Home / Dell Server Hardware Components / Dell PowerEdge R7425 Rack Server Chassis (24x2.5")
SKU: DPE-R7425-24x2.5-Chassis

Dell PowerEdge R7425 Rack Server Chassis (24x2.5")

Dell

| Chassis
Contact For Pricing

Thanks for the request. We'll get back to you with in 24 hours.

Quick Specs

Form Factor:

2U rack server

Processor | Max: 32 Cores

2x AMD Gen 1 EPYC

Memory | Max: 128GB

32 ECC DDR4 RDIMM/LRDIMM 2666Mhz

Storage | Max: N/A

Front bays: 24 SFF SAS/NL-SAS/SATA (HDD/SSD) NVMe
Mid Bay: 4 LFF/SFF SAS/SATA (HDD)
Rear bay: 4 SFF SAS/SATA (HDD/SSD)

Boot Options

Boot Optimized Server Storage (BOSS-S1)
Internal Dual SD module (IDSDM)
Internal USB

RAID Controller:

H330, H730P, H740P, H840, HBA330, 12Gbps SAS HBA

NIC/LOM

4 x 1GE or 2 x 10GE + 2 x 1GE or 4 x 10GE or 2 x 25GE

Remote Management:

iDRAC9 Express (default) with Lifecycle Controller

PCIe Slots:

Up to 8 PCIe 3.0 slots (6x 16 + 2x 8)

GPU: 3 DW
Other Versions

Ideal for:

  • Big Data Analytics
  • Data Analytics
  • High-Performance Computing (HPC)
Looking to Customize?

Need assistance with customization? Our sales experts are here to help you.

Start Customizing Today!

Base Standard Capabilities

FeaturesTechnical specification
ProcessorUp to 2x AMD EPYC™ processors, up to 32 cores per processor
Memory32 DDR4 DIMM slots, Supports RDIMM, LRDIMM
Storage controllersInternal Controllers: PERC H330, H730p, H740p, HBA330
External PERC (RAID): H840 12Gbps PERC9 or 10 series, PCIe PERC x8 slot
Boot Optimized Storage System: HW RAID 2 x M.2 + Internal USB + Internal Dual SD Module
Drive baysFront bays:
  • Up to 24 x 2.5” SATA/SAS/NVMe
  • Or up to 12x 3.5” SAS/SATA HDD
Mid bays:
  • Up to 4 x 2.5” NVMe
  • Or up to 4 x 3.5” SAS/SATA HDD
Rear bays:
  • Up to 4 x 2.5”
  • Or 2 x 3.5” SAS/SATA HDD
Power suppliesTitanium 750W, Platinum 495W, 750W, 1600W, 1100W, and 2000W
48VDC 1100W, 380HVDC 1100W, 240HVDC 750W
Hot plug power supplies with full redundancy
DimensionsForm factor: Rack (2U)
Chassis max depth: 715.5 mm
Embedded / At-ServeriDRAC9 with Lifecycle Controller (no power capping)
iDRAC Direct
iDRAC REST API with Redfish support
Quick Sync 2 BLE/wireless module
BezelOptional LCD bezel or security bezel
OpenManage SoftwareOpenManage Enterprise
OpenManage Mobile
OpenManage Essentials
Integrations and connectionsIntegrations:
Microsoft System Center
VMware vCenter
BMC Software (available from BMC)		Connections:
HPE Operations Manager i (OMi)
Nagios® Core
Nagios® XI
ToolsDell EMC Repository Manager
Dell EMC Update Package
Dell EMC System Update
Dell EMC Server Update Utility		iDRAC Service Module
OpenManage Server Administrator
OpenManage Storage Services
SecurityTPM 1.2/2.0 optional
Cryptographically signed firmware
Secure Root of Trust
Secure Boot
Secure Erase
System Lockdown
I/O & PortsNetwork daughter card options:
  • 4 x 1GbE
  • 2 x 10GbE + 2 x 1GbE
  • 4 x 10GbE
  • 2 x 25Gb
Front Ports:
  • 2 x USB 2.0
  • 1 x VGA
  • 1 x Dedicated iDRAC Direct Micro-USB
Rear Ports:
  • 1 x Dedicated iDRAC network port
  • 1 x Serial
  • 2 x USB 3.0
  • 1 x VGA
Video Card:
  • VGA
PCIe:
  • Up to 8 x Gen3 slots; up to 6 x 16 lanes
Supported operating systemsMicrosoft Windows Server® 2016
Red Hat® Enterprise Linux 7.4
VMware® vSphere 2016 U1 (ESXi 6.5 U1)
Microsoft Windows Server® 2012 R2
