Specs
Quick Specs
Form Factor:
Tower server
Processor | Max: N/A1x Intel E-2200, Core i3, or Celeron
Memory | Max: 64GB4 DDR4 UDIMM 2666Mhz
Storage | Max: N/A8 LFF Hot-Swap Drives
(also supports 2.5” HDD in 3.5” hybrid drive carrier)
Boot Optimized Server Storage (BOSS)
IDSDM
USB
S140 (SW RAID)
PERC H730P, H330, HBA330 (non-RAID), 12Gbps SAS HBA (non-RAID)
2 x 1GbE LOM
Remote Management:iDRAC9
PCIe Slots: 41x8 Gen3 (x16 connector) FH/HL
1x8 Gen3 (x8 connector) FH/HL
1x4 Gen3 (x8 connector) FH/HL
1x1 Gen3 (x1 connector) FH/HL
Not Supported
Ideal for:
Develop your business with the PowerEdge T340 tower server. It is a reliable, easy to manage, and scalable one-socket server. The PowerEdge T340 helps you share and connect quickly across your organization to drive business results.
Operate reliably and scale without limits
The PowerEdge T340 is your reliable server that allows you to collaborate and grow as you scale.
- Drive your business forward with improved performance due to 100% more cores with Intel Xeon E-2200 processors, 11% increase in memory speed, and 20% more PCIe lanes.
- Scale with 17% more storage capacity.
- Operate reliably with up to 8 hot-plug HDD’s or SSD’s and redundant power supplies.
- Get set up as much as 66% faster with our ProDeploy suite of services.
Intuitive systems management with intelligent automation
PowerEdge servers with embedded iDRAC with Lifecycle Controller offer agent-free management right out of the box, delivering smart automation of routine tasks. The T340 is easily managed which frees up time for work priorities.
- Simplify management with the New OpenManage Enterprise console, with customized reporting and automatic discovery.
- Easily manage multiple remote servers via the intuitive general user interface with iDRAC9 Group Manager or upgrade to OpenManage Enterprise.
- Conveniently receive data alert notifications and access hardware remotely anywhere with OpenManage Mobile.
- Resolve issues with up to 72% less IT effort using automated proactive and predictive technology from ProSupport Plus and SupportAssist.
Connect and manage your growing business
The Dell EMC PowerEdge T340 enables you to grow through collaboration. Grow without limits* with this reliable and easy to manage server.
The T340 enables you to address common business workloads in your office and across remote offices.
Operate reliably
The Dell EMC PowerEdge T340 operates reliably so you don’t have to slow down when connecting and managing your growing business.
- Operate reliably with up to 8 hot-plug HDD’s or SSD’s and redundant power supplies.
- Save time and IT effort resolving server hardware issues with ProSupport Plus and SupportAssist.
- Help prevent downtime and protect your data from malicious changes with iDRAC9 Enterprise Server Lockdown mode.
- Save your data automatically with reliable software RAID.
Looking to Customize?
Need assistance with customization? Our sales experts are here to help you.
Start Customizing Today!
Base Standard Capabilities
| Feature | PowerEdge T340 Technical specification | |
|---|---|---|
| Processor | 1 processor from the following: Intel® Xeon® E-2200 product family, Intel Pentium®, Intel Core i3®, Intel Celeron® | |
| Memory | 4x DDR4 DIMM slots, supports UDIMMs, speeds up to 2666MT/s, 64GB max. supports registered ECC. | |
| Storage controllers | Internal controllers: PERC H730P, H330, HBA330 (non-RAID) Software RAID: PERC S140 External HBAs: 12Gbps SAS HBA (non-RAID) Boot Optimized Storage Subsystem (BOSS): 2x M.2 240GB (RAID 1 or No RAID), 1x M.2 240GB (No RAID only) Internal Dual SD Module | |
| Drive bays | Up to 8 x 3.5” hot-pluggable bays (also supports 2.5” HDD in 3.5” hybrid drive carrier) | |
