 12Gbps SAS HBA
4x 1GbE
2x 10+2GbE
4x 10GbE NDC
iDRAC8 Express (default) with Lifecycle Controller
PCIe Slots:Up to 7 x PCIe 3.0 + dedicated PERC slot
-One x16 full-length, full-height
-Three x8 full-length, full-height
-Three x8 half-length, half-height
2 x 300W (double-wide) or
4 x 150W (single-wide)
- Dell PowerEdge R710
- Dell PowerEdge R720
- Dell PowerEdge R720XD
- Dell PowerEdge R730
- Dell PowerEdge R730XD
- Dell PowerEdge R740
- Dell PowerEdge R740XD
- Dell PowerEdge R740XD2
- Dell PowerEdge R7415
- Dell PowerEdge R7425
- Dell PowerEdge R750
- Dell PowerEdge R750XA
- Dell PowerEdge R750XS
- Dell PowerEdge R7515
- Dell PowerEdge R7525
- Dell PowerEdge R760
- Dell PowerEdge R760XA
- Dell PowerEdge R760XS
- Dell PowerEdge R760XD2
- Dell PowerEdge R7615
- Dell PowerEdge R7625
Ideal for:
- Database
- High-Performance Computing (HPC)
- Retail Servers
- Virtual Desktop Interface (VDI)
A highly versatile, two-socket 2U rack server with impressive processor performance, a large memory footprint, extensive I/O options and a choice of dense, high performance storage or low-cost, high-capacity storage.
The Refurbished Dell PowerEdge R730 CTO Rack Server, a highly versatile 2U rack server designed to deliver peak performance and tackle almost any workload. With the latest Intel Xeon processor E5-2600 v4 product family with up to 22 cores and up to 24 DIMMs of high-capacity DDR4 memory, this server is perfect for midsize and large enterprises that require demanding workloads such as data warehouses, e-commerce, virtual desktop infrastructure (VDI), databases, and high-performance computing (HPC) as a data node.
Deliver peak performance
With extensive I/O options and a choice of dense, high-performance storage or low-cost, high-capacity storage, the PowerEdge R730 provides up to 64TB of rapidly accessed storage for databases, business intelligence, and HPC applications when configured with 3.5" drives. This makes it an ideal solution for environments that require processing acceleration, including graphics-intensive VDI implementations such as CAD/CAM and other research and development applications.
GPU Performance
The R730 is extremely flexible with seven PCIe 3.0 expansion slots plus a dedicated PERC slot, up to 16 x 2.5" SAS, SATA, nearline SAS HDD/SSD, and up to 8 x 3.5" SAS, SATA, nearline SAS HDD/SSD. It also has the option for up to two 300W dual-width accelerators/GPUs (choose from Intel® Xeon Phi, NVIDIA Tesla, and AMD FirePro) to support environments that require processing acceleration
Discover greater versatility
With its ability to create a dense, resource-rich virtualization environment and consolidate management operations in a scalable and centralized virtual desktop environment, the R730 is an excellent choice for midrange medical imaging solutions. It also delivers outstanding functionality in just 2U of rack space, making it an ideal compute node for IT as a service (XaaS) providers
Looking to Customize?
Need assistance with customization? Our sales experts are here to help you.
Start Customizing Today!
