Dell PowerEdge T640 Tower Server Chassis (16x2.5")

SKU: DPE-T640-16x2.5-Chassis

Dell PowerEdge T640 Tower Server Chassis (16x2.5")

Name: Dell PowerEdge T640 Tower Server Chassis (16x2.5")
Brand: Dell
SKU: DPE-T640-16x2.5-Chassis
Price: 1955.0 USD
Availability: InStock

Dell

| Chassis

.price-ui--loading { display: block !important; opacity: 1 !important; }

$1,955.00

Thanks for the request. We'll get back to you with in 24 hours.

Quick Specs

Form Factor:

Tower server 5U (Rack conversion kit)

Processor Max: 28 Cores (PP)

2x Gen 2 Intel Scalable Processors

Memory Max: 3TB

24 DDR4 RDIMM/LRDIMM 2933Mhz

Up to 12 NVDIMM Max : 192GB

Storage Max: 228TB

16x 2.5” SAS/SATA (HDD/SSD) Max : 61TB

32x 2.5” SAS/SATA (HDD/SSD) Max : 122TB

16x 2.5” with up to 8 NVMe, SAS/SATA /NVMe (HDD/SSD) Max : 112TB

Boot Options

Boot Optimized Server Storage (BOSS)
IDSDM
Internal USB

RAID Controller:

S140 (SW RAID)
PERC H330, H730P, H740P, H840, HBA330, 12Gbps SAS HBA (non-RAID)

NIC/LOM

2 x 10GbE LOM (1GbE/10GbE)

Remote Management:

iDRAC9

PCIe Slots:

Up to 8 PCIe Gen3 slots

GPU:

(Rack Mode Only) 4x 300W (DW) passive or 8x 150W (SW)

Other Versions

Ideal for:

Virtual Desktop Interface (VDI)
Virtualization

Looking to Customize?

Need assistance with customization? Our sales experts are here to help you.

Start Customizing Today!

Base Standard Capabilities

Feature	PowerEdge T640 Technical specification
Processor	Up to two 2nd Generation Intel® Xeon ® Scalable processors, up to 28 cores per processor
Memory	24 DDR4 DIMM slots, Supports RDIMMS/ LRDIMMS, speeds up to 2993MT/s, 3TB max Up to 12 NVDIMM, 192GB max Supports registered ECC DDR4 DIMMs only
Storage controllers	Internal controllers: PERC H330, H730P, H740P, HBA330, Software RAID (SWRAID) S140 External PERC (RAID): H840 External HBAs (non-RAID): 12Gbps SAS HBA Boot Optimized Storage Subsystem (BOSS): HWRAID 2 x M.2 SSDs 120GB, 240 GB
Drive bays	Up to 8 x 3.5” SAS/SATA (HDD/SSD) max 288TB Up to 18 x 3.5” SAS/SATA (HDD/SSD) max 288TB Up to 16 x 2.5” SAS/SATA (HDD/SSD) max 61TB Up to 16 x 2.5” + Up to 8 NVMe, SAS/SATA /NVMe (HDD/SSD) max 112TB Up to 16 x 2.5” SAS/SATA (HDD/SSD) + Up to 16 x 2.5” SAS/SATA (HDD/SSD) max 61TB (Dual PERC) Up to 16 x 2.5” SAS/SATA (HDD/SSD) + Up to 16 x 2.5” SAS/SATA (HDD/SSD) max 61TB (Single PERC)
Power supplies	Titanium 750W Platinum 495W, 750W, 1100W, 1600W, 2000W and 2400W 48VDC 1100W, 240HVDC 750W Hot plug power supplies with full redundancy Up to 8 fans with N+1 redundancy (6 hot-pluggable internal fans plus 2 external fans)
Dimensions and weight	Form factor: Tower or rack, 5U	Chassis max depth: 708.7 mm
Bezel	Optional security bezel
Embedded / At-Server	iDRAC9 iDRAC Direct Quick Sync 2 BLE/wireless module
Consoles & Mobile	OpenManage Enterprise OpenManage Mobile OpenManage Power Manager
Integrations and connections	Integrations: Microsoft® System Center VMware® vCenter™ BMC Software	Connections: Nagios Core & Nagios XI HP Operations Manager i (OMi)
Tools	iDRAC Service Module iDRAC RESTful API with Redfish OpenManage Server Administrator OpenManage Storage Services	Dell EMC Repository Manager Dell EMC Update Package Dell EMC System Update Dell EMC Server Update Utility
Security	TPM 1.2/2.0 optional Cryptographically signed firmware Silicon Root of Trust	Secure Boot System Lockdown (requires iDRAC Enterprise or Datacenter) Secure Erase
I/O & Ports	2 x 10GbE LOM (1GbE/10GbE) 8 x USB (1 x USB 2.0, 1 x USB 3.0, 6 x USB 2.0/3.0) dedicated IDRAC Direct Micro-USB Video card: VGA Up to 8 PCIe Gen3 slots
GPU options	GPU options: 4 x DW or 8 x SW Nvidia Tesla P100, K80M, M60, M10, P40 AMD S7150, S7150X22
Supported Operating systems	Canonical® Ubuntu® LTS Citrix® Hypervisor Microsoft Windows Server® LTSC with Hyper-V Red Hat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi®

