SKU: P28702-B21
HPE Apollo 4200 Gen10 Plus 4Lff Sas/Sata Lp Drive Cage 3 Upgrade Kit | P28702-B21
Contact For Pricing
Thanks for the request. We'll get back to you with in 24 hours.
-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.
Drive Cage Specs
The 4LFF Drive Cage 3 can only be installed in 24LFF CTO SKU (P28700-B21).
The Drive Cage 3 cannot be installed with processors over 165W, Intel DC Persistent Memory DIMMs, 256GB LRDIMM, or GPU.
One of the Drive Cage 3 Cables and Controller mode must be selected when any Drive Cage 3 Upgrade SKU is selected.
HPE Apollo 4200 Gen10 Plus 4LFF Cage 3 Type-p Controller Cable Kit P43539-B21
Notes: When this SKU is selected, four LFF bays in Cage 3 are connect to one i-p SAS/SATA controller. It requires one dedicated SAS/SATA controller to be installed
HPE Apollo 4200 4LFF Cage 3 to Cage 2 P3 FIO Controller Mode P43619-B21>hr>Notes: When this SKU is selected, four LFF bays are connect to Drive Cage 2 Expander.
Compatible With:
- HPE Apollo 4200 plus
(Click to View)