| Power supplies | 2x Hot-Plug-Redundant 495W PSUs or Single Cabled 350W PSU | |
| Dimensions and weight | Form factor: Tower server | Chassis height: 430.3mm (16.94 in) Chassis width: 218mm (8.58 in) Chassis depth: 603 mm (23.7 in) Note: These metrics do not include PSU handle, bezel, or tower foot Chassis weight: 26 kg (55.67 lb.) |
| Embedded management | iDRAC9 iDRAC Direct | |
| Bezel | Optional security bezel | |
| OpenManage™ Software |
| |
| Integrations and connections | Integrations:
| Connections:
|
| Tools |
|
|
| Security |
|
|
| I/O & Ports |
| 4 x PCIe Slots:
|
| Supported Operating systems | Certify XenServer Citrix® XenServer® Microsoft Windows Server with Hyper-V Red Hat® Enterprise Linux Ubuntu Server | SUSE® Linux Enterprise Server VMware® ESXi |
Spec Sheet 4
| Feature | PowerEdge T340 | PowerEdge T330 |
|---|---|---|
| Processor | ● Intel® Xeon® E-2100 and E-2200 Processor
family
● Intel® Pentium® ● Intel® Celeron® ● Intel® Core™ i3® |
● Intel® Xeon® E3-1200 v6 Processor family
● Intel® Pentium® ● Intel® Celeron® ● Intel® Core™ i3® |
| Front Side Bus | DMI 3.0 | DMI 3.0 |
| Number of processors | 1 | 1 |
| Number or cores | Up to 8 cores | Up to 4 cores |
| L2/L3 cache | ● 2.0 MB per core
● 8 MB or 12 MB |
● 2.0 MB per core
● 4 MB or 8 MB |
| Chipset | Intel® C246 | Intel® C236 |
| Memory Module | ● DDR4: 4 UDIMMs with ECC
● Speed: Up to 2666MT/s ● Min RAM: 8GB ● Max RAM: 64 GB |
● DDR4: 4 UDIMMs with ECC
● Speed: Up to 2400MT/s ● Min RAM: 4 GB ● Max RAM: 64 GB |
| Hard drive bays | ● 8 x 3.5-inch hot plug
● 8 x 2.5-inch hot plug (in 3.5-inch carrier) |
● 8 x 3.5-inch hot plug
● 8 x 2.5-inch hot plug (in 3.5-inch carrier) |
| Hard drive types | ● 2.5-inch SATA 7.2K HDDs
● 2.5-inch Near Line SAS 7.2K HDDs ● 2.5-inch SAS 10K HDDs ● 2.5-inch SAS 15K HDDs ● 3.5-inch Enterprise SATA 7.2K HDDs ● 3.5-inch Near Line SAS 7.2K HDDs ● 2.5-inch SATA SSDs |
● 2.5-inch SATA 7.2K HDDs
● 2.5-inch Near Line SAS 7.2K HDDs ● 2.5-inch SAS 10K HDDs ● 2.5-inch SAS 15K HDDs ● 3.5-inch Enterprise SATA 7.2K HDDs ● 3.5-inch Near Line SAS 7.2K HDDs ● 2.5-inch SATA SSDs |
| External hard drive bays | 3 x 5.25-inch bay | 3 x 5.25-inch bay |
| RAID controllers | ● Chipset based SATA, PERC S140 ● Non RAID controller: 12GB SAS HBA, PERC HBA330 ● PERC H330 ● PERC H730P |
● Chipset based SATA, PERC S130
● Non RAID controller: 12GB SAS HBA ● PERC H330 ● PERC H730 ● PERC H830 |
| Boot optimized storage subsytem | ● 2x M.2 240GB (RAID 1 or No RAID)
● 1x M.2 240GB (No RAID only) |
Not supported |
| Server management | ● Dell Open Manage featuring Dell Management
Console
● Lifecycle Controller 3.0 ● iDRAC9 Enterprise |
● Dell Open Manage featuring Dell
Management Console
● Lifecycle Controller 3.0 ● iDRAC8 Enterprise |
| I/O slots | ● 1 x 8 PCIe Gen3 (x16 connector) FH/HL
● 1 x 8 PCIe Gen3 (x8 connector) FH/HL ● 1 x 4 PCIe Gen3 (x8 connector) FH/HL ● 1 x 1 PCIe Gen3 (x1 connector) FH/HL |
● 1 x 8 PCIe Gen3 (x16 connector) FH/HL
● 1 x 4 PCIe Gen3 (x8 connector) FH/HL ● 1 x 4 PCIe Gen3 (x8 connector) FH/HL ● 1 x 1 PCIe Gen3 (x1 connector) FH/HL |
| NIC/LOM | 2 x 1GbE LOM | 2 x 1GbE LOM |
| Power supplies | Single or Dual Redundant 495W power supply or single 350W cabled power supply | Single or Dual Redundant 495W power supply or single 350W cabled power supply |
| Fans | No Fan fault tolerance | No Fan fault tolerance |
| SD module | IDSDM | IDSDM |
| Dimensions (HxWxD) | ● Height 16.94 inch / 43.0 cm
● Width 8.58 inch / 21.8 cm ● Height 23.8 inch / 60.5 cm |
● Height 16.94 inch / 43.0 cm
● Width 8.58 inch / 21.8 cm ● Height 23.7 inch / 60.3 cm |
| Weight | Max 26 Kg | Max 26 Kg |
