What’s New
- Up to 2 Intel Xeon 6 processors
- 32 DDR5 DIMM slots – maximum memory 8 TB
- Five to seven system fans
- Up to 10 SFF, or 20 E#.S
- Up to three x16 PCIe Gen5
- OCP 3.0 support
- Up to 2 HPE power supplies
- NS204i-u boot device with 3 install option
- HPE iLO 7 management
- Up to 3 Single-Wide, low-profile GPUs
Other Versions
(Click to View)
Please Upgrade Server
*This Configure to Order has not been created.
*You can still
Contact Us
for a quote on this server.
*Thank you.
The request has been sent.
Thank you.
Price as Configured:
$0
Base Standard Capabilities
| Processor type | Intel |
|---|---|
| Processor family | Intel® Xeon® 6 Scalable processors |
| Processor number | 1 or 2 |
| Processor core available | 8 to 144 core, depending on processor |
| Processor speed | 4.0 GHz maximum, depending on processor |
| Processor cache | 48 MB to 336 MB L3 cache, depending on processor |
| Memory type | HPE DDR5 Smart Memory |
| Maximum memory | 8 TB with 256 GB DDR5 |
| Memory slots | 32 DDR5 DIMM slots (16 per processor) |
| Memory protection features | On-Die ECC (Error Correction Code) designed to correct bit errors within the DRAM |
| Accelerators | 3 Single-wide GPU in rear |
| System fan features | Standard Fan Kit (Q'ty 5), Standard Fan Kit (Q'ty 2) for 2nd Processor, High performance Fan Kit (Q'ty 7), Close Loop Liquid Cooling Heatsink & Fan kit, Direct Liquid Cooling Solution. |
| Expansion slots | Maximum 3 PCIe Gen5 slots (x16 lanes/each) & Maximum 2 OCP3.0 slots (x16 lanes/each) |
| Form factor | 1U Rack |
| Network controller | Optional - Minimum 1 to be selected. Wide range of speeds, cabling, chipsets and form factors (PCIe stand-up adapter and OCP3.0 in rear/front). Please see QuickSpecs for network card choices. |
| Storage controller | Optional - HPE ProLiant Compute Smart Array Gen12 Storage Controller in variety of protocols — including PCIe Gen5, NVMe, port count, array utilities, and form factors (PCIe stand-up adapter and OCP3.0). Optional - Intel® VROC Hybrid RAID for NVMe. Optional - HPE ProLiant Compute Gen12 OS Boot Device, in rear or front accessible or internal. Please see QuickSpecs for storage controllers selection. |
| Drive supported | Up to 4 LFF SAS/SATA HDDs or SSDs, optional 1 OS Boot device (internal, external accessible from rear wall); Up to 8+2 SFF SAS/SATA HDDs or SATA/SAS/NVMe U.3 SSDs, optional 1 OS Boot device (internal, external accessible from rear wall); Up to 10 SFF/20 E3.S to be mixed, optional 1 OS Boot Device (internal, external accessible from rear wall or front cage), optional 2 front OCP NICs |
| Optical drive type | Optional - HPE 9.5 mm SATA DVD-RW Optical Drive, HPE Mobile USB DVD-RW Drive. |
