Supported Drives
Part Number | Encryption | Capacity | RPM | Checksum |
---|---|---|---|---|
Drive Type: NL-SAS | ||||
X309A-R6[1] | Yes | 3TB | 7.2k | BCS |
X315A-R6[1] | Yes | 4TB | 7.2k | BCS |
X316A-R6 | No | 6TB | 7.2k | BCS |
X317A[1] | Yes | 6TB | 7.2k | BCS |
X318A-R6 | No | 8TB | 7.2k | BCS |
X322A[1] | Yes | 10TB | 7.2k | BCS |
X336A-R6 | No | 4TB | 7.2k | BCS |
X380A | No | 10TB | 7.2k | BCS |
X477A-R6 | No | 4TB | 7.2k | BCS |
Drive Type: SAS | ||||
X488A-R5 | No | 900GB | 10k | BCS |
X489A-R6 | No | 1.2TB | 10k | BCS |
X490A-R6 | No | 1.8TB | 10k | BCS |
Drive Type: SATA | ||||
X302A-R5 | No | 1TB | 7.2k | BCS |
X306A-R5 | No | 2TB | 7.2k | BCS |
X308A-R5 | No | 3TB | 7.2k | BCS |
Drive Type: SSD | ||||
X363A-R6 | No | 3.84TB | N/A | BCS |
X366A-R6[1] | Yes | 1.6TB | N/A | BCS |
X374A | No | 960GB | N/A | BCS |
X441A-R5 | No | 100GB | N/A | BCS |
X442A-R5[2] | No | 100GB | N/A | BCS |
X448A-R6 | No | 200GB | N/A | BCS |
X449A-R6 | No | 800GB | N/A | BCS |
X575A-R6 | No | 400GB | N/A | BCS |
X576A-R6 | No | 1.6TB | N/A | BCS |
X577A-R6[1] | Yes | 800GB | N/A | BCS |
Footnotes | ||||
[1] Mixing NSE drives or shelves with any other type of encrypting or non-encrypting drives or shelves across a stand-alone platform or high-availability (HA) pair is not supported. [2] This drive does not support the sanitization feature. |
Supported Shelf Modules for NetApp DS4246
Module | Part Number | Interface | Max Data Rate | Min ONTAP |
---|---|---|---|---|
IOM12 | X5720A | IN: miniSAS HD, OUT: miniSAS HD | 12 Gbps | 9.11.1RC1, 9.10.1RC1, 9.9.1RC1, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1 |
Module | Part Number | Interface | Max Data Rate | Min ONTAP |
---|---|---|---|---|
IOM6 | X5713A-R6 | IN: QSFP, OUT: QSFP | 6 Gbps | 9.11.1RC1, 9.10.1RC1, 9.9.1RC1, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.2RC1, 8.1, 8.0.2, 7.3.4 |
Cables Compatibility for Module IOM12
Cables Compatibility for Module IOM6
Mktg Part No | Mfg Part No | Length | End 1 / End 2 | Description | Supported Speed(s) | Min OS |
---|---|---|---|---|---|---|
SAS 6/12 Gbps (Copper Cables) | ||||||
NetApp Cable X66030A | 112-00435 | 0.5m | MiniSAS HD / MiniSAS HD | Cable,miniSAS HD/miniSAS HD,0.5m | 6/12 Gbps | - |
NetApp Cable X66020A-R6 | 112-00429 | 1m | MiniSAS HD / QSFP | Cable,Storage,MiniSAS HD/QSFP,12Gb,1m | 6/12 Gbps | - |
NetApp Cable X66031A | 112-00436 | 1m | MiniSAS HD / MiniSAS HD | Cable,miniSAS HD/miniSAS HD,1m | 6/12 Gbps | - |
NetApp Cable X66021A-R6 | 112-00430 | 2m | MiniSAS HD / QSFP | Cable,Storage,MiniSAS HD/QSFP,12Gb,2m | 6/12 Gbps | - |
NetApp Cable X66032A | 112-00437 | 2m | MiniSAS HD / MiniSAS HD | Cable,miniSAS HD/miniSAS HD,2m | 6/12 Gbps | - |
NetApp Cable X66033A | 112-00438 | 3m | MiniSAS HD / MiniSAS HD | Cable,miniSAS HD/miniSAS HD,3m | 6/12 Gbps | - |
NetApp Cable X66022A-R6 | 112-00431 | 5m | MiniSAS HD / QSFP | Cable,Storage,MiniSAS HD/QSFP,12Gb,5m | 6/12 Gbps | - |
NetApp Cable X66034A | 112-00439 | 5m | MiniSAS HD / MiniSAS HD | Cable,miniSAS HD/miniSAS HD,5m | 6/12 Gbps | - |
SAS 6/12 Gbps (Optical Cable) | ||||||
Optical Cables | ||||||
NetApp Cable X66040A | 112-00449 | 1m | MiniSAS HD / MiniSAS HD | Cable,miniSAS HD/miniSAS HD,AOC,1m | 12 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1 |
NetApp Cable X66041A | 112-00450 | 2m | MiniSAS HD / MiniSAS HD | Cable,miniSAS HD/miniSAS HD,AOC,2m | 12 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1 |
NetApp Cable X66042A | 112-00451 | 3m | MiniSAS HD / MiniSAS HD | Cable,miniSAS HD/miniSAS HD,AOC,3m | 12 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1 |
NetApp Cable X66043A | 112-00452 | 5m | MiniSAS HD / MiniSAS HD | Cable,miniSAS HD/miniSAS HD,AOC,5m | 12 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1 |
NetApp Cable X66047A | 112-00456 | 5m | MiniSAS HD / 4xLC | Cable,Opt,miniSAS HD/LC,OM4,5m | 12 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1 |
