NetApp FAS3210 Filer Head Single Controller

SKU: FAS3210

NetApp FAS3210 Single Controller Filer Head (Stand Alone)

Name: NetApp FAS3210 Single Controller Filer Head (Stand Alone)
Brand: NetApp
SKU: FAS3210
Availability: OutOfStock

NetApp

| Filer Head

.price-ui--loading { display: block !important; opacity: 1 !important; }

Contact For Pricing

Thanks for the request. We'll get back to you with in 24 hours.

-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.

-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.

Quick Specs

The NetApp FAS3210 is a compact, 3U storage system designed for mid-sized enterprise deployments. Its dual-controller, high-availability architecture ensures continuous access to data, while up to 10GB of shared memory helps maintain responsive performance for critical workloads.

Equipped with two 2.33GHz 64-bit processors and built-in 1GbE and 4Gb FC ports, the FAS3210 supports flexible network integration. Its RAID 4 and RAID-DP options enhance data protection, and four PCIe slots enable additional network or storage interface expansions.

With support for up to 240 drives and a maximum capacity of 1.4PB, the FAS3210 scales to meet growing demands. Compatible with various NetApp disk shelves—including DS14, DS2246, and DS424x models—it offers multiple drive interfaces (FC, SAS, SATA, SSD) to accommodate diverse performance and capacity requirements.

System Config

Model: NetApp FAS3210
Chassis: Single Chassis
Total Rack Height: 3U
Controllers: Single Controller (Stand Alone)
Memory (HA): 5GB
Ethernet Ports: 2 x RJ45 (1Gb)
Fibre Channel Ports: 2 x SFP (4Gb)
SAS Ports: 2 x QSFP (6Gb)
PCIe Expansion Slots: 2 x PCIe
Max Drives (total): 240
Max Capacity: 1,440TB (1.4PB)
Disk Shelves: DS14-Mk2-AT, DS14-Mk2-FC, DS14-Mk4-FC, DS2246, DS4243, DS4246
Filer Heads: N/A

Dimensions & Weight

Chassis Rack Height: 3U
Chassis Heights: 5.12" (13 cm)
Chassis Width w/o Mounting Flanges: 17.6" (44.7 cm)
Chassis Depth w/ Cable Mgmt: 23.9" (60.7 cm)
Chassis Weight: up to 79.4 lb (36.0 kg)

Controller Specs

Max Controllers: 2 (Per Chassis)
PCI Slot (per): 2 x PCIe
Ethernet Ports (per): 2 x RJ45 (1Gb)
Fibre Channel Ports (per): 2 x SFP (4Gb)
UTA2 Ports (per): N/A
SAS Ports (per): 2 x QSFP (6Gb)
Remote Management: Yes
Processor Model (per):1x 64-bit 2-core 2.33 Ghz
Memory (Single/HA): 5GB/10GB
NVRAM (Single/HA): 0GB/1GB

Storage

Max Number of Internal Drives: 0
Max Number Drives (total): 240
Max Capacity: 1,440TB (1.4PB)
Max Number of FC Drives: 240
Max Number of NL-SAS Drives: 240
Max Number of SAS Drives: 240
Max Number of SATA Drives: 840
Max Number of SSD Drives: 240
Drive Interface: FC, NL-SAS, SAS, SATA, SSD
RAID: RAID 4, RAID 6 (RAID-DP)
Max # of DS14-Mk2-AT Shelves: 18 external
Max # of DS14-Mk2-FC Shelves: 18 external
Max # of DS14-Mk4-FC Shelves: 18 external
Max # of DS2246 Shelves: 10 external
Max # of DS4243 Shelves: 10 external
Max # of DS4246 Shelves: 10 external

FAS3210 Parts Lists

View Adapters

View Transceiver(s

View Data Cables

View Power Cables

View Rail Kits

Ask about our NetApp Disk Shelves!
We can create custom Turn-Key configurations based on your needs!
Click here to view NetApp Disk Shelves

Compatible With:

NetApp FAS3210

(Click to View)

NetApp FAS3210 Single Controller Filer Head (Stand Alone)
