Dell PowerEdge R830 Rack Server Chassis (8x2.5")

PER830-16x2.5 | Refurbished Dell PowerEdge R830 Rack Server Chassis (16x2.5")

SKU: DPE-R830-8x2.5-Chassis

Dell PowerEdge R830 Rack Server Chassis (8x2.5")

Name: Dell PowerEdge R830 Rack Server Chassis (8x2.5")
Brand: Dell
SKU: DPE-R830-8x2.5-Chassis
Price: 750.0 USD
Availability: InStock

Dell

| Chassis

.price-ui--loading { display: block !important; opacity: 1 !important; }

$750.00

Thanks for the request. We'll get back to you with in 24 hours.

Quick Specs

Form Factor:

2U rack server

Processor Max: 22 Core

2x or 4x Intel Xeon E5-4600 v4

Memory Max: 1.5TB

48 DDR3 RDIMM/LRDIMM 1600Mhz

Storage Max: N/A

8 SFF SAS/NL-SAS/SATA (HDD/SSD)

Rear Storage:

None

Boot Options:

IDSDM
USB

PCIe Slots:

Up to 7 Gen: 2.0
- 2 x16 half-length, full-height
- 1 x8 half-length, full-height
- 3 x8 half-length, half-height
- 1 x8 half-length, full-height for the RAID controller

Remote management:

iDRAC8 Express with Lifecycle Controller

LOM:

Broadcom® 5720 4x1Gb Base-T

RAID controllers (PERC 9) Max: 2

PERC H330, H730, H730P, H830, 12Gbps SAS HBA

GPU

Not Supported

Other Versions

Ideal for:

Database
High-Performance Computing (HPC)
Retail Servers
Virtual Desktop Interface (VDI)
Virtualization

Looking to Customize?

Need assistance with customization? Our sales experts are here to help you.

Start Customizing Today!

Base Standard Capabilities

Feature	PowerEdge R830 Technical Specification
Form factor	2U rack server
Dimensions and weight	H: 86.8 mm (3.417 in) W: 482.4 mm (18.99 in) D: 811.06 mm (31.93 in) with PSU and bezel D: 776.46 mm (30.59 in) PSU without bezel
Processor	Intel® Xeon® processor E5-4600 v4 product family
Chipset	Intel C612
Memory	(48 DIMM slots): 8GB/16GB/32GB/64GB DDR4, RDIMM, LRDIMM up 2400MT/s
Storage	16 x 2.5" SATA/SAS SSD, SAS HDD (15K, 10K), nearline SAS HDD (7.2K)
Drive bays	Up to 16 x 2.5"
I/O slots	7 PCIe slots: 2 x16 half-length, full-height 1 x8 half-length, full-height 3 x8 half-length, half-height 1 x8 half-length, full-height for the RAID controller
RAID controllers	Internal hard drive bay and hot-plug backplane: Internal controllers: PERC H330, PERC H730, PERC H730P External HBAs (RAID): PERC H830 External HBAs (non-RAID): 12Gbps SAS HBA
Communications	Broadcom® 5720 quad-port 1GbE Base-T (no TOE or iSCSI offload) Broadcom 57800S dual-port 10GbE Base-T with 2 1GbE (TOE and iSCSI offload available on 10GbE ports) Broadcom 57800S dual-port 10GbE SFP+ with 2 1GbE (TOE and iSCSI offload available on 10GbE ports) Intel I350 quad-port 1GbE Base-T (no TOE or iSCSI offload) Intel X540 dual-port 10GbE Base-T with 2 1GbE (FCoE capability enabled on the 10GbE ports)
Power supplies	Platinum 750W AC, auto-ranging; Platinum 1600W AC, auto-ranging; hot-plug redundant 1100W AC
Systems management	Systems management: IPMI 2.0 compliant Dell OpenManage Essentials Dell OpenManage Mobile Dell OpenManage Power Center Remote management: iDRAC8 with Lifecycle Controller iDRAC8 Express (default) iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade) 16GB vFlash media (upgrade) iDRAC Quick Sync Dell OpenManage Connections: HP Operations Manager, IBM Tivoli® Netcool® and CA Network and Systems Management Dell OpenManage Plug-in for Oracle® Database Manager Dell OpenManage Integrations: Dell OpenManage Integration Suite for Microsoft® System Center Dell OpenManage Integration for VMware® vCenter™
Operating system	Microsoft Windows Server® 2008/2012 SP2, x86/x64 (x64 includes Hyper-V®) Microsoft Windows Server 2008/2012 R2, x64 (includes Hyper-V) Microsoft Windows HPC Server 2008 Novell® SUSE® Linux Enterprise Server Red Hat® Enterprise Linux
Rack support	ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm.