Spec Sheet 4

Feature	PowerEdge T640	PowerEdge T630
Processor	2x 2nd Generation Intel® Xeon® processor Scalable Family	2x Intel Xeon E5-2600 v3 (Haswell-EP), Broadwell
Memory Module	• 24 DDR4 DIMM slots • Supports RDIMMs/LRDIMMs • Speeds up to 2933MT/s, 3TB max • Up to 12 NVDIMM, 192GB max	• Up to 24 DDR4 DIMM slots • 1.5TB max memory • Speeds up to 2400MT/s
Chipset	Intel Ultra Path Interconnect (UPI)	Intel QuickPath Interconnect (QPI)
Hard drive bays	8x3.5 -inch, 18x3.5 -inch, 16x2.5 -inch, 16x2.5 -inch + 8x NVMe, 32x2.5 -inch - 12Gb SAS, 6Gb SATA	8x3.5 -inch, 18x3.5 -inch, 16x2.5 -inch, 32x2.5 - inch - 12Gb SAS, 6Gb SATA
Storage Controllers	Adapters: HBA330, H330, H730P, H740P, H840, 12Gb SAS HBA Mini Mono: HBA330, H330, H730P, H740P SW RAID: S140	Adapters: HBA330, H330, H730, H730P, H830 (ext) Mini Mono: HBA330, H330, H730, H730P SW RAID: S130
PCIe SSD	Up to 8x PCIe SSD (NVMe)	4x PCIe SSD
PCIe Slots	Max 8 PCIe 3.0 + 1 internal	Max 7 PCIe Gen3 + 1 internal
LOM	2x 10GbE (10GBASE-T) Broadcom 57416	2x 1GbE
USB Ports	Front: 1 port (USB 3.0), 1 port (USB 2.0), dedicated iDRAC, serial, video, 6x USB2.0/3.0	Front: 1 port (USB 3.0), 1 port USB2.0, dedicated iDRAC, serial, video,4x USB 2.0
Tower/Rack	5U (rack)	5U (rack)
Power Supplies	• 2400W Platinum (AC only) • 2000 Platinum (AC only) • 1600W Platinum (AC only) • 1100W Platinum (AC/DC) • 750W Platinum/Titanium (AC only) • 750W Platinum Mixed Mode DC (For china only) • 495W Platinum (AC only)	AC: 495W, 750W, 1100W DC: 1100W Mixed Mode: 750W 1100W DC, 1600W
Remote Management	iDRAC9	iDRAC8
Internal GPU	4x 300W (DW) Passive or 8x 150W (SW)	4x 300W (DW) Active or 7x 150w (SW)
Availability	• Hot-plug Drives • Hot-plug Redundant Cooling • Hot-plug Redundant Power Supplies • BOSS • IDSDM	• Hot-plug Drives • Hot-plug redundant Cooling • Hot-plug Redundant Power Supplies • IDSDM Support
