    NetApp FAS6250 Single Controller Filer Head w/ IOXM (Stand Alone)


    Price: Request a Quote

    Brand:
    MPN:
    FAS6250
    Type:
    Filer Head
    Condition:
    ECS Refurbished & Tested

    Request Quote

    Note: Please include as much details and relevant options about the item to help us match your request with an accurate price.


    -PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
    -SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.

    NetApp FAS6250 Single Controller Filer Head w/ IOXM (Stand Alone)

    The NetApp FAS6250 is a high-performance storage solution designed for enterprise environments requiring scalability and reliability. Featuring a single chassis configuration with a total rack height of 6U, it operates with a high-availability (HA) single-controller setup and IOXM for enhanced performance. Powered by two 64-bit 4-core 2.56 GHz processors and 72GB of HA memory, the system delivers efficient data processing for critical workloads. It includes 2x 1Gb RJ45 and 4x 10Gb SFP Ethernet ports, along with 4x 8Gb Fibre Channel ports for high-speed connectivity.

    With support for up to 1440 drives and a maximum storage capacity of 15PB, the FAS6250 provides a flexible storage infrastructure, accommodating MSATA, SATA, NL-SAS, SAS, and SSD drives. It supports RAID 4, RAID 6 (RAID-DP), and RAID-TEC for advanced data protection and redundancy. The system includes 15 PCIe expansion slots, ensuring seamless scalability and integration with additional storage components as enterprise needs grow.

    The chassis is optimized for efficient deployment, measuring 10.18 inches in height, 17.59 inches in width, and 29 inches in depth with cable management, with a maximum weight of 125.4 lbs. It supports multiple disk shelf models, including DS212C, DS2246, DS224C, DS4243, DS4246, DS4486, and DS460C. Featuring remote management capabilities and a scalable design, the NetApp FAS6250 is an ideal storage solution for enterprises demanding performance, flexibility, and reliability.


    System Config
    • Model: NetApp FAS6250
    • Chassis: Single Chassis
    • Total Rack Height: 6U
    • Controllers: Single Controller (HA) w/ IOXM
    • Memory (HA): 72GB
    • Processor Model: 2x 64-bit 4-core 2.56 Ghz
    • Ethernet Ports: 2 x RJ45 (1Gb) + 4 x SFP (10Gb)
    • Fibre Channel Ports: 4 x SFP (8Gb)
    • PCIe Expansion Slots: 15 x PCIe
    • Max Drives (total): 1440
    • Max Capacity: 15,000TB (15PB)
    • Disk Shelves: DS212C, DS2246, DS224C, DS4243, DS4246, DS4486, DS460C
    • Filer Heads: N/A
    Dimensions & Weight
    • Chassis Rack Height: 6U
    • Chassis Heights: 10.18" (25.86 cm)
    • Chassis Width w/o Mounting Flanges: 17.59" (44.68 cm)
    • Chassis Depth w/ Cable Mgmt: 29" (73.66 cm)
    • Chassis Weight: up to 125.4 lb (56.9 kg)
    Controller Specs
    • Max Controllers: 2 (Per Chassis)
    • PCI Slot (per): 15 x PCIe
    • Ethernet Ports (per): 2 x RJ45 (1Gb) + 4 x SFP (10Gb)
    • Fibre Channel Ports (per): 4 x SFP (4Gb)
    • UTA2 Ports (per): N/A
    • SAS Ports (per): N/A
    • Remote Management: Yes
    • Processor Model (per): 2x 64-bit 4-core 2.56 Ghz
    • Memory (Single/HA): 728GB/144GB
    • NVRAM (Single/HA): 4GB/8GB
    Storage
    • Max Number of Internal Drives: 0
    • Max Number Drives (total): 1440
    • Max Capacity: 15,000TB (15PB)
    • Max # of MSATA Drives: 1440
    • Max # of SATA Drives: 1440
    • Max # of NL-SAS Drives: 1440
    • Max # of SAS Drives: 1440
    • Max # of SSD Drives: 240
    • Drive Interface: MSATA, SATA, NL-SAS, SAS, SSD
    • RAID: RAID 4, RAID 6 (RAID-DP), RAID-TEC
    • Max # of DS212C Shelves: 60 external
    • Max # of DS2246 Shelves: 60 external
    • Max # of DS224C Shelves: 60 external
    • Max # of DS4243 Shelves: 60 external
    • Max # of DS4246 Shelves: 60 external
    • Max # of DS4448 Shelves: 30 external
    • Max # of DS460C Shelves: 24 external

    FAS6250 Parts Lists

    Ask about our NetApp Disk Shelves!
    We can create custom Turn-Key configurations based on your needs!
    Click here to view NetApp Disk Shelves

    This Product Is Compatible With The Following Systems:
