Quick Specs
- Intel Xeon Scalable Family Generation 2 processors (x2xx) − New level of performance per core processors
- Higher speed memory @ 2933 MT/s for a select new Intel Generation 2 processors
- Additional Drive solutions
The HPE ProLiant BL460c Gen10 Server Blade now offers the Intel Xeon Processor Scalable Family with up to 25%5 bin to bin performance gain over the previous generation, plus 2666 MT/s HPE DDR4 SmartMemory. Additional support includes tiered storage controller options, internal 12 Gb/s SAS, 20 Gb n, support for two M.2, NVMe, or up to four uFF drives.
Designed for a wide range of configuration and deployment options, the HPE ProLiant BL460c Gen10 Server Blade provides the flexibility to optimize your core IT applications with right-sized storage for the right workload for a lower TCO. All of this may be managed by HPE OneView, the converged management platform that accelerates IT operations, business delivery and boosts overall performance.
Supported Enclosures:
Ideal for:
- Cloud Servers
- Corporate IT
- Database
- Retail Servers
Need assistance with customization? Our sales experts are here to help you.
Start Customizing Today!
Base Standard Capabilities
| Technical specifications | HPE ProLiant BL460c Gen10 Server Blade |
|---|---|
| Processor family | Intel® Xeon® Scalable 8100 series Intel® Xeon® Scalable 6100 series Intel® Xeon® Scalable 5100 series Intel® Xeon® Scalable 4100 series Intel® Xeon® Scalable 3100 series |
| Processor speed | 3.6 GHz |
| Number of processors | 2 or 1 |
| Processor core available | 4 or 6 or 8 or 10 or 12 or 14 or 16 or 18 or 20 or 22 or 24 or 26, per processor, depending on model |
| Processor cache | 8.25 MB L3 11.00 MB L3 13.75 MB L3 16.50 MB L3 19.25 MB L3 22.00 MB L3 24.75 MB L3 27.50 MB L3 32.50 MB L3 33.00 MB L3 35.75 MB L3 |
| Drive description | 2 SFF SAS/SATA/SSD or 2 SFF NVMe (optional) SSD |
| Expansion slots | 2, for detail descriptions reference the QuickSpecs |
| Memory type | HPE DDR4 SmartMemory |
| Memory slots | 16 DIMM slots |
| Maximum memory | 2 TB, using 128 GB DIMMs, available second half 2017 |
| Network controller | HPE 10 Gb 536FLB FlexFabric adapter 2-ports per controller or HPE 20 Gb 650FLB FlexFabric adapter 2-ports per controller, depending on model |
| Storage controller | HPE Smart Array S100i and/or HPE Smart Array P204i-b, depending on model |
| Power supply type | (6) Enclosure-based |
| System fan features | Hot-plug enclosure-based |
| Infrastructure management | HPE iLO Management with Intelligent Provisioning (standard), HPE iLO Advanced for BladeSystem, HPE OneView Advanced (optional) |
