Specs
Quick Specs
Full Height Blade Server
Processor | Max: 6 Cores2 x Intel Xeon 5500 or 5600
Memory | Max: 288GB18 DDR3 RDIMM 1333Mhz
Storage | Max: 3.6TB4 SFF SAS/NL-SAS/SATA HDD/SSD
Networking LOM:4 Embedded Broadcom 5709S dual-port
PCIe Slots:4 Mezzanine Slots PCIe 2.0
GPU:None
Ideal for:
- Virtualization
This is one of the supported blade serves, each Modular Enclosure is a separate CTO you must configure.
The Dell PowerEdge M710 delivers the exceptional bandwidth and performance today’s data center environments require.
Dell M1000e Blade Architecture
- Dell PowerEdge M1000e CTO Blade Enclosure
- Dell PowerEdge M420 CTO Blade Server
- Dell PowerEdge M520 CTO Blade Server
- Dell PowerEdge M620 CTO Blade Server
- Dell PowerEdge M630 CTO Blade Server
- Dell PowerEdge M640 CTO Blade Server
- Dell PowerEdge M710 CTO Blade Server
- Dell PowerEdge M710HD CTO Blade Server
- Dell PowerEdge M820 CTO Blade Server
- Dell PowerEdge M830 CTO Blade Server
Strong IT foundation
To build the most efficient data center solutions, Dell sought input from IT professionals. You asked for reliability, scalability, energy efficiency, and a lower total cost of ownership (TCO). Our M710 blade servers deliver, becoming the cornerstone of a high-performance data center capable of keeping pace with your changing business demands.
Purposeful design
Today’s data centers demand performance, high availability and redundancy. Designed with those needs in mind, the M710 blade server uses the Intel Xeon processor 5500 and 5600 series. These processors adapt to your software in real time, processing more tasks simultaneously. Using Intel® Turbo Boost Technology, the M-Series blades can increase performance during peak usage periods. When demand decreases, Intel® Intelligent Power Technology helps reduce operating costs and energy usage by proactively putting your server into lower power states.
Dell’s innovative full-height M710 provides 18 DIMM slots and up to 288GB of total RAM, coupled with double the I/O capabilities of half-height blades and full-fabric redundancy on all three fabrics. The M710 blade server allows quick virtualization with software from leading industry vendors using an SD card or internal USB for embedded hypervisors.
Designed for Power Efficiency
The dynamic power management technology allows you to set high/low power thresholds to enable efficient energy management.
The Intel Xeon processor series is designed to adapt in real time to your software enabling multiple tasks to be done simultaneously, while boosting performance with Intel Turbo Boost Technology as business usage demands it most. It proactively puts your server into lower power states using Intel ® Intelligent Power Technology during periods of low demand, helping reduce operating costs.
Increased Memory Capacity and I/O for High-Performance Applications
Expanding to a full-height form factor enabled Dell to significantly increase the memory capacity of the M710 with 18 dual in-line memory module (DIMM) slots and up to 144 GB of total RAM.
New Double Data Rate 3 (DDR3) memory offers higher bandwidth and lower power consumption than previous Fully Buffered DIMM (FBD) or DDR2 RAM technologies. The numerous memory slots allow you to use smaller, less expensive DIMM to meet computing needs.
Looking to Customize?
Need assistance with customization? Our sales experts are here to help you.
Start Customizing Today!
Base Standard Capabilities
| Features | Technical Specifications | |
|---|---|---|
| Processors | Quad-core or six-core Intel Xeon processors 5500 and 5600 series | |
| Chipset | Intel 5520 | |
| Memory | Up to 192GB (18 DIMM slots): 1GB/2GB/4GB/8GB/16GB ECC DDR3 up to 1333MHz | |
| Drive Bays | Four 2.5 SAS/Solid State hot-swappable drives | |
| Storage | Hot-plug Hard Drive Options: 2.5 SAS SSD, SATA SSD, SAS (15K, 10K), nearline SAS (7.2K) Maximum Internal Storage: Up to 4TB per blade External Storage: For information about Dell external storage options, visit Dell.com/Storage. | |
| RAID Controller Options | Internal: PERC H200 Modular (6Gb/s) PERC H700 Modular (6Gb/s) with 512MB battery-backed cache; 512MB, 1GB Non-Volatile battery-backed cache SAS 6/iR Modular CERC 6/i Modular PERC 6/i Modular with 256MB battery-backed cache | |
| I/O Mezzanine Card Options | 1Gb & 10Gb Ethernet: Dual-Port Broadcom Gb Ethernet w/ TOE (BCM-5709S) Quad-Port Intel Gb Ethernet (BCM-82576) Quad-Port Broadcom Gb Ethernet (BCM-5709S) Dual-Port Broadcom 10Gb Ethernet (BCM-57711) Brocade BR1741M-k Dual-Port Mezzanine CNA 10Gb Enhanced Ethernet & Converged Network Adapters (CEE/DCB): Dual Port Intel 10GB Enhanced Ethernet Server Adapter X520-DA2 (FcoE Ready for Future Enablement) Dual-Port Qlogic Converged Network Adapter (QME8142) - Supports CEE/DCB 10GbE + FCoE | Fibre Channel: Dual-Port QLogic FC8 Fibre Channel Host Bus Adapter (HBA) (QME2572) Dual-Port Emulex FC8 Fibre Channel Host Bus Adapter (HBA) (LPe1205-M) Emulex 8 or 4 Gb/s Fibre Channel Pass-Through Module InfiniBand: Dual-Port Mellanox ConnectX Quad Data Rate (QDR) InfiniBand Dual-Port Mellanox ConnectX Dual Data Rate (DDR) InfiniBand |