NetApp Cable X66044A | 112-00453 | 15m | MiniSAS HD / MiniSAS HD | Cable,miniSAS HD/miniSAS HD,AOC,15m | 12 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1 |
NetApp Cable X66045A | 112-00454 | 30m | MiniSAS HD / MiniSAS HD | Cable,miniSAS HD/miniSAS HD,AOC,30m | 12 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1 |
NetApp Cable X66048A | 112-00457 | 30m | MiniSAS HD / 4xLC | Cable,Opt,miniSAS HD/LC,OM4,30m | 12 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1 |
NetApp Cable X66046A | 112-00455 | 50m | MiniSAS HD / MiniSAS HD | Cable,miniSAS HD/miniSAS HD,AOC,50m | 12 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1 |
Mktg Part No | Mfg Part No | Length | End 1 / End 2 | Description | Supported Speed(s) | Min OS |
---|---|---|---|---|---|---|
Ethernet 10/100 Mbps (Copper Cables) | ||||||
NetApp Cable X6560-R6 | 112-00194 | 0.5m | RJ45 / RJ45 | Cable,Ethernet,CAT6,RJ45,0.5m | - | |
NetApp Cable X6584-R6 | 112-00290 | 1m | RJ45 / RJ45 | Cable,Ethernet,CAT6,RJ45,1m | - | |
NetApp Cable X6561-R6 | 112-00195 | 2m | RJ45 / RJ45 | Cable,Ethernet,CAT6,RJ45,2m | - | |
NetApp Cable X6585-R6 | 112-00291 | 3m | RJ45 / RJ45 | Cable,Ethernet,CAT6,RJ45,3m | - | |
NOFRU_ETH_CAT6_RJ45_5M | ||||||
NetApp Cable X6562-R6 | 112-00196 | 5m | RJ45 / RJ45 | Cable,Ethernet,CAT6,RJ45,5m | - | |
NetApp Cable X6592-R6 | 112-00246 | 10m | RJ45 / RJ45 | Cable,Ethernet,CAT6,RJ45,10m | - | |
NetApp Cable X6593-R6 | 112-00247 | 20m | RJ45 / RJ45 | Cable,Ethernet,CAT6,RJ45,20m | - | |
NetApp Cable X6577-R6 | 112-00238 | 30m | RJ45 / RJ45 | Cable,Ethernet,CAT6,RJ45,30m | - | |
SAS 3/6 Gbps (Copper Cables) | ||||||
NetApp Cable X6557-R6 | 112-00176 | 0.5m | QSFP / QSFP | Cable,SAS Cntlr-Shelf/Shelf-Shelf/HA,0.5m | 3/6 Gbps | - |
NetApp Cable X66020A-R6 | 112-00429 | 1m | MiniSAS HD / QSFP | Cable,Storage,MiniSAS HD/QSFP,12Gb,1m | 6 Gbps | - |
NetApp Cable X6594-R6 | 112-00256 | 1m | QSFP / QSFP | Cable,SAS Cntlr-Shelf/Shelf-Shelf/HA,1m | 3/6 Gbps | - |
NetApp Cable X66021A-R6 | 112-00430 | 2m | MiniSAS HD / QSFP | Cable,Storage,MiniSAS HD/QSFP,12Gb,2m | 6 Gbps | - |
NetApp Cable X6558-R6 | 112-00177 | 2m | QSFP / QSFP | Cable,SAS Cntlr-Shelf/Shelf-Shelf/HA,2m | 3/6 Gbps | - |
NetApp Cable X6595-R6 | 112-00255 | 3m | QSFP / QSFP | Cable,SAS Cntlr-Shelf/Shelf-Shelf/HA,3m | 3/6 Gbps | - |
NetApp Cable X66022A-R6 | 112-00431 | 5m | MiniSAS HD / QSFP | Cable,Storage,MiniSAS HD/QSFP,12Gb,5m | 6 Gbps | - |
NetApp Cable X6559-R6 | 112-00178 | 5m | QSFP / QSFP | Cable,SAS Cntlr-Shelf/Shelf-Shelf/HA,5m | 3/6 Gbps | - |
NetApp Cable X6590-R6 | 112-00242 | 10m | QSFP / QSFP | Cable,SAS Cntlr-Shelf/Shelf-Shelf,Active,10m | 3/6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.2RC1, 8.1, 8.0.2, 7.3.5.1 |
NetApp Cable X6591-R6 | 112-00243 | 20m | QSFP / QSFP | Cable,SAS Cntlr-Shelf/Shelf-Shelf,Active,20m | 3/6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.2RC1, 8.1, 8.0.2, 7.3.5.1 |
SAS 3/6 Gbps (Optical Cables) | ||||||
Optical Transceiver X65400A-R6 with Supported Cables | ||||||
NetApp Cable X65400A-R6 | 332-00335, AFBR-79EQDZ-NA1, FTL410QE2C-N1, FTL410QE4C-N1, FTL410QL1C-N1 | XCVR | QSFP / MPO | XCVR,QSFP,Opt,6Gb,SAS | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
Optical Cables | ||||||
NetApp Cable X66000A-R6 | 112-00265 | 1m | QSFP / QSFP | Cable,SAS-OM4,Cntlr-Shelf/Shelf-Shelf,QSFP,1m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
NetApp Cable X66001A-R6 | 112-00266 | 2m | QSFP / QSFP | Cable,SAS-OM4,Cntlr-Shelf/Shelf-Shelf,QSFP,2m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
NetApp Cable X66002A-R6 | 112-00267 | 3m | QSFP / QSFP | Cable,SAS-OM4,Cntlr-Shelf/Shelf-Shelf,QSFP,3m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
NetApp Cable X66003A-R6 | 112-00268 | 5m | QSFP / QSFP | Cable,SAS-OM4,Cntlr-Shelf/Shelf-Shelf,QSFP,5m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
