Specs
CTO Item
This part is strictly for configuring Dell servers. If you have landed on this page and you're looking for a specific part number. Please send us a "Request a Quote" with the part number you need.
Base Standard Capabilities
| Features | Technical specification | |
|---|---|---|
| Processor | 1x AMD™ EPYC processor, up to 32 cores | |
| Memory | 16 DDR4 DIMMs, RDIMM, LRDIMM | |
| Storage controllers | Internal Controllers: PERC H330, H730p, H740p, HBA330 External PERC (RAID): H840 12Gbps PERC9 or 10 series, mini PERC x8 slot Boot Optimized Storage System: HW RAID 2 x M.2 + Internal USB + Internal Dual SD Module | |
| Drive bays | Front bays:
| |
| Power supplies | Titanium 750W, Platinum 495W, 750W, 1600W Hot plug power supplies with full redundancy | |
| Dimensions | Form factor: Rack (2U) Chassis max depth: 707.74 mm (without bezel) Max depth: 693.81 mm (with bezel) | |
| Embedded / At-Server | iDRAC9 with Lifecycle Controller (no power capping) iDRAC Direct iDRAC REST API with Redfish support Quick Sync 2 BLE/wireless module | |
| Bezel | Optional LCD bezel or security bezel | |
| OpenManage Software | OpenManage Enterprise OpenManage Mobile OpenManage Essentials | |
| Integrations and connections | Integrations: Microsoft System Center VMware vCenter BMC Software (available from BMC) | Connections: HPE Operations Manager i (OMi) Nagios® Core Nagios® XI |
| Tools | Dell EMC Repository Manager Dell EMC Update Package Dell EMC System Update Dell EMC Server Update Utility | iDRAC Service Module OpenManage Server Administrator OpenManage Storage Services |
| Security | TPM 1.2/2.0 optional Cryptographically signed firmware Secure Root of Trust Secure Boot Secure Erase System Lockdown | |
| I/O & Ports | Network daughter card options:
| Rear Ports:
|
| Supported operating systems | Microsoft Windows Server® 2016 Red Hat® Enterprise Linux 7.4 VMware® vSphere 2016 U1 (ESXi 6.5 U1) Microsoft Windows Server® 2012 R2 | |
