Dell PowerEdge R940xa

The Dell PowerEdge R940xa is a 4U four-socket server that pairs CPU power with GPU acceleration for database, analytics and AI work. It runs up to four 2nd Gen Intel Xeon Scalable processors with up to 28 cores each and takes up to four double-width GPUs, matching one GPU to each CPU. 48 DDR4 DIMM slots hold up to 6TB at 2933 MT/s (more with Optane persistent memory), and the front can hold up to 32x 2.5" drives with up to 4 NVMe. Up to 12 PCIe Gen3 slots, an NDC for networking and iDRAC9 complete it. Fully configurable.

Looking to compare generations? See its Gen 16 successor, the Dell PowerEdge R960, or compare Gen 14 models: Dell PowerEdge R940 and Dell PowerEdge R840.

Thanks for the request. We'll get back to you with in 24 hours.

  • Form Factor: 4U Rack
  • Processors: Up to 4x 1st or 2nd Gen Intel Xeon Scalable
  • Memory: 48x DDR4 DIMM slots, up to 6TB
  • Memory Speed: Up to 2933 MT/s
  • Storage: Up to 32x 2.5" (up to 4 NVMe)
  • Expansion: Up to 12x PCIe Gen3 slots
  • GPU Support: Up to 4x double-width
  • Networking: NDC: 4x 1GbE, 4x 10GbE or 2x 25GbE
  • Management: iDRAC9
  • Cooling: Air, 6 hot-swap fans
  • Power: Redundant PSUs, 1100W to 2400W

Thanks for the request. We'll get back to you with in 24 hours.

Configure this  R940XA →

Customize & Get Pricing

Configure your Dell PowerEdge R940xa with the exact specs you need

Configure This Server

Dell PowerEdge R940xa vs R960: Specs & Key Differences

Feature PowerEdge R940xa PowerEdge R960
Processors Up to 4x 2nd Gen Intel Xeon Scalable (up to 28 cores) Up to 4x 4th Gen Intel Xeon Scalable
Memory 48x DDR4 DIMM slots, up to 6TB 64x DDR5 DIMM slots, up to 16TB
Memory Speed Up to 2933 MT/s Up to 4800 MT/s
Storage Up to 32x 2.5" (up to 4 NVMe) Up to 32x 2.5" (up to 24x NVMe)
PCIe Up to 12x PCIe Gen3 Up to 12x PCIe Gen5
GPU Support Up to 4x double-width Up to 4x 400W double-width
Networking NDC: 4x 1GbE, 4x 10GbE or 2x 25GbE Optional 2x 1GbE LOM, 1x OCP 3.0
Power 1100W to 2400W 1100W to 2800W
Form Factor 4U Rack 4U Rack

Frequently Asked Questions

Up to four Intel Xeon Scalable processors. With 2nd Gen parts that means up to 28 cores per socket and up to 112 cores in total.

Up to four double-width GPUs, or up to four double-width or eight single-width FPGAs, installed in the x16 riser slots.

Forty-eight DDR4 sockets support up to 6TB of RDIMM or LRDIMM memory at up to 2933 MT/s. It can also take up to 24 Optane persistent memory modules, although they cannot be combined with GPUs.

Front bays take 8, 24 or 32 2.5-inch SAS/SATA drives, with up to four NVMe SSDs, plus BOSS M.2 boot. Please specify your capacity needs when you submit your quote configuration.

The Gen 16 R960 moves to 4th Gen Xeon Scalable, DDR5-4800 memory up to 16TB, PCIe Gen5 and up to 24 NVMe drives, and still takes four double-width GPUs. The R940xa offers a similar 4-CPU, 4-GPU layout at a lower cost.