NetApp Cable X66008A-R6 | 112-00260 | 5m | QSFP / 4xLC | Cable,Cntlr/Shelf-PatchP,OM4,QSFP-LC,5m | 6 Gbps | - |
NetApp Cable X66010A-R6 | 112-00263 | 5m | QSFP / 2xSC | Cable,Cntlr/Shelf-PatchP,OM4,QSFP-SC,5m | 6 Gbps | - |
NetApp Cable X66012A-R6 | 112-00278 | 5m | QSFP / 4xMT-RJ | Cable,Cntlr/Shelf-PatchP,OM4,QSFP/MTRJ,5m | 6 Gbps | - |
NetApp Cable X66014A-R6 | 112-00272 | 5m | QSFP / 8x Simplex LC | Cable,Cntlr/Shelf-PatchP,OS1,QSFP/LC,5m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
NetApp Cable X66016A-R6 | 112-00274 | 5m | QSFP / 8x Simplex SC | Cable,Cntlr/Shelf-PatchP,OS1,QSFP/SC,5m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
NetApp Cable X66018A-R6 | 112-00281 | 5m | QSFP / 4xMT-RJ | Cable,Cntlr/Shelf-PatchP,OS1,QSFP/MTRJ,5m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
NetApp Cable X66004A-R6 | 112-00269 | 7m | QSFP / QSFP | Cable,SAS-OM4,Cntlr-Shelf/Shelf-Shelf,QSFP,7m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
NetApp Cable X66005A-R6 | 112-00270 | 15m | QSFP / QSFP | Cable,SAS-OM4,Cntlr-Shelf/Shelf-Shelf,QSFP,15m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
NetApp Cable X66011A-R6 | 112-00264 | 30m | MPO / 4xSC | Cable,Cntlr/Shelf-PatchP,OM4,QSFP-SC,30m | 6 Gbps | - |
NetApp Cable X66006A-R6 | 112-00271 | 30m | QSFP / QSFP | Cable,SAS-OM4,Cntlr-Shelf/Shelf-Shelf,QSFP,30m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
NetApp Cable X66009A-R6 | 112-00261 | 30m | QSFP / 4xLC | Cable,Cntlr/Shelf-PatchP,OM4,QSFP-LC,30m | 6 Gbps | - |
NetApp Cable X66013A-R6 | 112-00279 | 30m | QSFP / 4xMT-RJ | Cable,Cntlr/Shelf-PatchP,OM4,QSFP/MTRJ,30m | 6 Gbps | - |
NetApp Cable X66015A-R6 | 112-00273 | 30m | QSFP / 8x Simplex LC | Cable,Cntlr/Shelf-PatchP,OS1,QSFP/LC,30m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
NetApp Cable X66017A-R6 | 112-00276 | 30m | QSFP / 8x Simplex SC | Cable,Cntlr/Shelf-PatchP,OS1,QSFP/SC,30m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
NetApp Cable X66019A-R6 | 112-00282 | 30m | QSFP / 4xMT-RJ | Cable,Cntlr/Shelf-PatchP,OS1,QSFP/MTRJ,30m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
NetApp Cable X66007A-R6 | 112-00280 | 50m | QSFP / QSFP | Cable,SAS-OM4,Cntlr-Shelf/Shelf-Shelf,QSFP,50m | 6 Gbps | 9.11.1RC1, 9.11.0, 9.10.1RC1, 9.10.0, 9.9.1RC1, 9.9.0, 9.8RC1, 9.7RC1, 9.6RC1, 9.5RC1, 9.4RC1, 9.3RC1, 9.2RC1, 9.1RC1, 9.0RC1, 8.3RC1, 8.1.3RC1, 8.2.1RC1 |
Supported Power Cords for NetApp DS4246
Marketing Part No. | End 1 / End 2 | Length | Description | |
---|---|---|---|---|
Non-Cabinet Power Cords | ||||
X800B-R6 | CEE 7/7 (Schuko) / IEC60320-C13 | 2.50 m | Pwr Cord,Non-Cabinet,Cont Europe/Korea,10A/250V | |
X800C-R6 | BS1363 / IEC60320-C13 | 2.50 m | Pwr Cord,Non-Cabinet,UK/Ireland,10A/250V | |
X800D-R6 | JIS-C-8303 / IEC60320-C13 | 1.83 m | Pwr Cord,Non-Cabinet,Japan,15A/125V | |
X800E-R6 | NEMA 5-15P / IEC60320-C13 | 1.83 m | Pwr Cord,Non-Cabinet,North America,15A/125V | |
X800F-R6 | AS/NZS 3112 / IEC60320-C13 | 2.50 m | Pwr Cord,Non-Cabinet,Aus/NZ,10A/250V | |
X800G-R6 | SEV 1011 / IEC60320-C13 | 2.50 m | Pwr Cord,Non-Cabinet,Switzerland,10A/250V | |
X800H-R6 | IRAM 2073 / IEC60320-C13 | 2.50 m | Pwr Cord,Non-Cabinet,Argentina,10A/250V | |
X800I-R6 | GB2099 / IEC60320-C13 | 2.50 m | Pwr Cord,Non-Cabinet,China,10A/250V | |
X800J-R6 | DHCR107-2-D1 / IEC60320-C13 | 2.50 m | Pwr Cord,Non-Cabinet,Demark,10A/250V | |
X800K-R6 | SANS 164-1 / IEC60320-C13 | 2.50 m | Pwr Cord,Non-Cabinet,India/S.Africa,10A/250V | |
X800L-R6 | SI32 / IEC60320-C13 | 2.50 m | Pwr Cord,Non-Cabinet,Israel,10A/250V | |
X800M-R6 | CEI 23-16 / IEC60320-C13 | 2.50 m | Pwr Cord,Non-Cabinet,Italy,10A/250V | |
X800P-R6 | NEMA 6-15P / IEC60320-C13 | 1.83 m | Pwr Cord,Non-Cabinet,North America,15A/250V | |
X800T-R6 | CNS 10917-3 / IEC60320-C13 | 2.50 m | Pwr Cord,Non-Cabinet,Taiwan,BSMI,15A/125V | |
X800VB-R6 | NBR14136 / IEC60320-C13 | 2.50 m | Pwr Cord,Non-Cabinet,Brazil,10A/250V | |
