Dell PowerEdge R6725

The Dell PowerEdge R6725 is a 1U dual-socket rack server powered by two 5th Gen AMD EPYC 9005 Series processors with up to 192 cores each. It supports 24 DDR5 DIMM slots (up to 6TB, speeds up to 6400 MT/s), up to three PCIe Gen5 slots, two optional OCP 3.0 NICs, up to three 75W single-width GPUs and up to 20x EDSFF E3.S Gen5 NVMe front drives, with air or Direct Liquid Cooling. Managed by iDRAC10, it packs high core density into 1U for virtualization, VDI and high-performance computing. Fully configurable.

Looking to compare generations? See the Gen 16 Dell PowerEdge R660, or compare Gen 17 models: Dell PowerEdge R6715 and Dell PowerEdge R670.

Thanks for the request. We'll get back to you with in 24 hours.

  • Form Factor: 1U Rack
  • Processors: Up to 2x AMD EPYC 9005
  • Memory: 24x DDR5 DIMM slots, up to 6TB
  • Memory Speed: Up to 6400 MT/s
  • Storage: Up to 20x E3.S, 10x 2.5" or 4x 3.5"
  • Expansion: Up to 3x PCIe Gen5 slots
  • GPU Support: Up to 3x 75W single-width
  • Networking: Up to 2x OCP 3.0
  • Management: iDRAC10
  • Cooling: Air or Direct Liquid Cooling
  • Power: Redundant PSUs, 800W to 1500W

Thanks for the request. We'll get back to you with in 24 hours.

Configure this  R6725 →

Customize & Get Pricing

Configure your Dell PowerEdge R6725 with the exact specs you need

Configure This Server

Dell PowerEdge R6725 vs R6625: Specs & Key Differences

Feature PowerEdge R6725 PowerEdge R6625
Processors 2x AMD EPYC 9005 (up to 192 cores each) 2x AMD EPYC 9004 (up to 128 cores each)
Memory 24x DDR5 DIMM slots, up to 6TB
Up to 6400 MT/s		 24x DDR5 DIMM slots, up to 6TB
Up to 4800 MT/s
PCIe Up to 3x PCIe Gen5 slots Up to 3x PCIe Gen5/Gen4 slots
GPU Support Up to 3x 75W SW Up to 3x 75W SW
Storage Up to 20x E3.S, 10x 2.5" or 4x 3.5"
Rear 2x E3.S		 Up to 16x E3.S, 10x 2.5" or 4x 3.5"
Rear 2x 2.5" or 2x E3.S
Networking Up to 2x OCP 3.0 2x 1GbE LOM + 1x OCP 3.0
Management iDRAC10 iDRAC9
Cooling Air or DLC Air or optional DLC
Power 800W to 1500W 800W to 1800W
Form Factor 1U Rack 1U Rack

Frequently Asked Questions

The R6725 is a dual-socket server that takes two 5th Gen AMD EPYC 9005 Series processors with up to 192 Zen 5 cores each and up to 500W TDP. Some high-TDP processor SKUs and configurations require Direct Liquid Cooling.

It has 24 DDR5 RDIMM slots, 12 per processor at one DIMM per channel, running at up to 6400 MT/s. Maximum capacity is up to 6TB. Only registered ECC DDR5 DIMMs are supported.

Yes. It supports up to three 75W single-width, low-profile GPUs. Cooling is air with up to four dual hot-plug fan modules and N+1 fan redundancy, or optional Direct Liquid Cooling (DLC) for the highest-power CPUs.

Front options include 4x 3.5-inch SAS/SATA, 8x 2.5-inch universal or U.2, 10x 2.5-inch SAS/SATA (or 10x 2.5-inch with 4 universal), 8 or 16 EDSFF E3.S Gen5 NVMe, or 20x E3.S plus 2 rear E3.S drives. Boot is handled by BOSS-N1. Please specify your capacity needs when you submit your quote configuration.

The R6725 moves from two EPYC 9004 CPUs with up to 128 cores each to two EPYC 9005 CPUs with up to 192 cores each. Memory speed rises from 4800 to 6400 MT/s on the same 24 DDR5 slots, PCIe slots are all Gen5, E3.S capacity grows to 20 front bays, it adds a second OCP 3.0 slot, and management moves from iDRAC9 to iDRAC10.
