Dell PowerEdge R620

The Dell PowerEdge R620 is a dense 1U two-socket rack server built for virtualization and compute clusters where rack space is tight. It runs up to two Intel Xeon E5-2600 or E5-2600 v2 processors with up to 12 cores each, 24 DDR3 DIMM slots for up to 768GB at 1866 MT/s, and up to ten 2.5" drives, with optional front-access Express Flash PCIe SSDs. Up to three PCIe 3.0 slots, a choice of network daughter cards, hot-plug fans and redundant PSUs keep it flexible. Fully configurable.

Looking to compare generations? See its Gen 13 successor, the Dell PowerEdge R630, or compare Gen 12 models: Dell PowerEdge R720 and Dell PowerEdge R420.

Thanks for the request. We'll get back to you with in 24 hours.

  • Form Factor: 1U Rack
  • Processors: Up to 2x Intel Xeon E5-2600/E5-2600 v2
  • Memory: 24x DDR3 DIMM slots, up to 768GB
  • Memory Speed: Up to 1866 MT/s
  • Storage: Up to 10x 2.5" hot-plug, or 4x 2.5" + 2x Express Flash
  • Expansion: Up to 3x PCIe 3.0 slots
  • GPU Support: 1x single-width, up to 75W
  • Networking: NDC: 4x 1GbE, or 2x 10GbE + 2x 1GbE
  • Management: iDRAC7 with Lifecycle Controller
  • Cooling: Air, hot-plug redundant fans
  • Power: Redundant PSUs, 495W to 1100W

Thanks for the request. We'll get back to you with in 24 hours.

Configure this  R620 →

Customize & Get Pricing

Configure your Dell PowerEdge R620 with the exact specs you need

Configure This Server

Dell PowerEdge R620 vs R630: Specs & Key Differences

Feature PowerEdge R620 PowerEdge R630
Processors Up to 2x Intel Xeon E5-2600/E5-2600 v2 (up to 12 cores) Up to 2x Intel Xeon E5-2600 v3/v4 (up to 22 cores)
Memory 24x DDR3 DIMM slots, up to 768GB
Up to 1866 MT/s		 24x DDR4 DIMM slots, up to 1.5TB
Up to 2400 MT/s
Storage Up to 10x 2.5" or 4x 2.5" + 2x Express Flash Up to 10x 2.5" or 24x 1.8" SSD
PCIe Up to 3x PCIe 3.0 Up to 3x PCIe 3.0
GPU Support 1x single-width, up to 75W 1x 75W single-width
Networking NDC: 4x 1GbE, or 2x 10GbE + 2x 1GbE NDC: 4x 1GbE, 2x 1GbE + 2x 10GbE or 4x 10GbE
Management iDRAC7 with Lifecycle Controller iDRAC8 with Lifecycle Controller
Cooling Hot-plug redundant fans 7 hot-swap fans
Power 495W to 1100W 495W to 1100W
Form Factor 1U Rack 1U Rack

Frequently Asked Questions

Up to two Intel Xeon E5-2600 or E5-2600 v2 processors, with 4 to 12 cores per socket, connected by two QPI links on the Intel C602 chipset.

Its 24 DDR3 DIMM sockets support up to 768GB, with speeds up to 1866 MT/s when E5-2600 v2 processors are installed.

Chassis choices include four, eight or ten 2.5-inch hot-plug bays for SAS, SATA or SSD drives, or four 2.5-inch bays plus two front-access Express Flash PCIe SSDs. RAID options include PERC S110, H310, H710 and H710P. Please specify your capacity needs when you submit your quote configuration.

Yes, one single-width card up to about 75W in the full-height slot. A GPU rules out the 10GbE network daughter card and mini PERC, so an adapter-style PERC is used instead.

The Gen 13 R630 moves to Xeon E5-2600 v3/v4 processors with up to 22 cores, doubles memory to 1.5TB of DDR4-2400, adds a 24x 1.8-inch SSD option and uses iDRAC8. Both are 1U dual-socket servers with 24 DIMM slots, up to three PCIe slots and 495W to 1100W power.