X800W-R6 | CNS10917/CNS690 / IEC60320-C13 | 1.83 m | Pwr Cord,Non-Cabinet,Taiwan,10A/250V | |
X800Y-R6 | JIS-C-830 / IEC60320-C13 | 1.83 m | Pwr Cord,Non-Cabinet,Japan,15A/250V | |
In-Cabinet Power Cords | ||||
X1558A-R6 | IEC60320-C14 / IEC60320-C13 | 1.20 m | Pwr Cord,In-Cabinet,48-In,C13-C14,10A/250V | |
X800-42U-35 | IEC60320-C14 / IEC60320-C13 | 0.89 m | Pwr Cord,In-Cabinet,C13-C14,35-inch | |
X800-42U-43 | IEC60320-C14 / IEC60320-C13 | 1.09 m | Pwr Cord,In-Cabinet,C13-C14,43-inch | |
X800-42U-64 | IEC60320-C14 / IEC60320-C13 | 1.63 m | Pwr Cord,In-Cabinet,C13-C14,64-inch | |
X800-42U-R6 | IEC60320-C14 / IEC60320-C13 | 0.68 m | Pwr Cord,In-Cabinet,27-In,C13-C14,10A/250V |
Supported Rail Kits for NetApp DS4246
Footnote: DS4243/4246 2-post Telco mid-mount bracket is only available in X5525A-R6
Marketing Part No. | Manufacturing Part No. | Description | |
---|---|---|---|
NetApp System Cabinet Rail Kits | |||
X877B-R6 | 111-00596 | Rail Kit II, NetApp Cabinet, R6 | |
X8783A-R6 | 111-01110 | Rail Kit III, NetApp Cabinet, R6 | |
X87880A | 111-03887 | Rail Kit 4,Cabinet | |
Third-Party Cabinet Rail Kits | |||
X-02659-00 | 113-00232 | Kit,4-Post,Square or Round-Hole, 24"-32" Rail | |
X5515A-R6 [1] | 111-00232 | Kit,2-Post (Round) or 4-Post (Square), 24"-32" Rail | |
X5525A-R6 [1] | 111-00583 | Kit,2-Post,Round-Hole | |
X5526A-R6 | 111-00593 | Kit,4-Post.Square-Hole, 24"-32" Rail | |
X5529A-R6 | 111-00310 | Kit,4-Post,Swift,Square-Hole, 24"-32" Rail |
Marketing Part No. | Manufacturing Part No. | Description |
---|
Field Replacement Unit Parts for NetApp DS4246
Marketing Part No. | Manufacturing Part No. | Description | |
---|---|---|---|
Cabinets | |||
X870F-C | - | Cabinet,1280mm,Empty,No PDU,No Rails,-C | |
X870F-N-C | - | Cab,1280mm,Empty,No PDU,No Rails,-C | |
X870F-QS-C | - | Cabinet,1280mm,Empty,No PDU,No Rails,QS,-C | |
Chassis | |||
X5723A | 111-03068 | SHELF,EMPTY,2 PSU,913W,MIDPLANE II,DS212C | |
Conversion Kit | |||
X898A | TBD | DS212C, Kit,FAS2620 Conversion | |
Data Cable | |||
X66020A-R6 | 112-00429 | Cable,Storage,MiniSAS HD,QSFP,12G,1m | |
X66020A-R6-C | 112-00429 | Cable,Storage,MiniSAS HD,QSFP,12G,1m,-C | |
X66021A-R6 | 112-00430 | Cable,Storage,MiniSAS HD,QSFP,12G,2m | |
X66021A-R6-C | 112-00430 | Cable,Storage,MiniSAS HD,QSFP,12G,2m,-C | |
X66022A-R6 | 112-00431 | Cable,Storage,MiniSAS HD,QSFP,12G,5m | |
X66022A-R6-C | 112-00431 | Cable,Storage,MiniSAS HD,QSFP,12G,5m,-C | |
X66030A | 112-00435 | Cable,12Gb,Mini SAS HD,0.5m | |
X66030A-C | 112-00435 | Cable,12Gb,Mini SAS HD,0.5m,-C | |
X66030A-K-N | 112-00435 | Cable,12Gb,Mini SAS HD,0.5m | |
X66030A-N | 112-00435 | Cable,12Gb,Mini SAS HD,0.5m | |
X66030A-N-C | 112-00435 | Cable,12Gb,Mini SAS HD,0.5m,-C | |
X66031A | 112-00436 | Cable,12Gb,Mini SAS HD,1m | |
X66031A-C | 112-00436 | Cable,12Gb,Mini SAS HD,1m,-C | |
X66031A-K-N | 112-00436 | Cable,12Gb,Mini SAS HD,1m | |
X66031A-N | 112-00436 | Cable,12Gb,Mini SAS HD,1m | |
X66031A-N-C | 112-00436 | Cable,12Gb,Mini SAS HD,1m,-C | |
X66032A | 112-00437 | Cable,12Gb,Mini SAS HD,2m | |
X66032A-C | 112-00437 | Cable,12Gb,Mini SAS HD,2m,-C | |
X66032A-K-N | 112-00437 | Cable,12Gb,Mini SAS HD,2m | |
X66032A-N | 112-00437 | Cable,12Gb,Mini SAS HD,2m | |
X66032A-N-C | 112-00437 | Cable,12Gb,Mini SAS HD,2m,-C | |
X66033A | 112-00438 | Cable,12Gb,Mini SAS HD,3m | |
X66033A-C | 112-00438 | Cable,12Gb,Mini SAS HD,3m,-C | |
X66033A-K-N | 112-00438 | Cable,12Gb,Mini SAS HD,3m | |
X66033A-N | 112-00438 | Cable,12Gb,Mini SAS HD,3m | |
X66033A-N-C | 112-00438 | Cable,12Gb,Mini SAS HD,3m,-C | |
X66034A | 112-00439 | Cable,12Gb,Mini SAS HD,5m | |
X66034A-C | 112-00439 | Cable,12Gb,Mini SAS HD,5m,-C | |
X66034A-K-N | 112-00439 | Cable,12Gb,Mini SAS HD,5m | |
X66034A-N | 112-00439 | Cable,12Gb,Mini SAS HD,5m | |
X66034A-N-C | 112-00439 | Cable,12Gb,Mini SAS HD,5m,-C | |
X66040A | 112-00449 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,1m | |
