HPE Apollo 4200 Gen10 Plus 2Lff Sas/Sata Lp Secondary Drive Cage 5 And Pcie Tertiary Riser Kit | P44984-B21

Drive Cage Specs

: One of the Secondary and Tertiary Kits is required per system.
− The PCIe Secondary and Tertiary Riser Kit (P28717-B21) include one X16 FHHL slot 4, one X8 FHHL slot 5, one X16 FHHL slot 6, and one X8 FHHL slot 7.
− The Secondary Drive Cage 5 and PCIe Tertiary Riser Kit (P28718-B21) includes 2SFF Drive Cage 5, one X16 FHHL slot 6, and one x8 FHHL slot 7.
− HPE Apollo 4200 Gen10 Plus PCIe Secondary and Tertiary Riser Kit (P28717-B21) is suggested for single processor configurations
− The rear LFF Cage4 and Cage5 are bundled, quantity one of the following SKUs are required when configure rear LFF Drive Cages:
P44987-B21, P44984-B21, P44990-B21, and 869083-B21.
− The core options for the rear drive cage 4/5, necessary controller(s), and controller cable kit selection are suggested to be configured at the factory. Customers can upgrade or change the rear drive cage 4 /5 core option or cable kit after they are installed and cabled in the factory, but these changes may require added service costs and new parts to complete this upgrade.
− Customers swapping between the PCIe riser and the rear SFF drive cage 4/5 kit(s) will incur new parts cost but no added service cost. Swapping from any other configurations will require additional parts cost and added HPE service cost.
− Additionally, customers can still install, upgrade, or swap the SFF, LFF or NVMe drives for Cage 4 /5 after the systems have left the factory if the new drives are supported by the drive cage 4/5, proper controller(s), and cable kit selection.
