Dell PowerEdge XE7740

The Dell PowerEdge XE7740 is a 4U, air-cooled, dual-socket Intel server built around standard PCIe accelerators for generative AI fine-tuning and inferencing, natural language processing and digital twins. Two Intel Xeon 6 processors with up to 86 cores each drive up to 4TB of DDR5 at up to 6400 MT/s. It holds up to eight double-wide 600W GPUs, such as the NVIDIA H200 NVL, L40S or Intel Gaudi 3, or up to sixteen single-wide NVIDIA L4 cards. Fully configurable.

Looking to compare? See its AMD twin, the Dell PowerEdge XE7745, or the Intel 8-GPU Dell PowerEdge XE9780.

Thanks for the request. We'll get back to you with in 24 hours.

  • Form Factor: 4U Rack
  • Processors: Up to 2x Intel Xeon 6 (up to 86 cores)
  • Memory: 32x DDR5 RDIMM slots, up to 4TB
  • Memory Speed: Up to 6400 MT/s
  • Storage: Up to 8x E3.S Gen5 NVMe SSDs
  • Expansion: 8x PCIe Gen5 x16 slots, plus GPU slots
  • GPU Support: Up to 8x DW 600W or 16x SW 75W PCIe Gen5 GPUs
  • Networking: 1x OCP 3.0 (optional), dedicated iDRAC port
  • Management: iDRAC10
  • Cooling: Air, hot-swap mid-tray and front fans
  • Power: Up to 8x Titanium 3200W or 2400W PSUs

Thanks for the request. We'll get back to you with in 24 hours.

Configure this  XE7740 →

Customize & Get Pricing

Configure your Dell PowerEdge XE7740 with the exact specs you need

Configure This Server

Dell PowerEdge XE7740 vs XE7745: Specs & Key Differences

Feature PowerEdge XE7740 PowerEdge XE7745
Processors Up to 2x Intel Xeon 6 (up to 86 cores) Up to 2x 5th Gen AMD EPYC 9005 (up to 192 cores)
Memory 32x DDR5 RDIMM slots, up to 4TB 24x DDR5 RDIMM slots, up to 3TB
Memory Speed Up to 6400 MT/s (5200 MT/s at 2DPC) Up to 6400 MT/s
Storage Up to 8x E3.S Gen5 NVMe SSDs Up to 8x E3.S Gen5 NVMe SSDs
PCIe 8x PCIe Gen5 x16 (NIC) plus GPU slots 8x PCIe Gen5 x16 (NIC) plus GPU slots
GPU Support 8x DW 600W or 16x SW 75W PCIe Gen5 GPUs 8x DW 600W or 16x SW 75W PCIe Gen5 GPUs
Networking 1x OCP 3.0 (optional), dedicated iDRAC port 1x OCP 3.0 (optional), dedicated iDRAC port
Management iDRAC10 iDRAC10
Cooling Air Air
Power Up to 8x Titanium 3200W or 2400W (CPU + GPU zones) Up to 8x Titanium 3200W or 2400W (CPU + GPU zones)
Form Factor 4U Rack 4U Rack

Frequently Asked Questions

Up to eight double-wide PCIe Gen5 accelerators at up to 600W each, or up to sixteen single-wide 75W cards. Dell lists the NVIDIA H200 NVL, H100 NVL, RTX Pro 6000 and L40S and the Intel Gaudi 3 as double-wide options, and the NVIDIA L4 as the single-wide option. H100 NVL pairs link with 2-way NVLink bridges and H200 NVL groups of four with 4-way bridges. Higher GPU counts need more system memory, which we match in your quote.

Two Intel Xeon 6 processors, with Dell listing the 6787P (86 cores), 6767P (64 cores) and 6747P (48 cores) at up to 350W. Each CPU has eight DDR5 channels with two DIMMs per channel, for 32 RDIMM slots. Memory runs at up to 6400 MT/s with one DIMM per channel and 5200 MT/s with two, and 32GB to 128GB RDIMMs take it up to 4TB.

The front holds up to eight EDSFF E3.S Gen5 NVMe SSDs, up to 122.88TB raw, plus a BOSS-N1 module with two M.2 NVMe SSDs in hardware RAID 1 for the OS. There is no RAID controller for the data drives. Besides the GPU slots, eight PCIe Gen5 x16 full-height half-length slots take network cards for back-end cluster fabrics, and one OCP 3.0 slot (x8) takes the host NIC. Please specify your capacity needs when you submit your quote configuration.

It is fully air cooled, with up to four dual-fan modules in the mid tray and up to twelve fans across the front, all hot-swap. Up to eight Titanium power supplies, 3200W or 2400W, are split into a CPU zone with two PSUs and a GPU zone with six. Full redundancy uses 1+1 in the CPU zone and 3+3 in the GPU zone, and 277V AC / 336V DC 3200W units are also offered.

They share the same 4U air-cooled layout: up to eight double-wide or sixteen single-wide PCIe GPUs, eight extra PCIe Gen5 x16 slots, up to eight E3.S NVMe drives, CPU and GPU power zones and iDRAC10. The XE7740 runs Intel Xeon 6 with up to 86 cores and 32 DIMM slots for up to 4TB, and Dell lists Intel Gaudi 3 for it. The XE7745 runs 5th Gen AMD EPYC 9005 with up to 192 cores and 24 DIMM slots for up to 3TB, and adds AMD MI350P options.