X66040A-C | 112-00449 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,1m,-C | |
X66040A-K-N | 112-00449 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,1m | |
X66040A-N | 112-00449 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,1m | |
X66040A-N-C | 112-00449 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,1m,-C | |
X66041A | 112-00450 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,2m | |
X66041A-C | 112-00450 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,2m,-C | |
X66041A-K-N | 112-00450 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,2m | |
X66041A-N | 112-00450 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,2m | |
X66041A-N-C | 112-00450 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,2m,-C | |
X66042A | 112-00451 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,3m | |
X66042A-C | 112-00451 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,3m,-C | |
X66042A-K-N | 112-00451 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,3m | |
X66042A-N | 112-00451 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,3m | |
X66042A-N-C | 112-00451 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,3m,-C | |
X66043A | 112-00452 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,5m | |
X66043A-C | 112-00452 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,5m,-C | |
X66043A-K-N | 112-00452 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,5m | |
X66043A-N | 112-00452 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,5m | |
X66043A-N-C | 112-00452 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,5m,-C | |
X66044A | 112-00453 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,15m | |
X66045A | 112-00454 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,30m | |
X66046A | 112-00455 | Cable,12Gb,SAS Opt,AOC,Mini SAS HD,50m | |
X66047A | 112-00456 | Cable,12Gb,SAS Opt,Mini SAS HD to LC,5m | |
X66047A-C | 112-00456 | Cable,12Gb,SAS Opt,Mini SAS HD to LC,5m,-C | |
X66047A-N-C | 112-00456 | Cable,12Gb,SAS Opt,Mini SAS HD to LC,5m,-C | |
X66048A | 112-00457 | Cable,12Gb,SAS Opt,Mini SAS HD to LC,30m | |
X66048A-C | 112-00457 | Cable,12Gb,SAS Opt,Mini SAS HD to LC,30m,-C | |
X66048A-N-C | 112-00457 | Cable,12Gb,SAS Opt,Mini SAS HD to LC,30m,-C | |
Drive | |||
X302A-R5 | 108-00268 | Disk Drive,1.0TB 7.2k,DS424x,FAS2240-4 | |
X306A-R5 | 108-00270 | Disk Drive,2.0TB 7.2k,DS424x,2554/2240-4 | |
X308A-R5 | 108-00277 | Disk Drive,3.0TB 7.2K,DS424x,2554/2240-4 | |
X315A-R6 | 108-00368 | DSK DRV,4TB 7.2k,NSE,DS424x,2554/2220/2240-4 | |
X317A | 108-00399 | DSK DRV,6TB,7.2K,12G,NSE,DS212C | |
X318A-R6 | 108-00455 | DSK DRV,8TB,7.2K,12G,DS212C | |
X322A | 108-00551 | DSK DRV,10TB,7.2K,12G,NSE,DS212C | |
X336A-R6 | 108-00427 | DSK DRV,4TB,7.2K,12G,DS212C | |
X339A | 108-00426 | DSK DRV,2TB,7.2K,12Gb,DS212C,FAS2620 | |
X363A-R6 | 108-00467 | SSD,3.8TB,FAS2520/2554 | |
X364A | 108-00650 | SSD,3.8TB,DS212C,FAS2620,w/MSW | |
X366A-R6 | 108-00470 | SSD,1.6TB,NSE,DS4246,FAS2554 | |
X374A | 108-00573 | SSD,960GB,12G,DS212C,W/MSW | |
X380A | 108-00549 | DSK DRV,10TB,7.2K,12G,DS212C | |
X388A | 108-00885 | DSK DRV,16TB,7.2K,12G,DS212C | |
X448A-R6 | 108-00253 | SSD,200GB,DS4246,FAS2554/2240-4/2220 | |
X449A-R6 | 108-00319 | SSD,800GB,DS4246,FAS2554/2240-4/2220 | |
X477A-R6 | 108-00315 | DSK DRV,4TB 7.2k,DS4246,2554/2220/2240-4 | |
X488A-R5 | 108-00298 | Disk Drive,900GB 10K,2520/2220 | |
X489A-R6 | 108-00322 | Disk Drive,1.2TB 10K,2520/2220 | |
X490A-R6 | 108-00425 | Disk Drive,1.8TB 10K,FAS2520 | |
X575A-R6 | 108-00370 | SSD,400GB,DS424x,FAS2554/2240-4/2220 | |
X576A-R6 | 108-00373 | SSD,1.6TB,DS424x,FAS2554/2240-4/2220 | |
X577A-R6 | 108-00375 | SSD,800GB,NSE,DS4246,FAS2554 | |
Power Cord | |||
X-50617-00 | - | Jumper Crd,In-Cab,2m,C20-C13,E-Series | |
X-50617-00-0E-C | - | Jumper Crd,In-Cab,2m,C20-C13,E-Series,0E,-C | |
X1558A-R6 | - | Jumper Crd,In-Cab,48-IN,C13-C14 | |
