Quick Specs
Form Factor:
2U rack server
Processor | Max: 8 Cores2 x Intel Xeon E5-2600
Memory | Max: 768GB24 ECC DDR3 UDIMM/RDIMM/LRDIMM 1866Mhz
Storage | Max: 32TB8 LFF or 8, 16 SFF SAS/NL-SAS/SATA (HDD/SSD)
RAID Controller:S110 (SW RAID), H310, H710, H710P, H810, 6Gbps SAS HBA
NIC/LOM:4x 1GbE Broadcom 5720 BASE-T
Remote Management:iDRAC7 Express (default) with Lifecycle Controller
PCIe Slots:7 PCIe 3.0 slots:
One x16 full-length, full-height
Three x8 full-length, full-height
Three x8 half-length, half-height
2 x 300W (double wide) or
4 x 150W (single wide)
Other Versions
- Dell PowerEdge R710
- Dell PowerEdge R720
- Dell PowerEdge R720XD
- Dell PowerEdge R730
- Dell PowerEdge R730XD
- Dell PowerEdge R740
- Dell PowerEdge R740XD
- Dell PowerEdge R740XD2
- Dell PowerEdge R7415
- Dell PowerEdge R7425
- Dell PowerEdge R750
- Dell PowerEdge R750XA
- Dell PowerEdge R750XS
- Dell PowerEdge R7515
- Dell PowerEdge R7525
- Dell PowerEdge R760
- Dell PowerEdge R760XA
- Dell PowerEdge R760XS
- Dell PowerEdge R760XD2
- Dell PowerEdge R7615
- Dell PowerEdge R7625
(Click to View)
Ideal for:
- Database
- High-Performance Computing (HPC)
- Retail Servers
- Virtualization
Setting the standard for feature flexibility in a 2-socket, 2U rack server, the Dell PowerEdge R720 is built to run complex workloads using its highly scalable memory, I/O capacity and flexible network options.
Designed to excel at running a wide range of applications and virtualization environments for both mid-size and large enterprises, the Dell PowerEdge R720 rack server is a general purpose platform with highly expandable memory (up to 768GB) and impressive I/O capabilities to match. With Intel Xeon E5-2600 processors, and the ability to support dual RAID controllers, the R720 can readily handle very demanding workloads, such as data warehouses, e-commerce, virtual desktop infrastructure (VDI), databases and high performance computing (HPC) as a data node.
Virtualize more with the R720
Maximize your data center’s application capacity by expanding your virtual environment using the PowerEdge R720’s large memory footprint. Choose an industry-leading hypervisor and take advantage of our system management capability to manage both physical and virtual assets. The R720 can help maximize your virtual machines’ uptime with redundant failsafe hypervisors. Finally, Dell’s Virtual Integrated System (VIS) solution lets you enable complex virtualization environments in just a few mouse clicks.
Manage data overload
Keep pace with the explosion of data in the virtual age with the flexible, powerful I/O and storage capabilities of the R720. Up to 16 internal hard drives and integrated PCI Express 3.0-capable expansion slots greatly increase your capacity, while optional hot-plug, front-access PCIe SSDs (up to 4) enable performance-enhancing, in-box storage tiering. Moreover, Dell Select Network Adapters, our flexible NIC technology, let you choose the right network fabric to match your needs without using up a valuable PCIe slot.
Accelerate the solution
Boost the performance of your HPC or VDI environment by combining the PowerEdge R720’s memory density with an optional GPU accelerator (some with over 500 cores). Choose from a range of GPU options for greater assisted performance.
Performance-packed computing
Dramatically boost application performance with the latest Intel Xeon processor E5-2600 or E5-2600v2 product family and up to 24 dual in-line memory modules (DIMMs). Built with 22-nanometer process technology and up to 12 cores per processor, it enables super-fast processing for compute-intensive tasks.
Advanced I/O capabilities
Enhance your data center performance with the balanced, scalable I/O capabilities of the PowerEdge R720 — including integrated PCI Express (PCIe) 3.0-capable expansion slots.
Flexible and scalable networking
Tailor your network throughout to match your application needs with features that allow you to take full advantage of your additional I/O performance.
Uncompromising productivity
Maximize your efficiency in demanding virtualization, databases and enterprise resource planning (ERP) workloads for midsize and large enterprises with the PowerEdge R720 rack server.
Powerful systems management
Experience easy lifecycle manageability with intelligent hardware-driven systems administration, extensive power management and other innovative management tools.
Powerful and balanced performance
Employ the newest Dell server technology, with high-density memory, balanced I/O and the latest processors, for your enterprise virtualization and business processing environments.
Enhanced operational efficiency
Maintain high-level data center productivity, security and maintenance with next-generation reliability, availability and serviceability (RAS) features within the R720 infrastructure.
Versatile storage capacity and performance
Keep pace and effectively manage exponential data growth with flexible I/O (input/output) and storage options, including Express Flash PCIe technology in the PowerEdge R720 rack server.
Networking and PCIe
The PowerEdge R720 supports one custom network daughter card (NDC), as part of the Select the Network Adapters family, to house the complete LOM subsystem. There are two form factors of Select Network Adapters — one for blade servers and one for rack servers. The rack NDC options supported on the R720 and R720xd include a selection of 1GbE and 10GbE port cards, such as 1000 Base-T, 10Gb Base-T, and 10Gb SFP+
The R720 provides greatly expanded PCIe slot capability over their predecessor servers. This is made possible by the 40 PCIe lanes available from each processor in the system. Two processors are required in the system to enable all PCIe slots. The R720 have been designed to be PCIe 3.0 compliant in order to take full advantage of the processor capabilities.
7 PCIe 3.0 Slots Type
- One x16 full-length, full-height
- Three x8 full-length, full-height
- Three x8 half-length, half-height
GPU Support
The R720 can support two 300W, full-length, double-wide GPUs or up to four 150W, full-length, single-wide GPUs. Each GPU can support up to 6GB of dedicated GDDR5 memory and is either actively or passively cooled. The GPUs are installed on the PCIe x16 2.0 interfaces available on riser 2 and GPU-optional riser 3. A system must have the optional riser 3 with a single x16 slot to support more than two GPUs.
Other GPU restrictions
The following GPU restrictions for the R720 are enforced by the order validator:
- Requires two processors
- Processors must be 115W or less
- Maximum of two double-wide GPUs (since they take up two slots)
- Maximum of four single-wide GPUs
- All GPUs must be same type and model
- GPUs require a redundant 1100W power supply and GPU enablement kit
- PowerEdge R720 and R720xd Technical Guide
- Two double-wide GPUs require the optional riser 3 with a single x16 slot
- Four single-wide GPUs cannot occupy optional riser 3 with a single x16 slot
- Dell PowerVault RD1000 backup unit not supported
