Specs
-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.
Quick Specs
- Supporting the second generation Intel Xeon Scalable processor family with up to a 11% per-core performance gain over first generation and with memory speeds up to 2933 MT/s.
- HPE Persistent Memory offers the flexibility to deploy as dense memory or fast storage featuring Intel Optane DC Persistent Memory and enables per-socket memory capacity of up to 3.0 TB.
- 800GB 1.6/3.2/6.4TB NVMe Mixed Use SFF SSDs
- 960GB 1.92/3.84/7.68TB NVMe Read Intensive SFF SSDs
- 480GB/1.92/3.84TB SATA Mixed Use SFF SSDs
- HPE StoreFabric SN1610Q 32Gb 1 port Fibre Channel Host Bus Adapter
- HPE StoreFabric SN1610Q 32Gb 2 port Fibre Channel Host Bus Adapter
- Networking Choice (NC) server models provide greater flexibility in the primary networking selection.
- HPE InfoSight provides a cloud-based analytics tool that predicts and prevents problems before your business is impacted.
- Enhanced iLO 5 security features such as Server Configuration Lock, iLO Security Dashboard and Workload Performance Advisor.
Ideal for:
- Cloud Servers
- Corporate IT
- Data Analytics
- Database
- High-Performance Computing (HPC)
- Hyper-Converged infrastructure (HCI)
- Virtual Desktop Interface (VDI)
- Virtualization
- Virtual Machines (VM)
Chassis Specs
| CTO Server [Chassis] | HPE DL360 Gen10 4LFF CTO Server | HPE DL360 Gen10 8SFF CTO Server | HPE DL360 Gen10 Premium 10NVMe CTO Server | HPE DL360 Gen10 4LFF NC CTO Server | HPE DL360 Gen10 8SFF NC CTO Server | HPE DL360 Gen10 Premium 10NVMe NC CTO Server | HPE DL360 Gen10 8SFF BC NC CTO Server | HPE DL360 Gen10 8SFF BC CTO System |
|---|---|---|---|---|---|---|---|---|
| SKU Number | 867958-B21 | 867959-B21 | 867960-B21 | P19765-B21 | P19766-B21 | P19767-B21 | P56949-B21 | P56950-B21 |
| Processor | Not included as standard | |||||||
| DIMM Slots | 24-DIMM slots DDR4 (Max 12 NVDIMMs with Gen 1 Processor) (Max 12 HPE Persistent Memory with Gen 2 Processors) |
|||||||
| Storage Controller | Embedded SW RAID (S100i) with 14 SATA ports Optional: Choice of HPE modular Smart Array and PCIe plug-in controller |
|||||||
| PCIe | 2 PCIe slots (1 x16 FH / 1 x8 LP) Optional: 1 x16 FH or LP |
|||||||
| Drives Cage - included | 4 LFF - SAS/SATA | 8 SFF - SAS/SATA Optional: up to 2 NVMe or 2 Dual uFF (4x M.2 cartridges) |
10 NVMe - SAS/SATA/NVME Optional: 1 Dual uFF (2x M.2 cartridges) |
4 LFF - SAS/SATA | 8 SFF - SAS/SATA Optional: up to 2 NVMe or 2 Dual uFF (4x M.2 cartridges) |
10 NVMe - SAS/SATA/NVME Optional: 1 Dual uFF (2x M.2 cartridges) |
8 SFF - SAS/SATA Basic Carrier (BC) Optional: up to 2 NVMe or 2 Dual uFF (4x M.2 cartridges) |
8 SFF - SAS/SATA Basic Carrier (BC) Optional: up to 2 NVMe or 2 Dual uFF (4x M.2 cartridges) |
| Network Controller | Embedded 1Gb Ethernet 4-Port 331i Adapter or Choice of HPE FlexibleLOM and stand-up card for additional NICs. | Choice of HPE FlexibleLOM and stand-up card for additional NICs. | Embedded 1Gb Ethernet 4-Port 331i Adapter or Choice of HPE FlexibleLOM and stand-up card for additional NICs. | |||||
| Fans | 1 CPU – 5 Standard Fans 2 CPU – 7 Standard Fans Optional: High Performance Fans |
2 CPU – 7 High Performance Fans | 1 CPU – 5 Standard Fans 2 CPU – 7 Standard Fans Optional: High Performance Fans |
2 CPU – 7 High Performance Fans | 1 CPU – 5 Standard Fans 2 CPU – 7 Standard Fans Optional: High Performance Fans |
|||
| Management | HPE iLO with Intelligent Provisioning (standard) Optional: iLO Advanced and OneView |
|||||||
| USB | Front: 1 USB 3.0 + iLO service port Rear: 2 USB 3.0 Internal: 2 USB 3.0 Optional: 1 USB 2.0 (lose iLO serv. Port) |
Front: 1 USB 3.0 + iLO service port Rear: 2 USB 3.0 Internal: 2 USB 3.0 |
Front: 1 USB 3.0 + iLO service port Rear: 2 USB 3.0 Internal: 2 USB 3.0 Optional: 1 USB 2.0 (lose iLO serv. Port) |
|||||
The refurbished HPE ProLiant DL360 Gen10 server delivers security, agility and flexibility without compromise. It supports the Intel Xeon Scalable processor with up to a 60% performance gain and 27% increase in cores, along with 2933 MT/s HPE DDR4 SmartMemory supporting up to 3.0 TB with an increase in performance of up to 82%.
With the added performance that HPE Persistent Memory, HPE NVDIMMs and 10 NVMe bring, the HPE ProLiant DL360 Gen10 means business. Deploy, update, monitor and maintain with ease by automating essential server life cycle management tasks with HPE OneView and HPE Integrated Lights Out 5 (iLO 5). Deploy this 2P secure platform for diverse workloads in space constrained environments.
Industry-leading Performance with Versatile Compute
HPE ProLiant DL360 Gen10 Server supports industry-standard technology leveraging the Intel Xeon Scalable processor with up to 28 cores, 12G SAS and 3.0 TB of 2933 MT/s HPE DDR4 SmartMemory.
HPE Persistent Memory works with DRAM to provide fast, high capacity, cost effective memory and storage to transform big data workloads and analytics by enabling data to be stored, moved, and processed quickly.
Achieve greater capacity with flexible drive configurations with up to 10 SFF and four LFF drives along with an option to support up to 10 NVMe PCIe SSDs delivering enhanced performance, capacity, and reliability to meet various customer segments and workload requirements at the right economics.
With support for up to 12 NVDIMMs per chassis and 2X capacity of first-generation HPE NVDIMMs, HPE ProLiant DL360 Gen10 Server delivers up to 192 GB per system.
Need assistance with customization? Our sales experts are here to help you.
Start Customizing Today!
Spec Sheet 4
| Technical specifications | HPE ProLiant DL360 Gen10 server |
|---|---|
| Processor name | Intel |
| Processor family | Intel® Xeon® Scalable 8100/8200 series - Intel® Xeon® Scalable 3100/3200 series |
| Number of processors | 2, maximum depending on model |
| Processor core available | 4 to 28 core, depending on model |
| Processor cache | 8.25 - 38.50 MB L3, depending on processor |
| Processor speed | 3.9 GHz, maximum depending on processor |
| Expansion slots | 3, for detailed descriptions refer to the QuickSpecs |
| Maximum memory | 3.0 TB with 128 GB DDR4 6.0 TB with HPE 512GB 2666 Persistent Memory Kit |
| Memory, standard | 3.0 TB (24 X 128 GB) LRDIMM 6.0 TB (12 X 512 GB) HPE Persistent Memory |
| Memory slots | 24 DIMM slots |
| Memory type | HPE DDR4 SmartMemory and Intel® Optane™ persistent memory 100 series for HPE, depending on model |
| System fan features | Hot-plug redundant standard |
| Network controller | Embedded 4 X 1GbE Ethernet Adapter (select models) or HPE FlexibleLOM and optional PCIe stand-up cards, depending on model |
| Storage controller | HPE Smart Array S100i and/or HPE Essential or Performance RAID controllers, depending on model |
| Product Dimensions (imperial) | SFF Chassis: 1.69 x 17.11 x 27.83 in, LFF Chassis: 1.69 x 17.11 x 29.5 in |
| Weight | 28.74 lb minimum, 37 lb maximum |
| Infrastructure management | HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) Optional- HPE iLO Advanced, and HPE OneView Advanced (require licenses) |
| Drive supported |
|
