Module Specs
- Product Name: Dell TPM Trusted Platform Module 2.0
- Version: TPM 2.0 8-Pin
- Interface: LPC (Low Pin Count)
- Form Factor: Internal Module
- Security: Hardware-based cryptographic operations
- Compliance: TCG (Trusted Computing Group) standards
Part Number:
- M48YR
The Dell TPM Trusted Platform Module 2.0 (M48YR) is a hardware-based security solution designed to provide tamper-resistant protection for sensitive data and cryptographic keys. It supports a wide range of security features, including secure boot, device authentication, and BitLocker drive encryption, ensuring that only trusted software and firmware are loaded during system startup. This module adheres to the Trusted Computing Group (TCG) standards, ensuring interoperability and industry compliance.
Installed internally on compatible Dell motherboards, the TPM 2.0 module operates via the LPC interface, providing an extra layer of protection beyond traditional software-based security. Its cryptographic functions help establish a hardware root of trust, essential for modern enterprise environments concerned with data integrity and protection from firmware-level threats. The M48YR is particularly valuable for organizations looking to enhance endpoint security in compliance with corporate and governmental IT policies.
- Dell C6300
- Dell C6320
- Dell C6520
- Dell FC830
- Dell M830
- Dell R230
- Dell R330
- Dell R430
- Dell R530
- Dell R630
- Dell R730
- Dell R730xd
- Dell R830
- Dell R930
(Click to View)