| Operating Systems | Microsoft Windows Server 2008 SP2, x86/x64 (x64 includes Hyper-V ) Microsoft Windows Server 2008 R2, x64 (includes Hyper-V v2) Microsoft Windows HPC Server 2008 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux Oracle Solaris Virtualization Options: Citrix XenServer Microsoft Hyper-V through Microsoft Windows Server 2008 VMware vSphere 4.1 (including VMware ESX 4.1 or VMware ESXi 4.1) For more information on the specific versions and additions, visit www.dell.com/OSsupport. | |
| Featured Database Applications | Microsoft SQL Server solutions (see Dell.com/SQL) Oracle database solutions (see Dell.com/Oracle) | |
| Power Supply | Supplied by Dell PowerEdge M1000e Blade Chassis | |
| Video | Matrox G200 with 8MB of cache | |
| Systems Management | Dell OpenManage BMC, IPMI 2.0 compliant Unified Server Configurator Lifecycle Controller | iDRAC6 Enterprise with optional vFlash Remote Management: iDRAC6 Enterprise with optional vFlash Microsoft System Center Essential (SCE) 2010 v2 |
| Embedded Hypervisor | Optional Embedded SD Media | |
Spec Sheet 4
| Feature | PowerEdge M710 | PowerEdge M710HD | PowerEdge M610x | PowerEdge M610 |
|---|---|---|---|---|
| Description | General purpose Fullheight 2S | General purpose Full-height 2S | Special purpose Full-height 2S | General purpose Half-height 2S |
| Processor | Intel Xeon Processor 5500 or 5600 Series | |||
| Front Side Bus | Two Intel QuickPath Interconnect (QPI) | |||
| Sockets | Two | |||
| Cores | Up to six | |||
| L2/L3 Cache | 8MB (5500 Series) or 12MB (5600 Series) | |||
| Chipset | Intel 5520 | Intel 5520 | Intel 5500 | Intel 5500 |
| DIMMs | 18 x DDR3 DIMMs | 18 x DDR3 DIMMs | 12 x DDR3 DIMMs | 12 x DDR3 DIMMs |
| Min/Max RAM | 4GB/288GB | 4GB/288GB | 4GB/192GB | 4GB/192GB |
| Hard Drive Bays | SAS: 4 x 2.5" (hotplug) SSD SATA: 4 x 2.5" |
SAS: 2 x 2.5" (hotplug) SSD SATA: 2 x 2.5" |
SAS: 2 x 2.5" (hotplug) SATA: 1 x 2.5" |
SAS: 2 x 2.5" (hotplug) SATA: 1 x 2.5" |
| Hard Drive Types | SAS SSD, SATA SSD, SAS, nearline SAS | SAS/SSD | SAS SSD, SATA SSD, SAS, nearline SAS | SAS SSD, SATA SSD, SAS, nearline SAS |
| Hard Drive Controller | PERC H200 PERC H700 CERC 6/i |
Embedded H200 | PERC Η200 PERC Η700 PERC Η800 SAS6/Ε |
H200
Non-RAID SATA (one hard drive only) |
| Optional Hard Drive Controller | SAS6/iR PERC6i with RAID battery | SAS6/iR PERC6i with RAID battery | SAS6/iR PERC6i with RAID battery | |
| Availability | Hot-plug hard drives ECC memory Single Device Data Correction (SDDC) Supports memory demand and patrol scrubbing High-availability failover cluster support |
|||
| Systems Management | Dell™ OpenManage™ BMC, IPMI2.0 compliant Unified Server Configurator Lifecycle Controller iDRAC6 Enterprise with optional vFlash Remote Management: iDRAC6 Enterprise with option vFlash media Microsoft System Center Essential (SCE) 2010 v2 | Dell™ OpenManage™ featuring Dell Management Console BMC, IPMI2.0 compliant Unified Server Configurator Lifecycle Controller iDRAC6 Enterprise with optional vFlash | Dell™ OpenManage™ featuring Dell Management Console BMC, IPMI2.0 compliant Unified Server Configurator Lifecycle Controller iDRAC6 Enterprise with optional vFlash | Dell™ OpenManage™ featuring Dell Management Console BMC, IPMI2.0 compliant Unified Server Configurator Lifecycle Controller iDRAC6 Enterprise with optional vFlash Remote Management: iDRAC6 Enterprise with option vFlash media |
| Mezz Slots | Four x8 PCIe Gen2 | Two x8 PCIe Gen2 | Two x8 PCIe Gen2 | Two x8 PCIe Gen2 |
| I/O slots | NA | NA | Two x16 PCIe Gen2 H800/6GB SAS nVidia M1060 and M2050-204 | NA |
| RAID | 0,1,5 | 0,1 | 0,1 | 0,1 |
| NIC/LOM | Four TOE with optional iSCSI offload | Four 1GbE dual Broadcom® BCM5709S Two 10GbE QLogic cLOM8214 (Future) Two 10GbE Broadcom BCM57712 (Future) | 2-port Broadcom® 5709S 1Gb w/ TOE plus optional iSCSI Accelerator | 2-port Broadcom® 5709S 1Gb w/ TOE plus optional iSCSI Accelerator |
| USB | Three external USB 2.0 ports at front bezel One internal USB port | Two external USB 2.0 ports at front bezel One internal USB port | ||
| SD Card | Two internal SD slots 1 x Persistent Storage 1 x Management |
Two internal SD slots 1 x Persistent Storage 1 x Management / Redundant Persistent Storage |
Two internal SD slots 1 x Persistent Storage 1 x Management |
Two internal SD slots 1 x Persistent Storage 1 x Management |
| TPM | Yes, except in China where Trusted Computing Module (TCM) is the standard. | |||
| Video | Matrox G200eW integrated into iDRAC chip | |||