X1558A-R6-C | - | Jumper Crd,In-Cab,48-IN,C13-C14-C | |
X800-42U-35 | - | Jumper Crd,In-Cab,C13-C14,35-inch | |
X800-42U-35-C | - | Jumper Crd,In-Cab,C13-C14,35-inch,-C | |
X800-42U-35-K-N | - | Jumper Crd,In-Cab,C13-C14,35-inch | |
X800-42U-35-N | - | Power Cable,In-Cabinet,C13-C14,35-inch | |
X800-42U-43 | - | Jumper Crd,In-Cab,C13-C14,43-inch | |
X800-42U-43-C | - | Jumper Crd,In-Cab,C13-C14,43-inch,-C | |
X800-42U-43-K-N | - | Jumper Crd,In-Cab,C13-C14,43-inch | |
X800-42U-43-N | - | Power Cable,In-Cabinet,C13-C14,43-inch | |
X800-42U-64 | - | Jumper Crd,In-Cab,C13-C14,64-inch | |
X800-42U-64-C | - | Jumper Crd,In-Cab,C13-C14,64-inch,-C | |
X800-42U-64-K-N | - | Jumper Crd,In-Cab,C13-C14,64-inch | |
X800-42U-64-N | - | Power Cable,In-Cabinet,C13-C14,64-inch | |
X800-42U-R6 | - | Jumper Crd,In-Cab,C13-C14 | |
X800-42U-R6-C | - | Jumper Crd,In-Cab,C13-C14,-C | |
X800B-R6 | - | Power Cable,Continental Europe,R6 | |
X800B-R6-C | - | Power Cable,Continental Europe,-C,R6 | |
X800C-R6 | - | Power Cable,UK and Ireland,R6 | |
X800C-R6-C | - | Power Cable,UK and Ireland,-C,R6 | |
X800D-R6 | - | Power Cable,Japan,R6 | |
X800D-R6-C | - | Power Cable,Japan,-C,R6 | |
X800E-R6 | - | Power Cable,North America,R6 | |
X800E-R6-C | - | Power Cable,North America,-C,R6 | |
X800F-R6 | - | Power Cable,Australia/New Zealand,R6 | |
X800F-R6-C | - | Power Cable,Australia/New Zealand,-C,R6 | |
X800G-R6 | - | Power Cable,Switzerland,R6 | |
X800G-R6-C | - | Power Cable,Switzerland,-C,R6 | |
X800H-R6 | - | Power Cable,Argentina,R6 | |
X800H-R6-C | - | Power Cable,Argentina,-C,R6 | |
X800I-R6 | - | Power Cable,China,R6 | |
X800I-R6-C | - | Power Cable,China,-C,R6 | |
X800J-R6 | - | Power Cable,Denmark,R6 | |
X800J-R6-C | - | Power Cable,Denmark,-C,R6 | |
X800K-R6 | - | Power Cable,India,South Africa,R6 | |
X800K-R6-C | - | Power Cable,India,South Africa,-C,R6 | |
X800L-R6 | - | Power Cable,Israel,R6 | |
X800L-R6-C | - | Power Cable,Israel,-C,R6 | |
X800M-R6 | - | Power Cable,Italy,R6 | |
X800M-R6-C | - | Power Cable,Italy,-C,R6 | |
X800N | - | POWER CABLE,INDIA BIS | |
X800N-C | - | Power Cable,India BIS,-C | |
X800P-R6 | - | Power Cable,North America,250V,R6 | |
X800P-R6-C | - | Power Cable,North America,250V,-C,R6 | |
X800T-R6 | - | Power Cable,Taiwan,BSMI,R6 | |
X800T-R6-C | - | Power Cable,Taiwan,BSMI,-C,R6 | |
X800VB-R6 | - | Power Cable,Brazil,IEC-60906-1-Plug | |
X800W-R6 | - | Power Cable,Taiwan,250V,BSMI,R6 | |
X800W-R6-C | - | Power Cable,Taiwan,250V,BSMI,-C | |
X800Y-R6 | - | Power Cable,Japan,250V/15A | |
X800Y-R6-C | - | Power Cable,Japan,250V/15A,-C | |
Power Supply Unit | |||
X5726A | 114-00148 | PSU,913W | |
RailKit | |||
X-02654-00 | 111-02852 | Rail Kit,Thin,Rnd/Sq-Hole,2-Post | |
X-02654-00-C | 111-02852 | Rail Kit,Thin,Rnd/Sq-Hole,2-Post,-C | |
X-02654-00-K-N | 111-02852 | Rail Kit,Thin,Rnd/Sq-Hole,2-Post | |
X-02654-00-N | 111-02852 | Rail Kit,Thin,Rnd/Sq-Hole,2-Post | |
X-02654-00-N-C | 111-02852 | Rail Kit,Thin,Rnd/Sq-Hole,2-Post | |
X-02657-00 | 111-02657 | Rackmount Kit,212C,4-post,Adj | |
X-02657-00-C | 111-02657 | Rail Kit,Thin,Rnd/Sq-Hole,4-Post,Adj,24-32,-C | |
X-02657-00-K-N | 111-02657 | Rackmount Kit,212C,4-post,Adj | |
X-02657-00-N | 111-02657 | Rackmount Kit,212C,4-post,Adj | |
X-02657-00-N-C | 111-02657 | Rail Kit,Thin,Rnd/Sq-Hole,4-Post,Adj,24-32,-C | |
Shelf Module | |||
X5720A | - | IOM12,SAS,12G |
Size, Weight, Acoustic, Power for NetApp DS4246
Associated Part No. | Configuration | Rack Units | Weight | Sound Power | Sound Pressure | Line Voltage Actual (Min to Max) | Amps Typical | Amps Worst | Watts Typical | Watts Worst | BTU / Hr Typical | BTU / Hr Worst |
---|---|---|---|---|---|---|---|---|---|---|---|---|
Empty Shelf (with AC PSU) | ||||||||||||
X5561A-R6 | shelf empty with 4x AC PSU | - | - | - | - | - | - | - | - | - | - | - |
X556B-R6 | shelf empty with 2x AC PSU | - | - | - | - | - | - | - | - | - | - | - |
Quickship Half Populated | ||||||||||||
