Specs
CTO Item
This part is strictly for configuring Dell servers. If you have landed on this page and you're looking for a specific part number. Please send us a "Request a Quote" with the part number you need.
Base Standard Capabilities
| Feature | PowerEdge R430 Technical specification | |
|---|---|---|
| Form factor | 1U rack server | |
| Dimensions and weight | H: 42.8 mm (1.68 in) W: 482.4 mm (18.99 in) with rack latches; 434.0 mm (17.08 in) without rack latches D: 607.0 mm (23.9 in) without bezel; 676.92 mm (26.7 in) with bezel | Weight 16.73 kg (36.88 lb) empty 19.9 kg (43.87 lb) maximum |
| Processor | Intel® Xeon® processor E5-2600 v4 product family Processor sockets: 2 Chipset: C610 Internal interconnect: Up to 9.6GT/s Cache: 2.5MB per core; core options: 4, 6, 8, 10, 12, 14, 16, 18, 20 | |
| Memory | DDR4 RDIMMs at up to 2400MT/s 12 DIMM slots: 4GB/8GB/16GB/32GB | |
| I/O slots | 2 PCIe 3.0 | |
| Storage | SAS, SATA, nearline SAS, SSD Multiple R430 chassis available:
| |
| RAID controllers | Internal controllers: PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P External HBAs (RAID): PERC H830 | |
| Communications | 4 x 1GbE LOM | |
| Power supplies | 450W, 550W PSU | |
| Management | Systems management
iDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade), 8GB vFlash media (upgrade), 16GB vFlash media (upgrade) | Dell OpenManage Connections:
|
| Optional supported hypervisors | Citrix® XenServer, VMware vSphere® ESXi®, Red Hat® Enterprise Virtualization® | |
| Operating system | Microsoft® Windows Server® 2016 Microsoft Windows 2012 Microsoft Windows Server 2012 R2, x64 Red Hat® Enterprise Linux® VMware® vSphere® ESXi® SUSE® Linux Enterprise Server | |
| Rack support | ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm. | |
