Dell PowerEdge R430

The Dell PowerEdge R430 is a short-depth 1U two-socket rack server running up to two Intel Xeon E5-2600 v3 or v4 processors with up to 20 cores each. It offers 12 DDR4 DIMM slots at up to 2400 MT/s, up to 10x 2.5", 8x 2.5" or 4x 3.5" hot-plug drives, two PCIe 3.0 slots and four 1GbE LOM ports. With iDRAC8 and Lifecycle Controller, it fits dense compute into space-limited racks for virtualization and clustered workloads. Fully configurable.

Looking to compare generations? See the Gen 14 Dell PowerEdge R640, or compare Gen 13 models: Dell PowerEdge R630 and Dell PowerEdge R330.

Thanks for the request. We'll get back to you with in 24 hours.

  • Form Factor: 1U Rack
  • Processors: Up to 2x Intel Xeon E5-2600 v3/v4 (up to 20 cores)
  • Memory: 12x DDR4 DIMM slots, up to 384GB
  • Memory Speed: Up to 2400 MT/s
  • Storage: Up to 10x 2.5", 8x 2.5" or 4x 3.5" hot-plug
  • Expansion: 2x PCIe 3.0 slots
  • GPU Support: Not listed by Dell
  • Networking: 4x 1GbE LOM
  • Management: iDRAC8 with Lifecycle Controller
  • Cooling: Air, non-hot-swap fans
  • Power: 450W Bronze or 550W Platinum PSUs

Thanks for the request. We'll get back to you with in 24 hours.

Configure this  R430 →

Customize & Get Pricing

Configure your Dell PowerEdge R430 with the exact specs you need

Configure This Server

Dell PowerEdge R430 vs R440: Specs & Key Differences

Feature PowerEdge R430 PowerEdge R440
Processors Up to 2x Intel Xeon E5-2600 v3/v4 (up to 20 cores) Up to 2x 2nd Gen Intel Xeon Scalable (up to 24 cores)
Memory 12x DDR4 DIMM slots, up to 384GB 16x DDR4 RDIMM/LRDIMM slots, up to 1TB
Memory Speed Up to 2400 MT/s Up to 2666 MT/s
Storage Up to 10x 2.5", 8x 2.5" or 4x 3.5" Up to 10x 2.5" (up to 4 NVMe) or 4x 3.5"
Storage Controllers PERC S130, H330, H730, H730P
External H830		 PERC H330, H730P, H740P, H750, H350
External H840, HBA355e
PCIe 2x PCIe 3.0 Up to 2x PCIe Gen3 x16
Networking 4x 1GbE LOM 2x 1GbE LOM + optional riser (2x 1GbE or 2x 10GbE)
Management iDRAC8 with Lifecycle Controller iDRAC9
Power 450W or 550W 450W Bronze cabled or 550W Platinum hot-plug
Form Factor 1U Rack 1U Rack

Frequently Asked Questions

Up to two Intel Xeon E5-2600 v3 or v4 processors, with core options from 4 up to 20 per socket, on the Intel C610 chipset.

There are 12 DDR4 DIMM sockets that take 4GB to 32GB RDIMMs, for up to 384GB with both processors installed, at up to 2400 MT/s.

Dell offers chassis with ten or eight 2.5-inch hot-plug bays, or four 3.5-inch hot-plug bays, for SAS, SATA, nearline SAS or SSD drives with PERC S130, H330, H730 or H730P. Please specify your capacity needs when you submit your quote configuration.

Both are 1U dual-socket E5-2600 v3/v4 servers, but the R430 is a shorter, value design with 12 DIMM slots, two PCIe slots and fixed 4x 1GbE. The R630 offers 24 DIMM slots, up to three PCIe slots, a network daughter card and hot-swap fans.

The Gen 14 R440 moves to Xeon Scalable processors, adds four more DIMM slots for up to 1TB at 2666 MT/s, supports up to four NVMe drives and uses iDRAC9. Networking changes from four fixed 1GbE ports to two plus an optional 10GbE riser. Dell's R440 spec sheet was used for the R440 column.