DS4246-07-8-12B-QS | 12x8TB 7.2K NL-SAS | 4 | 66.4 lb (30.1 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 2.18 | 2.52 | 213 | 246 | 727 | 840 |
DS4246-07-8-12B-QS | 12x8TB 7.2K NL-SAS | 4 | 66.4 lb (30.1 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.07 | 1.24 | 209 | 242 | 714 | 826 |
DS4246-0712-12A-QS-R6 | 12x1.0TB 7.2K SATA | 4 | 61.7 lb (28.0 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 2.06 | 2.4 | 201 | 235 | 686 | 803 |
DS4246-0712-12A-QS-R6 | 12x1.0TB 7.2K SATA | 4 | 61.7 lb (28.0 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.01 | 1.18 | 197 | 231 | 673 | 789 |
DS4246-0724-12A-QS-R6 | 12x2.0TB 7.2K SATA | 4 | 61.7 lb (28.0 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 1.83 | 2.74 | 179 | 268 | 611 | 915 |
DS4246-0724-12A-QS-R6 | 12x2.0TB 7.2K SATA | 4 | 61.7 lb (28.0 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 0.9 | 1.35 | 176 | 263 | 601 | 898 |
DS4246-0736-12A-QS-R6 | 12x3.0TB 7.2K SATA | 4 | 62.6 lb (28.4 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 2.06 | 2.4 | 201 | 235 | 686 | 803 |
DS4246-0736-12A-QS-R6 | 12x3.0TB 7.2K SATA | 4 | 62.6 lb (28.4 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.01 | 1.18 | 197 | 231 | 673 | 789 |
DS4246-0748-12A-QS-R6 | 12x4.0TB 7.2K NL-SAS | 4 | 63.9 lb (29.0 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 2.14 | 2.48 | 209 | 243 | 714 | 830 |
DS4246-0748-12A-QS-R6 | 12x4.0TB 7.2K NL-SAS | 4 | 63.9 lb (29.0 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.05 | 1.22 | 205 | 239 | 700 | 816 |
DS4246-0772-12A-QS-R6 | 12x6.0TB 7.2K NL-SAS | 4 | 66.6 lb (30.2 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 2.16 | 2.49 | 211 | 244 | 721 | 833 |
DS4246-0772-12A-QS-R6 | 12x6.0TB 7.2K NL-SAS | 4 | 66.6 lb (30.2 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.06 | 1.23 | 207 | 240 | 707 | 820 |
Quickship Fully Populated | ||||||||||||
DS4246-07-.8-6-24M-QS | 20x6.0TB,NSE,4x800GB,NSE,Mixed | 4 | 85.1 lb (38.6 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 3.43 | 3.78 | 336 | 370 | 1147 | 1263 |
DS4246-07-.8-6-24M-QS | 20x6.0TB,NSE,4x800GB,NSE,Mixed | 4 | 85.1 lb (38.6 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.69 | 1.86 | 330 | 363 | 1127 | 1239 |
DS4246-07-.8-8-24M-QS | 20x8TB,NL-SAS,4x800GB,SSD,Mixed | 4 | 87.7 lb (39.8 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 3.47 | 3.82 | 340 | 374 | 1161 | 1277 |
DS4246-07-.8-8-24M-QS | 20x8TB,NL-SAS,4x800GB,SSD,Mixed | 4 | 87.7 lb (39.8 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.71 | 1.88 | 334 | 367 | 1140 | 1253 |
DS4246-07-6-24N-QS | 24x6.0TB,NSE | 4 | 92.8 lb (42.1 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 3.8 | 4.14 | 372 | 405 | 1270 | 1383 |
DS4246-07-6-24N-QS | 24x6.0TB,NSE | 4 | 92.8 lb (42.1 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.87 | 2.03 | 365 | 397 | 1246 | 1355 |
DS4246-07-8-24B-QS | 24x8TB 7.2K NL-SAS | 4 | 92.2 lb (41.8 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 3.85 | 4.19 | 377 | 410 | 1287 | 1400 |
DS4246-07-8-24B-QS | 24x8TB 7.2K NL-SAS | 4 | 92.2 lb (41.8 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.89 | 2.06 | 370 | 402 | 1263 | 1372 |
DS4246-0724-24A-QS-R6 | 24x1.0TB 7.2K SATA | 4 | 110.0 lb (49.9 kg) | 6.7 Bels | - | 100 (100 to 120) | 4.42 | 4.41 | 438 | 439 | 1495 | 1499 |
DS4246-0724-24A-QS-R6 | 24x1.0TB 7.2K SATA | 4 | 110.0 lb (49.9 kg) | 6.7 Bels | - | 200 (200 to 240) | 2.27 | 2.21 | 424 | 429 | 1448 | 1465 |
DS4246-0724-24A-QS-R6 | 24x1.0TB 7.2K SATA | 4 | 110.0 lb (49.9 kg) | 6.7 Bels | - | 215 (200 to 240) | 1.9 | 2.1 | 409 | 452 | 1396 | 1543 |
DS4246-0748-24A-QS-R6 | 24x2.0TB 7.2K SATA | 4 | 101.0 lb (45.8 kg) | 6.7 Bels | - | 100 (100 to 120) | 4.62 | 4.72 | 458 | 469 | 1561 | 1599 |
DS4246-0748-24A-QS-R6 | 24x2.0TB 7.2K SATA | 4 | 101.0 lb (45.8 kg) | 6.7 Bels | - | 200 (200 to 240) | 2.42 | 2.42 | 456 | 470 | 1554 | 1602 |
