Netapp Ds224C Expansion Shelf 12X 800Gb Sas 12Gbps Nse Ssd (X440B-R6) | DS224C-AF-0.8-12N-0P-C
Thanks for the request. We'll get back to you with in 24 hours.
Condition: Refurbished ✓ Pulled from working servers & Tested. ✓ 1-year Parts Warranty.
Warranty | Return Policy
-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.
NetApp DS224C with 12x 800GB SAS 12Gbps SSD X440B-R6 Disk Shelf achieves both storage and performance in a 2U form factor. The DS224C has the ability to use performance SAS drives, SSD's or Self-Encrypting drives. This DS224C is populated with twelve 800GB SAS 12Gbps SSD (X440A-R6), comes with all necessary parts and a 1-Year Parts Replacement Warranty as standard.
Parts Included:
- 1x DS224C Disk shelf
- 12x 800GB SAS 12Gbps SSD (X440A-R6)
- 2x X5720A IOM12 Controller 12gbps
- 2x X526A-R6 913W AC PSU
- 1x X5529A-R6 Railkit 19” 4 Post Universal (or sub)
- 2x X66030A .5m HD Mini SAS – HD Mini SAS (longer cables available please ask for custom order)
- 2x X800-42U C13-C14 Power Cables
| Technical Specifications | |
|---|---|
| Drive Count | 24 |
| Physical Characteristics | |
Rack Units |
2 |
Weight (Empty) |
35.27 lb (16 kg) |
Height |
3.35'' (8.5 cm) |
Width with Mounting |
18.9'' (48 cm) |
Width without Mounting Flanges |
17.6'' (44.7 cm) |
Depth with Cable Mgmt |
20.2'' (51.3 cm) |
Depth without Cable Mgmt |
19.06'' (48.4 cm) |
| Clearance Dimensions | |
Front Clearance (Cooling/Maintenance) |
6.02'' (15.3 cm) 22.01'' (55.9 cm) |
Rear Clearance (Cooling/Maintenance) |
12.01'' (30.5 cm) 12.01'' (30.5 cm) |
| Environmental Requirements | |
Operating Temperature Range |
50 to 104 deg F 10 to 40 deg C |
Storage Temperature Range |
-40 to 158 deg F -40 to 70 deg C |
Transit Temperature Range |
-40 to 158 deg F -40 to 70 deg C |
Operating Relative Humidity |
20 to 80 % |
Storage Relative Humidity |
10 to 95 % |
Transit Relative Humidity |
10 to 95 % |
Operating Altitude Range |
0 to 9987.6 ft 0 to 3045 m |
Storage Altitude Range |
-1000.4 to 39989.76 ft -305 to 12192 m |
Transit Altitude Range |
-1000.4 to 39989.76 ft -305 to 12192 m |
Acoustic Noise - Sound Power |
- |
Acoustic Noise - Sound Pressure |
- |
Input Power Voltage |
100 to 120, 200 to 240 |
