Specs
-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.
Comes with:
- Processors: 1 x Intel® Xeon® E5-2603v4
- Memory: 8GB (1x8GB Registered DIMMs, 2400 MHz)
- Network Controller: HPE Embedded Dual Port 361i Adapter Network Interface
- Storage Controller: HPE H240 FIO Smart Host Bus Adapter
- Hard Drive: None ship standard
- Internal Storage: 8 SFF HDD Bays
- Optical Drive Bay: 1; (Optional: DVD-ROM, DVD-RW)
- Optical Drive: Optional Slim Optical Bay (SATA DVD-RW/ROM Optical Drive)
- PCIe Slots: 2 Standard (1-FH/HL, 1-LP) PCIe 3.0
- Power Supply: (1) HPE 550W FIO Power Supply
- Fans: 3 hot swap fans, non-redundant
- Management: iLO Management (standard), Intelligent Provisioning (standard), iLO Essentials (optional), iLO Scale-out (optional only for DL), iLO Advanced (optional)
- Energy Start: N/A
- Form Factor: Rack (1U), HPE Easy Install Rails
What's new DL160 Gen9
- HPE Smart Memory 2400 MHz memory (up to 64GB)
- Intel Xeon E5-2600v4 processor support (up to 120 W)
- New 900 W/240 V power supply
- HPE Trusted Platform Module (TPM) 2.0
- New HDD offerings
The compact refurbished HP ProLiant DL160 Gen9 Server provides right-sized performance and storage density, making it well-suited for a small to midsize business or service provider. You get exceptional reliability, manageability, and efficiency in a 2P rack design that fits your available space and won’t strain your budget.
Essential Combination of Performance, Manageability and Storage for the IT Needs of SMBs
The HPE ProLiant DL160 Gen9 Server offers (16) DIMM slots of HPE DDR4 SmartMemory, with built-in intelligence to reduce downtime and up to 14% better throughput performance.
Embedded management to deploy, monitor and support your server remotely, out of band with HPE iLO makes it easier to manage complex IT environments thereby minimizing the IT resource requirements.
Supports up to (2) Intel Xeon E5-2600 v3/v4 processors offering improved performance and efficiency.
HPE SmartDrives continue to deliver optimal performance, capacity, and reliability to meet various customer segments and workload requirements at the right economics.
Supports up to (4) LFF and (8) SFF 12 Gb/s with flexibility of (4) LFF NHPE option.
Embedded SATA HPE Dynamic Smart Array B140i Controller for boot and data. Choice of HPE Smart Array Controllers with increased performance, data availability with 12 Gb/s SAS technology or HPE Smart HBAs with reliable high performance SAS connectivity capable of running HBA mode or simple RAID mode.
Looking to Customize?
Not seeing the exact specs you need?
Start your build today with Express Computer Systems!
Start Customizing Today!
Spec Sheet 4
| Technical specifications | HPE ProLiant DL160 Gen9 Server |
|---|---|
| Compute | Up to 2 Intel® Xeon® E5-2600 v3 Series, 4/6/8/10/12 cores PCIe 3.0, up to 3 available slot(s) |
| Memory | HP SmartMemory (16) DDR4, up to 2,133 MHz (512 GB max at launch), support for NVDIMM (third party) |
| Storage | Standard HP Dynamic Smart Array B140i, optional HP Smart Array Controllers, and HP Smart HBAs via PCIe stand-up cards |
| HPE SmartDrives | 8 SFF/4 LFF max, HDD/SSD |
| Networking | Embedded 2x 1GbE, optional FlexibleLOM slot on riser |
| VGA/serial/USB ports/SD | Rear video, 3x USB 3.0 and 1x USB 2.0 (std), 1x USB 3.0 (opt of SFF models), microSD |
| On Premise management | HP OneView and HP iLO Advanced |
| On Cloud management | HP Insight Online with enhanced mobile application |
| On System management | HP iLO, HP SUM, Intelligent Provisioning and scripting tools; plus the new UEFI and HP RESTful Interface Tool |
| Power and cooling | Up to 94 percent efficient (Platinum) 900 W RPS,1 550 W multi-output Hot swap fans with optional redundancy |
| Industry compliance | ASHRAE A3 and A4, ENERGY STAR® |
| Form factor/Chassis depth | ASHRAE A3 |
| Form factor/chassis depth | Rack (1U), 23.9" (SFF), 23.9" (LFF) |
| Serviceability — Easy install rails | Standard |
