Dell PowerEdge R7525

The Dell PowerEdge R7525 is a 2U dual-socket rack server running up to two 2nd or 3rd Generation AMD EPYC processors with up to 64 cores each. It offers 32 DDR4 DIMM slots (up to 2TB RDIMM or 4TB LRDIMM at up to 3200 MT/s), up to 24x 2.5" NVMe/SAS/SATA or 12x 3.5" front drives plus two rear bays, up to eight PCIe Gen4 slots, up to three 300W double-width or six 75W single-width GPUs, two 1GbE LOM ports and an OCP 3.0 slot. Managed by iDRAC9, it handles data analytics, VDI and HPC. Fully configurable.

Looking to compare generations? See its Gen 16 successor, the Dell PowerEdge R7625, or compare Gen 15 models: Dell PowerEdge R7515 and Dell PowerEdge R750xa.

Thanks for the request. We'll get back to you with in 24 hours.

  • Form Factor: 2U Rack
  • Processors: Up to 2x 2nd or 3rd Gen AMD EPYC (up to 64 cores)
  • Memory: 32x DDR4 DIMM slots, up to 2TB RDIMM or 4TB LRDIMM
  • Memory Speed: Up to 3200 MT/s
  • Storage: Up to 24x 2.5" NVMe/SAS/SATA or 12x 3.5", plus 2x rear 2.5"
  • Expansion: Up to 8x PCIe Gen4 slots
  • GPU Support: Up to 3x 300W DW or 6x 75W SW
  • Networking: 2x 1GbE LOM, 1x OCP 3.0 (x16)
  • Management: iDRAC9
  • Cooling: Air, hot-plug fans
  • Power: Redundant 800W, 1400W or 2400W PSUs

Thanks for the request. We'll get back to you with in 24 hours.

Configure this  R7525 →

Customize & Get Pricing

Configure your Dell PowerEdge R7525 with the exact specs you need

Configure This Server

Dell PowerEdge R7525 vs R7425: Specs & Key Differences

Feature PowerEdge R7525 PowerEdge R7425
Processors Up to 2x 2nd or 3rd Gen AMD EPYC (up to 64 cores) Up to 2x AMD EPYC (Naples, SP3)
CPU Interconnect xGMI-2 xGMI
Memory 32x DDR4 RDIMM, LRDIMM or 3DS
Up to 3200 MT/s		 32x DDR4 RDIMM or LRDIMM
Storage Up to 24x 2.5" NVMe/SAS/SATA or 12x 3.5"
Rear 2x 2.5"		 3.5"/2.5" SAS/SATA, up to 24x PCIe SSD
Storage Controllers H755, H755N, H745, H345, H840, HBA345, HBA355
Software RAID S150		 H330, H730P, H740P, H840, HBA330
Software RAID S140
PCIe Up to 8 (PCIe 4.0) Up to 8 (Gen3 x16)
GPU Support Up to 3x 300W DW or 6x 75W SW Up to 3x 300W DW or 6x 150W SW
Networking 2x 1GbE LOM + OCP 3.0 NDC: 4x 1GbE, 4x 10GbE, 2x 10GbE + 2x 1GbE or 2x 25GbE
Power 800W, 1400W or 2400W 495W to 2400W, 1100W -48V DC
Form Factor 2U Rack 2U Rack

Frequently Asked Questions

Up to two 2nd or 3rd Generation AMD EPYC processors with up to 64 cores each, connected by xGMI-2.

It has 32 DDR4 DIMM slots for up to 2TB with RDIMMs or 4TB with LRDIMMs at bandwidth up to 3200 MT/s. 3DS DIMMs are supported.

Front options include up to 24x 2.5-inch NVMe/SAS/SATA drives (up to 24 NVMe), 16x 2.5-inch SAS/SATA or 12x 3.5-inch SAS/SATA, with an optional rear module for 2x 2.5-inch drives. Please specify your capacity needs when you submit your quote configuration.

Up to three 300W double-width GPUs or up to six 75W single-width GPUs, using up to eight PCIe Gen4 slots.

The R7525 moves from first-generation EPYC (Naples) to 2nd/3rd Gen EPYC, from PCIe Gen3 to Gen4, and adds OCP 3.0 networking, NVMe on all 24 bays and PERC 11 controllers. Both offer 32 DIMM slots and up to three 300W double-width GPUs.
