NetApp Adapter X3149-R6 (ONTAP) PCIe bus with plug QSFP (NVRAM8 4GB)

SKU: X3149-R6

NetApp Dual Port QSFP 40Gb QDR InfiniBand w/ NVRAM8 4GB Cache Adapter (111-00819) | X3149-R6

Name: NetApp Dual Port QSFP 40Gb QDR InfiniBand w/ NVRAM8 4GB Cache Adapter (111-00819) | X3149-R6
Brand: NetApp
SKU: X3149-R6
Price: 74.99 USD
Availability: InStock

NetApp

| Adapter

.price-ui--loading { display: block !important; opacity: 1 !important; }

$74.99

-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.

-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.

Adapter Specs

Part Number: X3149-R6
Mfg Number: 111-00819
Spare Part Number: SP-3149-R6
Bus Type: PCI-e
Ports: Dual Port
Plug Type: QSFP
Cable Type: N/A
Speed: 40Gb QDR
Supported Protocol(s): 40Gb QDR InfiniBand
Optical Module Included?: No
Min ONTAP: 9.1RC1, 9.0RC1, 8.3RC1, 8.2RC1, 8.1, 8.0.1

Platform Models

V6290, V6280, V6250, V6240, V6220, V6210, SA620, FAS6290, FAS6280, FAS6250, FAS6240, FAS6220, FAS6210

Cables

InfiniBand 40Gbps (Cu) Copper Cables

Description	Mktg / Mfg Part No	Length	End 1 / End 2
NetApp 0.5m	X6557-R6 / 112-00176	0.5m	QSFP / QSFP
NetApp 1m	X6594-R6 / 112-00256	1m	QSFP / QSFP
NetApp 2m	X6558-R6 / 112-00177	2m	QSFP / QSFP
NetApp 3m	X6595-R6 / 112-00255	3m	QSFP / QSFP
NetApp 5m	X6559-R6 / 112-00178	5m	QSFP / QSFP

InfiniBand 40Gbps (Op) Optical Transceiver X1949A-R5 with Supported Cables

Description	Mktg / Mfg Part No	Length	End 1 / End 2
NetApp XCVR Optical Fibre / Fiber Data Cable	X1956-R6 / 332-00284R6,AFBR-79EQDZ-NA3,AFBR-79EQDZ-NA4,AFBR-79Q4Z-NA1,AFBR-79Q4Z-NA2	XCVR	QSFP / MPO

Min OS

NetApp Min OS:

OS	Platforms
ONTAP 9.1P9	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
ONTAP 9.1P8	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
ONTAP 9.1P3	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
ONTAP 9.1P17	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
ONTAP 9.1P13	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
ONTAP 9.1P10	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
ONTAP 9.1P1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
ONTAP 9.1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
ONTAP 9.1RC2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
ONTAP 9.1RC1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
ONTAP 9.0	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
ONTAP 9.0RC2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
ONTAP 9.0RC1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.3.2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.3.2RC2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.3.2RC1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.3.1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.3.1RC1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.3	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.3RC2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.3RC1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.2.5P5	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.2.5	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.2.4	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.2.4	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.2.3	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.2.3	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.2.2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.2.2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.2.2RC2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.2.2RC2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.2.2RC1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.2.2RC1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.2.1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.2.1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.2.1RC2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.2.1RC2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.2.1RC1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.2.1RC1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.2RC1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.2RC1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.1.4	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.1.4	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.1.3	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.1.3	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.1.3RC1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.1.3RC1	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.1.2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.1.2	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.1.2RC2	FAS6210, FAS6240, FAS6280, V6210, V6240, V6280,
7-Mode 8.1.2RC2	FAS6210, FAS6240, FAS6280, SA620, V6210, V6240, V6280,
Clustered Data ONTAP 8.1.1	FAS6210, FAS6240, FAS6280, V6210, V6240, V6280,
7-Mode 8.1.1	FAS6210, FAS6240, FAS6280, SA620, V6210, V6240, V6280,
Clustered Data ONTAP 8.1.1RC1	FAS6210, FAS6240, FAS6280, V6210, V6240, V6280,
7-Mode 8.1.1RC1	FAS6210, FAS6240, FAS6280, SA620, V6210, V6240, V6280,
Clustered Data ONTAP 8.1	FAS6210, FAS6240, FAS6280, V6210, V6240, V6280,
7-Mode 8.1	FAS6210, FAS6240, FAS6280, SA620, V6210, V6240, V6280,
Clustered Data ONTAP 8.0.5	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, V6210, V6220, V6240, V6250, V6280, V6290,
7-Mode 8.0.5	FAS6210, FAS6220, FAS6240, FAS6250, FAS6280, FAS6290, SA620, V6210, V6220, V6240, V6250, V6280, V6290,
Clustered Data ONTAP 8.0.4	FAS6210, FAS6240, FAS6280, V6210, V6240, V6280,
7-Mode 8.0.4	FAS6210, FAS6240, FAS6280, SA620, V6210, V6240, V6280,
Clustered Data ONTAP 8.0.4RC1	FAS6210, FAS6240, FAS6280, V6210, V6240, V6280,
7-Mode 8.0.4RC1	FAS6210, FAS6240, FAS6280, SA620, V6210, V6240, V6280,
Clustered Data ONTAP 8.0.3	FAS6210, FAS6240, FAS6280, V6210, V6240, V6280,
7-Mode 8.0.3	FAS6210, FAS6240, FAS6280, SA620, V6210, V6240, V6280,
Clustered Data ONTAP 8.0.2	FAS6210, FAS6240, FAS6280, V6210, V6240, V6280,
7-Mode 8.0.2	FAS6210, FAS6240, FAS6280, SA620, V6210, V6240, V6280,
Clustered Data ONTAP 8.0.1	FAS6210, FAS6240, FAS6280, V6210, V6240, V6280,
7-Mode 8.0.1	FAS6210, FAS6240, FAS6280, SA620, V6210, V6240, V6280,
