Home / Fibre Channel / Cisco MDS 9148S 48 Port 16Gb Multilayer Fabric Switch (12P Active) | DS-C9148S-12PK9
SKU: DS-C9148S-12PK9

Cisco MDS 9148S 48 Port 16Gb Multilayer Fabric Switch (12P Active) | DS-C9148S-12PK9

Cisco

| Switches
Contact For Pricing

Thanks for the request. We'll get back to you with in 24 hours.

Switch Specs

  • PN: DS-C9148S-12PK9
  • Spare PN: DS-C9148S-K9
  • Active Ports: 12
  • Max Ports: 24, 36, or 48 (License Required)
  • Speed: 2, 4, 8, and 16 Gbps
  • Protocol: Fiber Channel
  • From Factor: 1U
  • Power: 300W AC (2 per switch)

Part Number:

  • A standalone SAN in small departmental storage environments
  • A top-of-the-rack switch in medium-sized redundant fabrics
  • An edge switch in enterprise data center core-edge topologies

The Cisco MDS 9148S offers up to 48 autosensing Fibre Channel ports, supporting speeds of 2, 4, 8, and 16 Gbps, with each port delivering 16 Gbps of dedicated bandwidth. The base model includes 12 active ports and can be expanded in 12-port increments—up to 24, 36, or 48 ports—using the Cisco MDS 9148S On-Demand Port Activation license. Uniquely, the MDS 9148S is the only 1RU switch that scales from 12 to 48 high-performance Fibre Channel ports. It is also the first 16-Gbps Fibre Channel switch in a 1RU form factor designed with NVMe readiness. When deployed as an N-Port Virtualization (NPV) node or an N-Port ID Virtualization (NPIV) core, it offers a flexible and scalable solution for host connectivity—whether connecting to legacy Fibre Channel switches or multi-protocol Nexus NPV switches.

Security
  • VSAN fabric isolation
  • Hardware zoning by Access Control Lists (ACLs)
  • Fibre Channel Security Protocol (FC-SP) switch-to-switch authentication
  • FC-SP host-to-switch authentication
  • Role-based access control (RBAC) using RADIUS, TACACS+, or Lightweight Directory Access Protocol (LDAP) authentication, authorization, and accounting (AAA) functions
  • Secure FTP (SFTP)
  • Secure Shell Protocol Version 2 (SSHv2)
  • Simple Network Management Protocol Version 3 (SNMPv3) implementing Advanced Encryption Standard (AES)
  • Control-plane security
Ports
  • Fixed configuration with 48 ports of 16-Gbps Fibre Channel
  • Available in a 12-port configurable base or as a bundle with all 48 ports enabled
  • Enable incremental ports on the 12-port base model, with the 12-port On-Demand Activation license
Performance
  • Port speed: 2/4/8/16-Gbps autosensing with 16 Gbps of dedicated bandwidth per port
  • Buffer credits: Up to 256 for a group of 4 ports, with a default of 64 buffer credits per port and a maximum of 253 buffer credits for a single port in the group
  • PortChannel: Up to 16 physical links

Spec Sheet 4

Product Licenses
Cisco MDS 9000 Family Enterprise Package Includes advanced traffic-engineering and network security features such as IVR, QoS and zone-based QoS, Fibre Channel Security Protocol (FC-SP), port security, VSAN-based access control, and fabric binding for open systems. Licensed per switch for all the ports on the switch.
Cisco Prime DCNM for SAN Advanced Edition for Cisco MDS 9100 Series Includes advanced management capabilities such as vCenter integration, performance trending, advanced provisioning, backup, and dashboards. Licensed per switch for all the ports on the switch. License is hosted on a server.
Cisco MDS 9148S 12-port On-Demand Activation Enables 12 additional Fibre Channel ports (up to 48 total ports on the switch).
