Specs
-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.
Comes with:
- Processors - 1 x Intel® Pentium® G4560
- Memory - 8GB (1x8GB UDIMM, 2400 MHz)
- Network Controller - HPE embedded 1Gb 2-port 332i network Adapter
- Storage Controller - HPE Dynamic Smart Array B140i
- Hard Drive - None ship standard; includes 2 LFF hard drive blanks
- Internal Storage - 2 LFF HDD Bays (Non Hot Plug)
- Optical Drive Bay - 1; (Optional: DVD-ROM, DVD-RW)
- Optical Drive - None
- PCIe Slots - 2 PCIe 3.0 Slots
- Power Supply - (1) 290W Non Hot Plug Power Supply
- Fans - 3 non hot plug, non-redundant
- Management - iLO Management (standard), Intelligent Provisioning (standard), iLO Essentials (optional), iLO Scale-out (optional only for DL), iLO Advanced (optional)
- Energy Start - N/A
- Form Factor - Rack (1U), HPE Short Friction Rail Kit
Looking to Customize?
Not seeing the exact specs you need?
Start your build today with Express Computer Systems!
Start Customizing Today!
Spec Sheet 4
| Technical specifications | HPE ProLiant DL20 Gen9 Server |
|---|---|
| Compute | Choose from one Intel Xeon E3-1200 v5 or v6 Series, Up to 2 PCIe 3.0 slots |
| Memory | 4 x DDr4, up to 2133 MHz (64 GB max) |
| Storage | HPE Dynamic Smart Array B140i, HPE Smart Array Controller P440 with FBWC, and HPE Smart HBA H240 |
| HPE SmartDrives | 2LFF Non hot-Plug & Hot Plug (SAS/SATA); 4SFF Hot Plug (SAS/SATA) |
| Networking | 2 x 1GbE embedded Ethernet Adapter and FlexibleLOM |
| vGA/serial/USB ports/SD | 2 rear USB 3.0, 2 front USB 2.0, and 1 internal USB 3.0 |
| GPU support | One single-width, half-length GPU (optional) |
| On-premise management | HPE iLO 4 (Advanced/Scale-out/Essentials Optional) |
| On-cloud management | HPE Insight Online with enhanced mobile application |
| On-system management | HPE iLO 4, HPE Intelligent Provisioning, HPE System Update Manager (SUM), HPE RESTful Interface Tool |
| Power and cooling | Standard 290 W power supply; 900 W AC 240vDC redundant power supply (optional for SFF chassis only) |
| Industry compliance | ASHRAE A3, ENErGY STAr (only on RPS configuration models)* |
| Form factor/chassis depth | Rack (1U) 15.05" (ear to rear) |
| System rOM | UEFI and Legacy BIOS |
| System fan features | Depending on model SKU. Standard 2 fans, none-hot-plug. Optional 4 additional fans, hot-plug and N+1 redundancy Reference QuickSpecs for config. detail. |
| Network controller | HPE Ethernet 1Gb 4-port 369i Adapter |
| Storage controller | 1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a SR Gen10 and/or 1 HPE Smart Array E208i-a Gen10, depending on model. For detail reference QuickSpecs. |
| Product Dimensions (metric) | 18.2 x 25.51 x 6.85 in |
| Weight | 46.30 lb |
| Infrastructure management | HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) (standard), HPE iLO Advanced, and OneView Advanced (optional) |
| Drive supported | 24 SFF SAS/SATA HDD/SSD, or 16 SFF SAS/SATA HDD/SSD and 8 SFF NVMe SSD. 12 LFF SAS/SATA HDD/SSD or 12 LFF NHP SATA HDD, depending on model. Upgrade option kits are available. |
