Dell PowerEdge T320 Tower Server Chassis (8x3.5")

PET320-8x3.5 | Refurbished Dell PowerEdge T320 Tower Server Chassis (8x3.5")

SKU: DPE-T320-8x3.5-Chassis

Dell PowerEdge T320 Tower Server Chassis (8x3.5")

Name: Dell PowerEdge T320 Tower Server Chassis (8x3.5")
Brand: Dell
SKU: DPE-T320-8x3.5-Chassis
Availability: InStock

Dell

| Chassis

.price-ui--loading { display: block !important; opacity: 1 !important; }

Contact For Pricing

Thanks for the request. We'll get back to you with in 24 hours.

Quick Specs

Form Factor:

Tower server 5U (Rack Conversion)

Processor Max: N/A

1x Intel E5-2400 v2, or Pentium

Memory Max: 192GB

6 DDR3 UDIMM 1600Mhz

Storage Max: 32TB

8x 3.5” hot-plug SAS/NL-SAS/SATA (HDD/SSD)

Boot Options

IDSDM

USB

RAID Controller:

S110 (SW RAID SATA)
PERC H310, H710, H710P, H810, 6Gbps SAS HBA (non-RAID)

NIC/LOM

Broadcom® 5720 Dual Port 1Gb LOM

Remote Management:

iDRAC7 with Lifecycle Controller

PCIe Slots: 5

One x16 slot with x16 bandwidth, 3.0, full-length, full-height

One x8 slot with x4 bandwidth, 3.0, half-length, full-height

One x8 slot with x4 bandwidth, 2.0, half-length, full-height

One x8 slot with x4 bandwidth, 3.0, full-length, full-height

One x8 slot with x1 bandwidth, 2.0, full-length, full-height

GPU:

1 single-width or 1 double-width (optional)

Other Versions

Ideal for:

Virtualization

Looking to Customize?

Need assistance with customization? Our sales experts are here to help you.

Start Customizing Today!

Base Standard Capabilities

Feature	PowerEdge T320 technical specification
Form factor	Tower (5U rackable)
Processors	Intel® Xeon® processor E5-2400 product family Intel Xeon processor E5-1410 Intel Pentium® processor 1400 product family
Processor sockets	1
Internal interconnect	Intel DMI 2.0
Cache	2.5MB per core; core options: 2, 4, 6, 8
Chipset	Intel C600 series
Memory	Up to 192GB (6 DIMM slots): 2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s
I/O slots	5 PCIe slots: • One x16 slot with x16 bandwidth, 3.0, full-length, full-height • One x8 slot with x4 bandwidth, 3.0, half-length, full-height • One x8 slot with x4 bandwidth, 2.0, half-length, full-height • One x8 slot with x4 bandwidth, 3.0, full-length, full-height • One x8 slot with x1 bandwidth, 2.0, full-length, full-height
GPU options	One NVIDIA® Quadro® 6000 or 4000 graphics card
RAID controller	Internal controllers: PERC S110 (SW RAID) PERC H310 PERC H710 PERC H710P	Internal HBAs (non-RAID): Internal tape adapter External HBAs (RAID): PERC H810 External HBAs (non-RAID): 6Gbps SAS HBA
Drive bays	Choose from four 3.5” cabled, eight 3.5” hot-plug, or sixteen 2.5” hot-plug drive bays
Maximum internal storage	Up to 32TB
Hard drives	Hot-plug hard drive options: 2.5” SATA, nearline SAS, SAS (15K, 10K), SAS SSD, SATA SSD 3.5” SATA, nearline SAS, SAS (15K) Self-encrypting drives available	Cabled hard drive options: 3.5” SATA, nearline SAS, SAS (15K)
Embedded NIC	Broadcom 5720 Dual Port 1Gb LOM
I/O adapter options	1Gb Ethernet: Broadcom 5720 Dual Port 1Gb NIC Broadcom 5719 Quad Port 1Gb NIC Intel I350 Dual Port 1Gb stand-up adapter Intel I350 Quad Port 1Gb stand-up adapter	FC4 HBA: QLogic QLE2460 4Gb Single Port FC HBA QLogic QLE2462 4Gb Dual Port FC HBA
Power supply	Platinum efficiency, hot-plug, redundant 495W or 750W power supply Silver efficiency, cabled 350W power supply Auto-ranging power supplies
Availability	Optional high-efficiency, hot-plug, redundant power supplies; hot-plug drive bays; TPM; dual internal SD support; redundant fans; optional bezel; information tag; ECC memory; optional interactive LCD screen; extended thermal support; ENERGY STAR® compliant
Remote management	Basic management (default) iDRAC7 with Lifecycle Controller iDRAC7 Express (upgrade option) or iDRAC7 Enterprise (upgrade option) 8GB or 16GB vFlash media (upgrade options)
Systems management	IPMI 2.0 compliant OpenManage™ Essentials and Dell Management Console OpenManage Power Center Dell OpenManage Connections: • OpenManage Integration Suite for Microsoft® System Center • Dell plug-in for VMware® vCenter® • HP Operations Manager, IBM Tivoli® Netcool®, and CA Network and Systems Management (NSM)
Rack support	ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm
Operating systems	Microsoft Windows Server 2012 Microsoft Windows Server 2012 Essentials Microsoft Windows Server 2008 R2 SP1, x64 (includes Hyper-V® v2) Microsoft Windows® Small Business Server 2011 Novell® SUSE® Linux Enterprise Server Red Hat® Enterprise Linux® Optional embedded hypervisors: Citrix® XenServer® VMware® vSphere® ESX™ and ESXi™ Red Hat Enterprise Virtualization® For more information on the specific versions and additions, visit Dell.com/OSsupport.

Spec Sheet 4

Feature	PowerEdge T310	PowerEdge T320
Chassis	5U tower	5U rackable tower
Processors	Intel Xeon processor 3400 product family	Intel Xeon processor E5-2400 v2 product family, Intel Xeon processor E5-1410, Intel Pentium processor 1400 product family
Internal interconnect	Intel DMI	Intel DMI 2.0
Memory	Up to 6 x DDR3 RDIMM or 4 x DDR3 UDIMM	Up to 6 x DDR3 RDIMM and UDIMM up to 1600MT/s
Hard drive bays	Up to 4x 3.5" 2.5" hot plug or cabled	Up to 16x 2.5" or 8 x 2.5"/3.5" hot plug or 4 x 3.5" cabled
RAID controller	PERC 6/i, SAS 6/iR, PERC 6/E, H200, H700, H800, S100, S300	PERC H310, H710, H710P, H810, S110
PCI slots	Up to 5 PCIe 2.0	Up to 3 PCIe 3.0 and 2 PCIe 2.0
Embedded NICs	2 x 1GbE Dual Port LOM with optional TOE	2 x 1GbE Dual Port LOM with optional TOE
Power supplies	Non-redundant 375W Redundant 400W	Non-redundant 350W Hot-plug redundant 495W, 750W
Dell OpenManage Systems Management	Dell OpenManage Lifecycle Controller 1.x iDRAC6 (Express or Enterprise) with Lifecycle Controller	OpenManage Essentials OMSA Agent OpenManage Power Center (requires iDRAC7 Enterprise with Lifecycle Controller) OpenManage Integrations and Connections Basic management (standard option)
Internal GPU	Not supported	1 single-width or 1 double-width (optional)
Power efficiency	Silver	Platinum
Availability	Hot-plug drives Hot-plug redundant power supply units	Hot-plug drives Hot-plug redundant power supply units Fan fault tolerance Dell fault-resilient memory
