Specs
Quick Specs
Half Height - 4 Sleds in an FX2 Enclosure
Processor | Max: 28 Cores2 x 2nd Generation Intel Xeon ScalableM
Memory | Max: 2TB16 DDR4 RDIMM/LRDIMM 2933Mhz
Storage | Max: 12.8TB2 SFF SAS/SATA (HDD/SSD), NVMe SSD
Mixing SAS/SATA is not supported
S140 (SW RAID SATA/NVMe)
H330, H730p, 12 Gbps SAS HBA
4x1 GbE, 2x10 GbE, 4x10 GbE
iDRACiDRAC9 with Lifecycle Controller
GPU:None
Ideal for:
- Big Data Analytics
- Cloud Servers
- Data Analytics
- High-Performance Computing (HPC)
- Virtualization
This is one of the supported Node Servers, the PowerEdge FX2 or PowerEdge FX2s must be configured separately.
The PowerEdge FC640 delivers powerful performing processors, large memory capacity and highly scalable I/O capability that meet virtualization, server consolidation, scale-out, private cloud or hybrid cloud needs.
- PowerEdge FX2s: “switched” configuration supporting up to eight low-profile PCIe 3.0 expansion slots
- PowerEdge FX2: lower-cost “unswitched” configuration that does not offer expansion slots.
Powerful 2-socket modular architecture server
A flexible, two-socket half-height/width compute sled powered by up to two 28-core, Intel® 2nd generation Xeon® Scalable processors, each FC640 supports up to 2TB of DDR4 memory, making it a perfect candidate for dense virtualization environments, software defined storage, databases, HPC, big data analytics, and private cloud workloads. The FC640 storage options include two 2.5-inch drives, with an option of NVMe PCIe SSDs for high performing direct attached storage requirements. The FX2 chassis supports up to four FC640 servers. SDS environment support now includes VMware vSAN with the HBA330 controller.
Innovative management with intelligent automation
The Dell EMC OpenManage systems management portfolio enables peak efficiency for PowerEdge servers, through intelligent, automated management of routine IT tasks. Combined with the unique agent-free management capabilities of the embedded iDRAC9 with Lifecycle Controller, the FC640 is simply managed, freeing up your time for high profile projects.
- Increase IT data protection and integrity with the embedded security features of iDRAC9.
- Enable collective or individual management of your servers with the Dell EMC Chassis Management Controller (CMC), embedded within the FX2 enclosure.
- Improve IT productivity and agility with OpenManage Enterprise and Essentials: from bare-metal deployment to ongoing maintenance, and enforcement of IT policies within production environments.
End-to-end server ecosystem and life cycle security
Every PowerEdge server is designed as part of a cyber-resilient architecture, integrating security into the full server life cycle. The FC640 leverages new security features built into every new PowerEdge server strengthening protection so you can reliably and securely deliver accurate data to your customers no matter where they are. By considering each aspect of system security, from design to retirement, Dell EMC ensures trust and delivers a worry-free, secure infrastructure without compromise.
| DIMM Speed | DIMM Type | DIMM Capacity (GB) | Ranks per DIMM | Data Width | SDDC Support | DIMM Volts |
|---|---|---|---|---|---|---|
| 2933 MT/s | RDIMM | 8 | 1 | x8 | Advanced ECC | 1.2 |
| 2933 MT/s | RDIMM | 16 | 2 | x8 | Advanced ECC | 1.2 |
| 2933 MT/s | RDIMM | 32 | 2 | x4 | All Modes | 1.2 |
| 2933 MT/s | LRDIMM | 64 | 4 | x4 | All Modes | 1.2 |
| 2933 MT/s | LRDIMM | 128 | 4 | x4 | All Modes | 1.2 |
- Width: 211.0mm (8.3")
- Height: 40.25mm (1.58")
- Depth: 535.75mm (21.09")
Weight
- 5.8kg (12.79lb)
Need assistance with customization? Our sales experts are here to help you.
Start Customizing Today!