Base Standard Capabilities
| Feature | PowerEdge R730 Technical Specification | |
|---|---|---|
| Form factor | 2U rack server | |
| Dimensions and weight |
| |
| Processor | Intel® Xeon® processor E5-2600 v4 product family | |
| Processor sockets | 2 | |
| Cache | 2.5MB per core; core options: 4, 6, 8, 10, 12, 14, 16, 18, 22 | |
| Chipset | Intel C610 series chipset | |
| Memory | Up to 3TB (24 DIMM slots): 4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s | |
| I/O slots | Up to 7 x PCIe 3.0 plus dedicated PERC slot | |
| RAID controllers | Internal controllers: PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P External HBAs (RAID): PERC H830 External HBAs (non-RAID): 12Gbps SAS HBA | |
| Drive bays | Internal hard drive bay and hot-plug backplane:
| |
| Maximum internal storage | HDD: SAS, SATA, nearline SAS SSD: SAS, SATA
| |
| Embedded NIC | 4 x 1GbE, 2 x 10+2GbE, 4 x 10GbE NDC | |
| Power supplies | Titanium efficiency 750W AC power supply; 1100W DC power supply; Platinum efficiency 495W, 750W, 1100W AC power supply; | |
| Availability | ECC memory, hot-plug hard drives, hot-plug redundant cooling, hot-plug redundant power, internal dual SD module, single device data correction (SDDC), spare rank, tool-less chassis, support for high availability clustering and virtualization, proactive systems management alerts, iDRAC8 with Lifecycle Controller | |
| Remote management | iDRAC8 with Lifecycle Controller iDRAC8 Express (default) iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade) 16GB vFlash media (upgrade) | |
| Systems management |
| |
| Optional supported hypervisors | Citrix® XenServer, VMware vSphere® ESXi® | |
| Operating system | Microsoft Windows Server® 2008/2012 SP2, x86/x64 (x64 includes Hyper-V®) Microsoft Windows Server 2008/2012 R2, x64 (includes Hyper-V) Microsoft Windows HPC Server 2008 Novell® SUSE® Linux Enterprise Server Red Hat® Enterprise Linux | |
| Rack support | ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm. | |
Spec Sheet 4
| Feature | PowerEdge R720/R720xd | PowerEdge R730/R730xd |
|---|---|---|
| Chassis | 2U rack | 2U rack |
| Processors | Intel Xeon processor E5-2600 v2 product family | Intel Xeon processor E5-2600 v3 product family |
| Internal interconnect | Intel QuickPath Interconnect (QPI) | Intel QPI |
| Memory | 24 x DDR3 RDIMM, UDIMM, and LRDIMM Up to 768GB | 24 x DDR4 RDIMM and LRDIMM Up to 768GB |
| Disk drives | R720:
Up to 16 x 2.5“ or 8 x 3.5” 6Gb SAS, 3Gb SATA R720xd: Up to 26 x 2.5” SAS SSD, SATA SSD, SAS, NLSAS, SATA, SAS 512n or 12 x 3.5” SAS, NL-SAS, SATA + 2 x 2.5” drives |
R730:
Up to 16 x 2.5” HDD: SAS, SATA, NL-SAS; SSD: 12Gb SAS, 6Gb SATA Up to 8 x 3.5” HDD: SATA, NL-SAS; SSD: 12Gb SAS, 6Gb SATA R730xd: Up to 24 x 2.5” + 2 x 2.5” HDD: SAS, SATA, NL-SAS; SSD: 12Gb SAS, 6Gb SATA, up to 4 NVMe Express Flash PCIe Up to 16 x 3.5” + 2 x 2.5” HDD: SAS, SATA, NL-SAS; SSD: 12Gb SAS, 6Gb SATA |
| RAID controller | PERC S110 (software RAID), H310, H710,
H710P, H810 (external); support for 2 internal RAID controllers |
PERC S130 (software RAID), H330,
H730, H730P, H830 (external); support for 2 internal RAID controllers |
| PCI slots | Max 7 + 1 x PCIe 3.0/6 + 1 x PCIe 3.0 | Max 7 + 1 x PCIe 3.0/6 + 1 x PCIe 3.0 option to eliminate Riser 1 |
| Embedded NICs | Select Network Adapter NDC 4 x 1GbE, 2 x 10GbE |
Select Network Adapter NDC 4 x 1GbE, 2 x 10GbE, 4 x 10GbE |
| USB | USB 2.0 | USB 3.0 (back and internal ports only) |
| Power supplies | Hot-plug, redundant power supply units:
>95W AC, 750W AC, 750W AC/DC mixed mode, 1100W AC, 1100W DC |
Hot-plug, redundant power supply units:
495W AC, 750W AC, 750W AC/DC mixed mode2, 1100W AC, 1100W DC |
| Power efficiency 80 PLUS® certification | Titanium and Platinum | Titanium and Platinum |
| Dell OpenManage Systems Management | OpenManage Essentials
Dell Management Console IT Assistant OMSA Agent OpenManage Power Center (requires iDRAC7 Enterprise with Lifecycle Controller) OpenManage Integrations and Connections iDRAC7 Express with Lifecycle Controller (standard option) |
OpenManage Essentials
Dell Management Console OMSA Agent OpenManage Power Center (requires iDRAC8 Enterprise with Lifecycle Controller) OpenManage Integrations and Connections iDRAC8 Express with Lifecycle Controller (standard option) |
| Internal GPU | 2 x 300W (double-wide) or
4 x 150W (single-wide) Not supported on R720xd |
2 x 300W (double-wide) or
4 x 150W (single-wide) Not supported on R730xd |
| Availability | Hot-plug drives
Hot-plug redundant cooling Hot-plug redundant PSUs IDSDM support |
Hot-plug drives
Hot-plug redundant cooling Hot-plug redundant PSUs IDSDM support (next generation) |
