Dell PowerEdge R4715 Rack Server | Configurable

Dell

| CTO Servers

R4715 Overview →



READ ME

  • Some options may not be displayed until the compatible parent option is chosen ie. Chassis – Drives, Processor – RAM etc.
  • “Quote” items can be added to your cart and sent to us via the cart page
  • Click the blue bar to close/open a section from view after choosing your options

Select Chassis

Select Processor

You can not mix CPUs

AMD 9005 Series

Cooling Options

Memory

LFF SAS

SFF SATA

SFF SAS

SFF U.2 NVMe G4

Boot Options

Storage Controllers

Open Compute Program (OCP) 3.0

Riser Configurations

Power Supply Units

ECS Warranty

Helpful Tip: Once desired configuration is selected click "Add to Cart".
From the cart page you can submit a submit a quote request for best pricing

Quick Specs
Form Factor:

1U rack server

Processor | Max: 32 Cores

1x AMD EPYC 9005 Series

Memory | Max: 1.5TB

24 ECC DDR5 RDIMM 5200Mhz
Supports registered ECC DDR5 DIMMs only

Storage:

4 x 3.5" SAS
8 x 2.5" SAS/SATA (Universal)
8 x U.2 NVMe

Storage Controller:

Front PERC H365i, H965i

Boot Options:

BOSS-N1 DC-MHS (rear)

Networking Options (NOC):

Up to 2x OCP 3.0 (25GbE)
1GbE dedicated BMC port

Remote Management:

iDRAC10

PCIe Slots:

Up to 3x G5 x16 (LP)

Other Versions

(Click to View)

Ideal for:
  • Cloud-Native Applications
  • Database
  • Virtualization

The Dell PowerEdge R4715 is a 1U, single-socket rack server built on a 5th Generation AMD EPYC 9005 Series processor with up to 32 Zen 5 cores. With 24 DDR5 RDIMM slots, right-sized SAS/SATA or U.2 NVMe front storage, three PCIe Gen5 slots and dual OCP 3.0 networking, it covers a broad range of everyday data center workloads on a tight budget.

Chassis Configurations
Dell PowerEdge R4715 4 x 3.5in SAS 4 x 3.5" SAS
Dell PowerEdge R4715 8 x 2.5in Universal 8 x 2.5" SAS/SATA Universal
Dell PowerEdge R4715 8 x U.2 NVMe 8 x U.2 NVMe

ⓘ Drives No rear drives. Max weight with 8 x 2.5" Universal SSDs: 19.96 kg.

AMD EPYC 9005 Series

One 5th Generation AMD EPYC 9005 Series processor with up to 32 cores. Processors above 240W TDP are not supported.

AMD EPYC 9005 Series
Supported Processors
  • AMD EPYC 9015 | 8 Cores | 155 W (cTDP)
  • AMD EPYC 9135 | 16 Cores | 240 W (cTDP)
  • AMD EPYC 9255 | 24 Cores | 240 W (cTDP)
  • AMD EPYC 9335 | 32 Cores | 240 W (cTDP)
Single Socket
  • The system supports only one processor.

ⓘ PDF View AMD 9005 Series PDF here

Cooling Options
Dell PowerEdge R4715 C-type Heatsink C-type HSK
Dell PowerEdge R4715 Standard (STD) Fan STD Fan
Dell PowerEdge R4715 High Performance Silver (HPR) Fan HPR Silver Fan
Configuration 8 x 2.5" (smart flow) 4 x 3.5"
EPYC 9015 / 9135 / 9255 / 9335 C-type HSK, STD fan C-type HSK, HPR silver fan
16 / 32 / 64 GB RDIMM STD fan HPR silver fan

ⓘ Fans The PowerEdge R4715 is air cooled with up to four sets of hot-plug dual fan modules. HPR Silver fans are required for 4 x 3.5" configurations and for memory > 96 GB.

Memory Options | 24x DDR5
DIMM type Rank Capacity DIMM voltage
and speed		 Operating Speed Maximum system capacity
RDIMM 1R 16 GB DDR5 (1.1 V),
6400 MT/s		 5200 MT/s 384 GB
2R 32 GB DDR5 (1.1 V),
6400 MT/s		 5200 MT/s 768 GB
64 GB DDR5 (1.1 V),
6400 MT/s		 5200 MT/s 1.5 TB

ⓘ Memory 128 GB and larger RDIMMs are not supported. Mixing module types is not supported; all DIMMs must be RDIMM.

Storage Controllers (Internal)
Dell PowerEdge R4715 Front H965i DC-MHS Front H965i
  • RAID: 0, 1, 5, 6, 10, 50, and 60
  • Cache memory: 8 GB DDR4
  • Supported Drive Types: SAS, SATA and NVMe
  • R4715 upgrade: From onboard controller (8 x U.2) or from H365i (8 x 2.5" Universal)
Dell PowerEdge R4715 Front H365i DC-MHS Front H365i
  • RAID: 0, 1, and 10
  • Cache memory: No
  • Supported Drive Types: SAS, SATA and NVMe
  • R4715 config: 8 x 2.5" Universal, Front PERC 12
Boot Options
Dell PowerEdge R4715 BOSS-N1 DC-MHS BOSS-N1 DC-MHS
Dell PowerEdge R4715 Internal USB Internal USB Port

ⓘ BOSS BOSS-N1 DC-MHS mounts at the rear of the R4715 and supports up to two M.2 NVMe SSDs (PCIe Gen3 x4).

Networking Options (OCP 3.0)
Dell PowerEdge R4715 2 x 25GbE OCP 3.0 2 x 25GbE OCP 3.0
Dell PowerEdge R4715 4 x 25GbE OCP 3.0 4 x 25GbE OCP 3.0

ⓘ OCP Up to two OCP 3.0 NICs plus a 1GbE dedicated BMC port on the DC-SCM. OCP NIC width is x8 on this system board.

Riser Configurations
Dell PowerEdge R4715 Riser (R2r) Riser (R2r)
Dell PowerEdge R4715 Riser (R2k) Riser (R2k)
Dell PowerEdge R4715 Riser (R4a) Riser (R4a)
Config No. Riser configuration PCIe slots Form factor Bandwidth
RC 2: R2r LP + R4 LP 1, 2 LP PCIe Gen5 x16
RC 4: R2r LP + R4a LP 1, 2, 4 LP PCIe Gen5 x16
RC 5: R2k LP + R4a LP 2 (LP + 2nd OCP), 1 LP PCIe Gen5 x16
Remote Management | iDRAC10
Embedded Management
  • iDRAC10 with 1GbE dedicated BMC Ethernet port (DC-SCM)
  • iDRAC Direct via front USB Type-C
  • Optional Quick Sync 2.0 or KVM on the Left Control Panel
Security
  • TPM 2.0, Secure Boot, Silicon Root of Trust
  • System Lockdown, Secure Erase
  • Chassis Intrusion Detection
Power Supply Units (PSU)

Not sure what power supply to use. Dell has a calculator for you - Click Here

Form factor Output Power cord
Redundant 60 mm 800 W Platinum mixed mode C13
800 W Titanium mixed mode C13
1100 W Platinum mixed mode C13
1100 W Titanium mixed mode C13
Dimensions & Weight
Dimensions
  • Width: 482.0mm (18.97")
  • Depth: 786.14mm (30.95") with bezel
  • Height: 42.8mm (1.68")
Weight
  • 8 x 2.5" Universal SSDs (max) 19.96 kg (44.00 lbs)
