NetApp FAS8300 Dual Controller FC Bundle Filer Head (HA)
Thanks for the request. We'll get back to you with in 24 hours.
Condition: Refurbished ✓ Pulled from working servers & Tested. ✓ 1-year Parts Warranty.
Warranty | Return Policy
-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.
The NetApp FAS8300 is a powerful enterprise storage system designed for high availability and scalability. Featuring a single-chassis design with dual controllers in an HA (high availability) configuration, it delivers 256GB of memory and four 64-bit, 10-core processors running at 2.20 GHz. With a total rack height of 4U, this system supports up to 720 drives and a maximum storage capacity of 15PB, making it an ideal choice for demanding workloads and large-scale data storage.
For connectivity, the FAS8300 includes eight 10Gb SFP+ fiber ports for high-speed networking, eight MiniSAS HD ports (12Gb) for storage expansion, and ten PCIe slots for additional functionality. It also features four M.2 PCIe slots, typically used for system caching and boot functions. The system is compatible with DS212C, DS224C, and DS460C disk shelves, providing flexible storage expansion options to accommodate evolving enterprise needs.
The chassis measures 6.89 inches in height, 17.6 inches in width, and 34.72 inches in depth, with a maximum weight of 108.5 lbs. Supporting RAID 4, RAID 6 (RAID-DP), and RAID-TEC, the FAS8300 ensures robust data protection and reliability. With remote management capabilities and high-speed networking options, it is well-equipped to handle mission-critical applications and enterprise workloads that require continuous availability and performance.
- Model: NetApp FAS8300
- Chassis: Single Chassis
- Total Rack Height: 4U
- Controllers: Dual Controller (HA)
- Memory: 256GB
- Processor Model: 4x 64-bit 10-core 2.20 Ghz
- Fiber Ports: 8 x SFP+ (16Gb)
- SAS Ports: 8 x MiniSAS HD (12Gb)
- PCIe Expansion Slots: 4 x M.2 PCIe + 10 x PCIe
- Max Drives (total): 720
- Max Capacity: 15,000TB (15PB)
- Disk Shelves: DS212C, DS224C, DS460C
- Filer Heads: N/A
- Chassis Rack Height: 4U
- Chassis Heights: 6.89" (17.5 cm)
- Chassis Width w/o Mounting Flanges: 17.6" (44.7 cm)
- Chassis Depth w/ Cable Mgmt: 34.72" (88.2 cm)
- Chassis Weight: up to 108.5 lb (49.2 kg)
Controller Specs
- Max Controllers: 2 (Per Chassis)
- PCI Slot (per): 4 x M.2 PCIe + 10 x PCIe
- Ethernet Ports (per): N/A
- Fibre Channel Ports (per): 4 x SFP+ (16Gb)
- UTA2 Ports (per): N/A
- SAS Ports (per): 4 x MiniSAS HD (12Gb)
- Remote Management: Yes
- Processor Model (per): 2x 64-bit 10-core 2.20 Ghz
- Memory (Single/HA): 128GB/256GB
- NVRAM (Single/HA): 16GB/32GB
- Max Number of Internal Drives: 0
- Max Number Drives (total): 720
- Max Capacity: 15,000TB (15PB)
- Max # of MSATA Drives: 720
- Max # of SATA Drives: 720
- Max # of NL-SAS Drives: 720
- Max # of SAS Drives: 720
- Max # of SSD Drives: 480
- Drive Interface: MSATA, SATA, NL-SAS, SAS, SSD
- RAID: RAID 4, RAID 6 (RAID-DP), RAID-TEC
- Max # of DS212C Shelves: 60 external
- Max # of DS224C Shelves: 30 external
- Max # of DS460C Shelves: 12 external