DS4246-0772-24A-QS-R6 | 24x3.0TB 7.2K SATA | 4 | 99.2 lb (45.0 kg) | 6.7 Bels | - | 100 (100 to 120) | 4.6 | 4.95 | 456 | 495 | 1557 | 1690 |
DS4246-0772-24A-QS-R6 | 24x3.0TB 7.2K SATA | 4 | 99.2 lb (45.0 kg) | 6.7 Bels | - | 200 (200 to 240) | 2.38 | 2.5 | 448 | 483 | 1529 | 1649 |
DS4246-0772-24N-QS-R6 | 24x3.0TB 7.2K NSE | 4 | 99.2 lb (45.0 kg) | 6.7 Bels | - | 100 (100 to 120) | 4.6 | 4.95 | 456 | 495 | 1557 | 1690 |
DS4246-0772-24N-QS-R6 | 24x3.0TB 7.2K NSE | 4 | 99.2 lb (45.0 kg) | 6.7 Bels | - | 200 (200 to 240) | 2.38 | 2.5 | 448 | 483 | 1529 | 1649 |
DS4246-0796-24A-QS-R6 | 24x4.0TB 7.2K NL-SAS | 4 | 87.5 lb (39.7 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 3.77 | 4.12 | 369 | 403 | 1260 | 1376 |
DS4246-0796-24A-QS-R6 | 24x4.0TB 7.2K NL-SAS | 4 | 87.5 lb (39.7 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.85 | 2.02 | 362 | 395 | 1236 | 1349 |
DS4246-0796-24N-QS-R6 | 24x4.0TB 7.2K NSE | 4 | 87.5 lb (39.7 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 3.77 | 4.12 | 369 | 403 | 1260 | 1376 |
DS4246-0796-24N-QS-R6 | 24x4.0TB 7.2K NSE | 4 | 87.5 lb (39.7 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.85 | 2.02 | 362 | 395 | 1236 | 1349 |
DS4246-07A1-24A-QS-R6 | 24x6.0TB 7.2K NL-SAS | 4 | 92.8 lb (42.1 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 3.8 | 4.14 | 372 | 405 | 1270 | 1383 |
DS4246-07A1-24A-QS-R6 | 24x6.0TB 7.2K NL-SAS | 4 | 92.8 lb (42.1 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.87 | 2.03 | 365 | 397 | 1246 | 1355 |
DS4246-18TB-24M-QS-R6 | 18x1.0TB,6x100GB,Mixed | 4 | 92.2 lb (41.8 kg) | 6.7 Bels | - | 100 (100 to 120) | 3.41 | 3.91 | 335 | 386 | 1144 | 1318 |
DS4246-18TB-24M-QS-R6 | 18x1.0TB,6x100GB,Mixed | 4 | 92.2 lb (41.8 kg) | 6.7 Bels | - | 200 (200 to 240) | 1.84 | 2.11 | 331 | 388 | 1130 | 1325 |
DS4246-40TB-24M-QS-R6 | 20x2.0TB,4x200GB,Mixed | 4 | 80.3 lb (36.4 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 3.23 | 3.58 | 316 | 350 | 1079 | 1195 |
DS4246-40TB-24M-QS-R6 | 20x2.0TB,4x200GB,Mixed | 4 | 80.3 lb (36.4 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.59 | 1.75 | 310 | 343 | 1058 | 1171 |
DS4246-54TB-24M-QS-R6 | 18x3.0TB,6x100GB,Mixed | 4 | 92.2 lb (41.8 kg) | 6.7 Bels | - | 100 (100 to 120) | 3.72 | 4.11 | 368 | 406 | 1256 | 1386 |
DS4246-54TB-24M-QS-R6 | 18x3.0TB,6x100GB,Mixed | 4 | 92.2 lb (41.8 kg) | 6.7 Bels | - | 200 (200 to 240) | 2.14 | 2.25 | 397 | 418 | 1355 | 1427 |
DS4246-80TB-24M-QS-R6 | 20x4.0TB,4x200GB,Mixed | 4 | 83.8 lb (38.0 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 3.37 | 3.71 | 330 | 363 | 1127 | 1239 |
DS4246-80TB-24M-QS-R6 | 20x4.0TB,4x200GB,Mixed | 4 | 83.8 lb (38.0 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.66 | 1.82 | 324 | 356 | 1106 | 1215 |
DS4246-S-1.6-6-24N-QS | 20x6TB,NL-SAS,NSE,4x1.6TB,SSD,NSE,Mixed | 4 | 88.2 lb (40.0 kg) | 6.9 Bels | 49.6 dBA | 100 (100 to 120) | 3.41 | 3.75 | 334 | 367 | 1140 | 1253 |
DS4246-S-1.6-6-24N-QS | 20x6TB,NL-SAS,NSE,4x1.6TB,SSD,NSE,Mixed | 4 | 88.2 lb (40.0 kg) | 6.9 Bels | 49.6 dBA | 200 (200 to 240) | 1.68 | 1.84 | 328 | 360 | 1120 | 1229 |
DS4246-SL001-24M-QS-R6 | 20x2.0TB,4x400GB,Mixed | 4 | 92.2 lb (41.8 kg) | - | - | 100 (100 to 120) | 3.2 | 3.5 | 315 | 353 | 1075 | 1204 |
DS4246-SL001-24M-QS-R6 | 20x2.0TB,4x400GB,Mixed | 4 | 92.2 lb (41.8 kg) | - | - | 200 (200 to 240) | 1.61 | 1.67 | 302 | 312 | 1030 | 1064 |
DS4246-SL002-24M-QS-R6 | 20x4.0TB,4x400GB,Mixed | 4 | 92.2 lb (41.8 kg) | - | - | 100 (100 to 120) | 3.5 | 3.6 | 340 | 360 | 1160 | 1228 |
DS4246-SL002-24M-QS-R6 | 20x4.0TB,4x400GB,Mixed | 4 | 92.2 lb (41.8 kg) | - | - | 200 (200 to 240) | 1.7 | 1.8 | 311 | 345 | 1061 | 1177 |
DS4246-SL003-24M-QS-R6 | 20x6.0TB,4x400GB,Mixed | 4 | 95.7 lb (43.4 kg) | - | - | 100 (100 to 120) | 3.4 | 3.71 | 338 | 367 | 1153 | 1251 |
DS4246-SL003-24M-QS-R6 | 20x6.0TB,4x400GB,Mixed | 4 | 95.7 lb (43.4 kg) | - | - | 200 (200 to 240) | 1.72 | 1.83 | 333 | 357 | 1136 | 1217 |
