- Single configurable Intel Xeon 6 processor (up to 144 cores)
- 16 DDR5 DIMM slots – maximum memory 4 TB
- Seven system fans (standard or high-performance kits)
- Up to two full-height half-length x16 PCIe Gen5 slots
- OCP 3.0 support (rear and optional front configurations)
- One or two M-CRPS titanium hot-plug power supplies (1000W, 1500W, or 2400W options)
- NS204i-u front or rear install option based on configuration.
- Optional dual M.2 NVMe boot device with hardware RAID 1
- HPE iLO 7 management
- Support for up to four single-wide or two double-wide GPUs (configuration dependent)
(Click to View)
The HPE ProLiant DL320 Gen12 is designed to get more compute density out of each rack unit while reducing power and virtualization constraints. It delivers stronger expansion options than earlier generations, driven by Intel Xeon 6 processors that scale up to 144 cores, support for as much as 4 TB of memory, and PCIe Gen5 connectivity for higher performance and improved data-center efficiency.
4 LFF P75218-B21
12 LFFP75219-B21
8 SFFP71437-B21
SFF / EDSFFP75217-B21
GPUP75220-B21
12 LFF CTO Server requires 1200mm depth rack for proper mounting.
Please Upgrade Server
*This Configure to Order has not been created.
*You can still
Contact Us
for a quote on this server.
*Thank you.
The request has been sent.
Thank you.
Price as Configured:
$0
Base Standard Capabilities
| Technical specifications | HPE ProLiant Compute DL320 Gen12 |
|---|---|
| Processor type | Intel |
| Processor family | Intel Xeon 6 processors |
| Processor number | 1 |
| Processor core available | 8 to 144 cores, depending on processor |
| Processor speed | Up to 3.5 GHz maximum, depending on processor |
| Processor cache | 48 to 336 MB L3 total, depending on processor |
| Memory type | HPE DDR5 Smart Memory |
| Maximum memory | 4.0 TB when using 256 GB DDR5 modules |
| Memory slots | 16 |
| Accelerators | Up to 2 double-wide or 4 single-wide in the front, or 1 single-wide in the rear (model dependent) |
| System fan features | Standard Fan Kit or High Performance Fan Kit (model dependent) |
| Expansion slots | Up to 6 PCIe Gen5 plus 2 OCP 3.0 (with Rich I/O processor); see QuickSpecs for details |
| Form factor | 1U Rack |
| Network controller | Wide range of speeds, cabling, chipsets and form factors (PCIe stand-up or OCP 3.0). See QuickSpecs for options |
| Storage controller | Optional – HPE MR216i-o, MR216i-p, MR408i-o, MR408i-p, MR416i-o, and MR416i-p. See QuickSpecs for selection |
| Drive supported | Up to 8+2 SFF SAS/SATA HDDs or SATA/SAS/NVMe U.2/U.3 SSDs (model dependent). Up to 12 LFF SAS/SATA HDDs or SSDs (model dependent). Up to 20 EDSFF E3.S 1T (model dependent). Optional RAID 1 NVMe M.2 boot device (internal or external, with 2x NVMe M.2) |
| Optical drive type | Optional DVD-ROM / DVD-RW |
| Power supply type | 1000W, 1500W, or 2400W Titanium Hot-Plug Modular Common Redundant Power Supply (M-CRPS) |