Base Standard Capabilities
| Feature | PowerEdge FC640 Technical specification | |
|---|---|---|
| Processor | Up to two Intel® 2nd generation Xeon® Scalable processors, up to 28 cores per processor | |
| Memory | 16 DDR4 DIMM slots, supports RDIMM / LRDIMM / AEP, up to 2933MT/s speeds, 2TB max mem ECC Registered DDR4 | |
| Storage controllers | Internal controllers: Software RAID S140, PERC H330, H730P, HBA330 Boot Optmized Storage system, Internal Dual SD Module | |
| Drive bays | Front: Up to 2 x 2.5” SAS/SATA (HDD/SDD), NVMe SSD on a Universal Backplane, max 12.8TB (PCIe SSD) | |
| Power supplies Fans | PowerEdge FX2 enclosure: Platinum Rated - 1600W, 2000W, 2400W Hot plug fans with full redundancy | |
| Dimensions | 40.3mm x 211 mm x 535.8 mm | |
| Embedded/At-Server | iDRAC9 iDRAC Direct | iDRAC REST API with Redfish Chassis Management Controller (CMC) |
| Consoles & Mobile | OpenManage Enterprise OpenManage Essentials | OpenManage Mobile OpenManage Power Center |
| Integrations | Microsoft® System Center, VMware® vCenter™, BMC Software (available from BMC) | |
| Connections | Nagios Core and Nagios XI, MicroFocus | |
| Tools | Dell EMC Repository Manager Dell EMC Update Package Dell EMC System Update Dell EMC Server Update Utility | iDRAC Service Module OpenManage Server Administrator OpenManage Storage Services |
| Security | TPM 1.2/2.0 optional Cryptographically signed firmware Silicon Root of Trust | Secure Boot System Lockdown System Erase |
| I/O & Ports | Network daughter card options 2 x 10GE + 2 x 1GE, 4 x 10GE Video card: VGA controller integrated with iDRAC PCIe: See enclosure specifications | |
| Supported operating systems | Canonical® Ubuntu® Server LTS Citrix® XenServer® Microsoft Windows Server® with Hyper-V Oracle® Linux | Red Hat® Enterprise Linux SUSE® Linux Enterprise Server VMware vSphere® For specifications and interoperability details, see Dell.com/OSsupport. |
| Recommended support and services | Choose ProSupport Plus for critical systems or ProSupport for automated proactive and predictive support for your PowerEdge solution. Consulting, deployment and education offerings are also available. Availability and terms for Dell EMC Services vary by region. Contact your Dell EMC representative or visit DellEMC.com/Services | |
| Dell Financial Services | Deliver results with easy financing. Explore financial options that move at the speed of business. For more information, visit https://www.emc.com/products/how-to-buy/global-financial-services/index.htm.* | |
Spec Sheet 4
| Feature | PowerEdge FC630 | PowerEdge FC640 |
|---|---|---|
| Form factor | Half height blade | Half height blade |
| CPU | 2 socket Intel Haswell EP | 2 socket Intel Processor |
| Memory | 24x DDR4 RDIMM and LRDIMM | 16x DDR4 RDIMM and LRDIMM |
| Hard drives | 2.5-inch-12 GB SAS/SATA
1.8-inch-6 GB SATA |
12 GB SAS and 6 GB SATA |
| Backplane | 2.5-inch hard drive:
|
2.5-inch hard drive:
|
| Storage controller | Hardware RAID: H330, H730, H730P
Software RAID: PERC S130 |
Hardware RAID: H330, H730P, BOSS-M.2 SATA
Software RAID: PERC S140 |
| PCIe SSD | Yes | Yes-NVMe |
| Communications | bNDC: 4x1 GbE, 2x10 GbE, 4x10GbE | bNDC: 4x1 GbE, 2x10 GbE, 4x10 GbE |
| System management | iDRAC8 Express/Enterprise Lifecycle Controller 3.0 |
iDRAC9 Express/Enterprise
Lifecycle Controller 3.x |
| Heat sink type | 68 mm width for 24 DIMMs
86 mm width for 20 DIMMs |
CPU1 heat sink: 100 x 108 x 24 mm
CPU2 heat sink: 86.7 x 108 x 24 mm |
| TPM | TPM Modular-FIPS TPM 1.2 | TPM Modular-TPM 1.2 FIPS, TPM 2.0 FIPS, TPM 2.0 China |
