Dell PowerEdge R740xd2

The Dell PowerEdge R740xd2 is a 2U two-socket storage server built to keep huge data sets on premises, from video archives and backup targets to software-defined storage nodes. It holds up to 26 3.5" drives (24 in front plus 2 in the rear) and runs up to two 2nd Gen Intel Xeon Scalable processors with up to 22 cores each, with 16 DDR4 RDIMM slots for up to 1TB at 2933 MT/s. Up to five PCIe Gen3 slots, a LOM riser for 10GbE or 25GbE, BOSS M.2 boot and iDRAC9 round it out. Fully configurable.

Looking to compare generations? See its Gen 16 successor, the Dell PowerEdge R760xd2, or compare Gen 14 models: Dell PowerEdge R740xd and Dell PowerEdge R540.

Thanks for the request. We'll get back to you with in 24 hours.

  • Form Factor: 2U Rack
  • Processors: Up to 2x 1st or 2nd Gen Intel Xeon Scalable
  • Memory: 16x DDR4 RDIMM slots, up to 1TB
  • Memory Speed: Up to 2933 MT/s
  • Storage: Up to 24x 3.5" front + 2x rear
  • Expansion: Up to 5x PCIe Gen3 slots
  • GPU Support: Not listed by Dell
  • Networking: 2x 1GbE LOM + optional LOM riser
  • Management: iDRAC9
  • Cooling: Air, 6 fans with N+1 redundancy
  • Power: Redundant PSUs, 750W or 1100W

Thanks for the request. We'll get back to you with in 24 hours.

Configure this  R740XD2 →

Customize & Get Pricing

Configure your Dell PowerEdge R740xd2 with the exact specs you need

Configure This Server

Dell PowerEdge R740xd2 vs R760xd2: Specs & Key Differences

Feature PowerEdge R740xd2 PowerEdge R760xd2
Processors Up to 2x 2nd Gen Intel Xeon Scalable (up to 22 cores) Up to 2x 4th/5th Gen Intel Xeon Scalable
Memory 16x DDR4 RDIMM slots, up to 1TB 16x DDR5 DIMM slots, up to 1.5TB
Memory Speed Up to 2933 MT/s Up to 4800 MT/s
Storage Up to 24x 3.5" front + 2x rear Up to 28x 3.5" (front, mid and rear)
PCIe Up to 5x PCIe Gen3 Up to 5x PCIe Gen4
GPU Support Not listed by Dell Up to 2x 75W SW or 1x 180W DW
Networking 2x 1GbE LOM + optional LOM riser 2x 1GbE LOM, 1x OCP 3.0
Management iDRAC9 iDRAC9
Power 750W or 1100W 700W to 1800W
Form Factor 2U Rack 2U Rack

Frequently Asked Questions

Up to two Intel Xeon Scalable processors. With 2nd Gen parts you get up to 22 cores per socket, which is plenty for storage-heavy workloads.

Up to 24 front 3.5-inch SAS/SATA bays plus two rear bays, so 26 large drives in only 2U. Some front bays can take 2.5-inch SSDs in hybrid carriers for a mix of flash and disk. Please specify your capacity needs when you submit your quote configuration.

Sixteen DDR4 RDIMM sockets support up to 1TB, running at up to 2933 MT/s with 2nd Gen Xeon Scalable processors.

The R740xd2 is tuned for raw capacity, with up to 26 3.5-inch drives in sliding drive sleds, while the R740xd offers more memory (24 slots, up to 3TB), more NVMe and GPU options.

The Gen 16 R760xd2 moves to 4th and 5th Gen Xeon Scalable, DDR5-4800 memory up to 1.5TB, PCIe Gen4 slots, up to 28 3.5-inch bays and GPU options. The R740xd2 delivers similar density at a lower cost.
