NetApp FAS8060 Dual Controller Filer Head w/ IOXM (HA)
Thanks for the request. We'll get back to you with in 24 hours.
Condition: Refurbished ✓ Pulled from working servers & Tested. ✓ 1-year Parts Warranty.
Warranty | Return Policy
-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.
The NetApp FAS8060 is a high-performance enterprise storage system designed for scalability and reliability. Featuring a single-chassis configuration with a total rack height of 6U, it includes dual controllers in a high-availability (HA) setup for enhanced redundancy. Powered by four 64-bit 8-core 2.10 GHz processors and 128GB of HA memory, the system delivers exceptional performance for demanding workloads. It includes 8x 1Gb RJ45 and 8x 10Gb SFP Ethernet ports, along with 8x UTA2 (10Gb/16Gb SFP+) and 8x QSFP (6Gb SAS) ports for versatile connectivity.
With support for up to 1200 drives and a maximum storage capacity of 15PB, the FAS8060 provides extensive storage flexibility, accommodating MSATA, SATA, NL-SAS, SAS, and SSD drives. The system supports RAID 4, RAID 6 (RAID-DP), and RAID-TEC for enhanced data protection and fault tolerance. It includes 8 PCIe expansion slots, ensuring seamless upgrades and integration with additional hardware as enterprise needs grow.
The chassis is optimized for efficient rack deployment, measuring 10.2 inches in height, 17.6 inches in width, and 28.9 inches in depth with cable management, with a maximum weight of 121.5 lbs. It supports multiple disk shelf models, including DS212C, DS2246, DS224C, DS4243, DS4246, DS4486, and DS460C. With remote management capabilities and a scalable architecture, the NetApp FAS8060 is an ideal storage solution for businesses requiring high availability, performance, and flexibility.
- Model: NetApp FAS8060
- Chassis: Dual Chassis
- Total Rack Height: 12U
- Controllers: Dual Controller (HA) w/ IOXM
- Memory (HA): 128GB
- Processor Model: 4x 64-bit 8-core 2.10 Ghz
- Ethernet Ports: 8 x RJ45 (1Gb) + 8 x SFP (10Gb)
- UTA2 Ports: 8 x SFP+ (10Gb/16Gb)
- SAS Ports: 8 x QSFP (6Gb)
- PCIe Expansion Slots: 24 x PCIe
- Max Drives (total): 1200
- Max Capacity: 15,000TB (15PB)
- Disk Shelves: DS212C, DS2246, DS224C, DS4243, DS4246, DS4486, DS460C
- Filer Heads: N/A
- Chassis Rack Height: 6U
- Chassis Heights: 10.2" (25.9 cm)
- Chassis Width w/o Mounting Flanges: 17.6" (44.7 cm)
- Chassis Depth w/ Cable Mgmt: 28.9" (73.4 cm)
- Chassis Weight: up to 121.5 lb (55.1 kg)
IOXM Specs
- PCIe Slots: 8
- Max Controllers: 2 (Per Chassis)
- PCI Slot (per): 4 x PCIe
- Ethernet Ports (per): 4 x RJ45 (1Gb) + 4 x SFP (10Gb)
- Fibre Channel Ports (per): N/A
- UTA2 Ports (per): 4 x SFP+ (10Gb/16G)
- SAS Ports (per): 4 x QSFP (6Gb)
- Remote Management: Yes
- Processor Model (per): 2x 64-bit 8-core 2.10 Ghz
- Memory (Single/HA): 64GB/128GB
- NVRAM (Single/HA): 8GB/16GB
- Max Number of Internal Drives: 0
- Max Number Drives (total): 1200
- Max Capacity: 15,000TB (15PB)
- Max # of MSATA Drives: 1200
- Max # of SATA Drives: 1200
- Max # of NL-SAS Drives: 1200
- Max # of SAS Drives: 1200
- Max # of SSD Drives: 240
- Drive Interface: MSATA, SATA, NL-SAS, SAS, SSD
- RAID: RAID 4, RAID 6 (RAID-DP), RAID-TEC
- Max # of DS212C Shelves: 50 external
- Max # of DS2246 Shelves: 50 external
- Max # of DS224C Shelves: 50 external
- Max # of DS4243 Shelves: 50 external
- Max # of DS4246 Shelves: 50 external
- Max # of DS4448 Shelves: 25 external
- Max # of DS460C Shelves: 20 external
