Specs
-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.
Comes with:
- Processors - 1 x 4314 (16-Core, 2.4 GHz, 135W)
- Memory - 32 GB RDIMM 2R 3200 MT/s (1x 32 GB) & 31 DIMM blanks
- Network Controller - Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T CP3
Adapter for HPE
Notes: No embedded networking
- Storage Controller - P408i-a/2GB with Smart Storage Battery
- Backplane - 8SFF 12G x1 SAS UBM2 BC
- Hard Drive - None included
- Internal Storage - 8 SFF
- Optical Drive Bay - Not included (Optical Drive options available)
- PCIe Slots - 2 PCIe: 1 x16 FH / 1 x8 LP
- Power Supply - 1x 800W
- Fans - 5 - Standard
- Management - HPE iLO 5
- Security - TPM (Trusted Platform Module)
- Energy Start - Energy Star 2.1
- Form Factor - Rack (1U), Easy Install w/o CMA
Looking to Customize?
Not seeing the exact specs you need?
Start your build today with Express Computer Systems!
Start Customizing Today!
Spec Sheet 4
| Technical specifications | HPE ProLiant DL360 Gen10 Plus server |
|---|---|
| Processor name | 3rd Generation Intel® Xeon® Scalable Processor Family |
| Processor family | Intel® Xeon® Scalable 8300 series Intel® Xeon® Scalable 6300 series |
| Processor core available | 4 to 28 core, depending on model |
| Processor cache | 12 - 60 MB L3, depending on processor |
| Processor speed | 3.6 GHz, maximum depending on processor |
| Expansion slots | Maximum 3 PCIe Gen4, for detail descriptions please see QuickSpecs |
| Maximum memory | 6.0 TB per socket, when populated with 256 GB DDR4 and 512 GB Persistent Memory |
| Memory, standard | 4 TB (16x 256 GB) RDIMM per socket 6 TB (8x 256 GB RDIMM and 8x 512 GB Persistent Memory) per socket, depending on processor model |
| Memory slots | 16 DIMM slots per socket = 32 Total |
| Persistent memory type | Optional: Intel® Optane™ Persistent Memory for HPE |
| Persistent memory media capacity | Optional: 128 to 256 GB |
| Memory type | HPE DDR4 SmartMemory |
| Memory protection features | HPE Fast Fault Tolerant Memory Advanced ECC Memory Online Spare Memory Mirrored Memory |
| Network controller | Wide range of speeds, cabling, chipsets and form factors. Please see QuickSpecs for network card choices |
| Storage controller | Included - Embedded SATA controller (AHCI or SR100i modes) Optional - Variety of protocols -including NVMe-, port count, array utilities, and form factors. Please see QuickSpecs for storage controllers selection |
| Product Dimensions (imperial) | SFF: 1.69 x 17.11 x 30.30 in LFF: 1.69 x 17.11 x 31.50 in |
| Weight | SFF: 28.74 lb to 35.86 lb LFF: 30.36 lb to 37.00 lb |
| Infrastructure management | Included - HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires
download) Optional - HPE iLO Advanced, and HPE OneView Advanced |
| Drive supported |
|
