Dell 12Gb SAS HBA (Non-RAID) x8 PCIe Full Height External Controller | 6PDH5

SKU: 6PDH5

Dell 12Gb SAS HBA (Non-RAID) x8 PCIe FH External Controller | 6PDH5

Name: Dell 12Gb SAS HBA (Non-RAID) x8 PCIe FH External Controller | 6PDH5
Brand: Dell
SKU: 6PDH5
Price: 295.0 USD
Availability: InStock

Dell

| Adapter

.price-ui--loading { display: block !important; opacity: 1 !important; }

$295.00

Thanks for the request. We'll get back to you with in 24 hours.

Quick Specs

Models

Drive Types

12 Gb/s SAS

PCI Support

PCI-e 3.0

SAS Connectors

2x4 External

Cache Memory

No Cache

Write Back Cache

No Cache

RAID Levels

No RAID Pass-Thru Only

Max Drive Support

255

RAID Support

No RAID Pass-Thru Only

Part Numbers:

6PDH5

The 12Gbps Sas Host Bus Adapter offers exceptional Performance And Advanced Management Functionality That Can Shave Days Off Installing And Managing Adapters. It Is Coupled With Up To 3X Better Iops Performance Per Watt, Which Makes Dell 12Gbps Host Bus Adapters The Clear Choice For The Toughest Virtualized, Cloud And Mission Critical Deployments.The Card provides the connection needed to add the Storage Array to a compute Server. This will give that Server a 12Gb/s connection to connect the Storage arrays to the Compute Server.
This does not get installed into the Storage Array or Storage Enclosure.

Compatible With:

Dell Ml6000
Dell R210
Dell R210ii
Dell R240
Dell R330
Dell R340
Dell R430
Dell R440
Dell R510
Dell R530
Dell R540
Dell R610
Dell R630
Dell R640
Dell R650
Dell R6515
Dell R6525
Dell R710
Dell R730
Dell R730xd
Dell R740
Dell R740xd
Dell R740xd2
Dell R7415
Dell R7425
Dell R750
Dell R750xa
Dell R7515
Dell R7525
Dell R810
Dell R830
Dell R840
Dell R930
Dell R940
Dell R940xa
Dell T130
Dell T140
Dell T330
Dell T340
Dell T350
Dell T430
Dell T440
Dell T550
Dell T610
Dell T630
Dell T640
Dell T710
Dell Tl1000
Dell Tl2000
Dell Tl4000
Dell vrtx

(Click to View)

Spec Sheet 4

Models	Drive Types	PCI Support	SAS Connectors	Cache Memory	Write Back Cache	RAID Levels	Max Drive Support	RAID Support
H830 Adapter	12 Gb/s SAS 6 Gb/s SATA	PCI-e 3.0	2x4 External	2 GB NV	Flash Backed Cache	0,1,5,6,10,50,60	255	Hardware
H730P Adapter FH - X4TTX	12 Gb/s SAS 6 Gb/s SATA	PCI-e 3.0	2x4 External	2 GB NV	Flash Backed Cache	0,1,5,6,10,50,60	32	Hardware
H730P Adapter LP - J14DC
H730P Adapter No Bracket - C9Y6K
H730P MX	12 Gb/s SAS 6 Gb/s SATA/SAS 3 Gb/s SATA	PCI-e 3.0	2x4 External	2 GB NV	Flash Backed Cache	0,1,5,6,10,50,60	-	Hardware
H730P Mini Mono	12 Gb/s SAS 6 Gb/s SATA	PCI-e 3.0	2x4 External	2 GB NV	Flash Backed Cache	0,1,5,6,10,50,60	32	Hardware
H730P Mini Blade - 3X31R	12 Gb/s SAS 6 Gb/s SATA	PCI-e 3.0	2x4 External	2 GB NV	Flash Backed Cache	0,1,5,6,10,50,60	32	Hardware
H730P Mini Blade - GD07N
H730P Mini Blade - YRPP6
H730 Adapter FH	12 Gb/s SAS 6 Gb/s SATA	PCI-e 3.0	2x4 External	1 GB NV	Flash Backed Cache	0,1,5,6,10,50,60	32	Hardware
H730 Adapter LP
H730 Adapter No Bracket
H730 Mini Mono	12 Gb/s SAS 6 Gb/s SATA	PCI-e 3.0	2x4 External	1 GB NV	Flash Backed Cache	0,1,5,6,10,50,60	32	Hardware
H730 Mini Blade	12 Gb/s SAS 6 Gb/s SATA	PCI-e 3.0	1x4 External	1 GB NV	Flash Backed Cache	0,1,5,6,10,50,60	32	Hardware
H330 Adapter FH	12 Gb/s SAS 6 Gb/s SATA	PCI-e 3.0	2x4 External	No Cache	No Cache	0,1,5,10,50	16 RAID, 32 Non-RAID	Hardware
H330 Adapter LP	12 Gb/s SAS 6 Gb/s SATA	PCI-e 3.0	2x4 External	No Cache	No Cache	0,1,5,10,50	16 RAID, 32 Non-RAID	Hardware
H330 Mini Mono	12 Gb/s SAS 6 Gb/s SATA	PCI-e 3.0	2x4 External	No Cache	No Cache	0,1,5,10,50	16 RAID, 32 Non-RAID	Hardware
H330 Mini Blade	12 Gb/s SAS 6 Gb/s SATA	PCI-e 3.0	2x4 External	No Cache	No Cache	0,1,5,10,50	8	Hardware
S130 Software RAID	6 Gb/s SATA	N/A	N/A	No Cache	No Cache	0,1,5,10	10	Software - Windows and Linux
12 Gbps SAS Ext. HBA FH	12 Gb/s SAS	PCI-e 3.0	2x4 External	No Cache	No Cache	No RAID Pass-Thru Only	255	No RAID Pass-Thru Only
12 Gbps SAS Ext. HBA LP	12 Gb/s SAS	PCI-e 3.0	2x4 External	No Cache	No Cache	No RAID Pass-Thru Only	255	No RAID Pass-Thru Only
More HBA Gen 9 Controllers
	FD33XD Dual HBA (Split Host)	FD33XD Dual HBA (Dual Host)	FD33XD Dual PERC (Split Host)	FD33XD Dual PERC (Dual Host)	FD33XS Single HBA (Joined Mode)	FD33XS Single PERC (Joined Mode)	HBA330 + 12Gb SAS HBA	HBA330 MX 12Gb SAS Non-RAID
