Home / All / Dell PowerEdge R570

Condition: Refurbished ✓ Pulled from working servers & Tested. ✓ 1-year Parts Warranty.

Warranty | Return Policy

Dell PowerEdge R570

The Dell PowerEdge R570 delivers strong single-socket performance in a compact 2U rack design, powered by one Intel Xeon 6 processor (up to 144 E-cores or 86 P-cores). Sixteen DDR5 slots support speeds to 6400 MT/s and up to 4 TB of memory. Dense EDSFF Gen5 NVMe storage, up to six PCIe Gen5 slots, and GPU options (three 400 W DW or four 75 W SW) expand its capabilities. Energy-efficient and cyber-resilient, it suits virtualization, scale-out databases, edge compute, VDI, and software-defined storage. Fully configurable.

Looking to compare generations? See the previous Dell PowerEdge R550

Thanks for the request. We'll get back to you with in 24 hours.

  • Form Factor: 2U rack server
  • Processors: One Intel Xeon 6 E-core (up to 144 cores) or one Intel Xeon 6 P-core (up to 86 cores with R1S option)
  • Memory: 16 DDR5 DIMMs; 1TB (E-core) or 4TB (P-core)
  • Memory Speed: Up to 6400 MT/s
  • Storage: 12× 3.5″ SATA, 24× 2.5″ SATA, or 32× EDSFF E3.S Gen5 NVMe;
    rear EDSFF options;
    PERC H365i/H965i controllers
  • Expansion:6× PCIe 5.0
  • GPU Support:3× double-width or 4× single-width
  • Networking: two OCP 3.0 NIC cards (front or rear)
  • Management: iDRAC with Direct, RESTful API/Redfish, RACADM, iDRAC Service Module
  • Cooling: Air-cooled
  • Power: Dual hot-swap redundant PSUs

Thanks for the request. We'll get back to you with in 24 hours.

Configure this  R570 →

Customize & Get Pricing

Configure your Dell PowerEdge R570 with the exact specs you need

Configure This Server

Dell PowerEdge R570 vs R550: Specs & Key Differences

Feature PowerEdge R570 PowerEdge R550
Processors 1× Intel Xeon 6 (E-core up to 144 cores or P-core up to 86 cores) Up to 2× 3rd Gen Intel Xeon Scalable (up to 24 cores each)
Memory 16× DDR5 RDIMM, up to 6400 MT/s (1–4 TB max) 16× DDR4 RDIMM, up to 2933 MT/s (1 TB max)
PCIe Up to 6× Gen5 slots (x16) 3× Gen4 + 1× Gen3 slots
GPU Support Up to 3× 400 W DW or 4× 75 W SW Limited (value-focused platform; no high-power GPU support)
Storage High-density EDSFF E3.S Gen5 (up to 32 drives) + flexible 2.5″/3.5″ options Up to 16× 2.5″ or 8× 3.5″ SAS/SATA only
Management Next-gen iDRAC (enhanced security & Redfish) iDRAC9

Frequently Asked Questions

It excels at virtualization and cloud scale-out, medium-density VDI, scale-out databases, software-defined storage nodes, edge compute, and high-performance computing thanks to its high core counts, memory bandwidth, and flexible expansion.

Sixteen DDR5 RDIMM slots support speeds up to 6400 MT/s. Maximum capacity reaches 1 TB with an E-core processor or 4 TB with a P-core (R1S) processor.

Yes. It can accommodate up to three 400 W double-width GPUs or four 75 W single-width cards, making it suitable for inference, VDI acceleration, and lighter AI workloads within thermal limits.

It supports up to 32 EDSFF E3.S Gen5 NVMe drives (plus traditional 2.5″ and 3.5″ options), delivering significantly higher capacity and performance density than previous-generation 2U servers that relied mainly on U.2 or SAS/SATA bays.

Absolutely. Integrated iDRAC provides out-of-band management with Redfish API support, iDRAC Direct, RACADM CLI, and the OpenManage portfolio for automation, security, and fleet-wide monitoring.
