-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.
Quick Specs
DL380 Gen10 Notes:
- − Max Qty = 2
- − This GPU requires Pwr Cable Kit (871829-B21) to also be selected.
- − This option requires the High Performance Fan Kit (867810-B21) to be selected
- − This option requires the selection of the High Performance Heatsink (826706-B21)
- − Not supported on 12LFF Model-X
- − Only supported with 2 nd generation processors
- − Requires selection of HPE DL380 Gen10 Pri/Sec Rsr w/o Retainer (P38515-B21) and/or HPE DL380 Gen10 Tert Riser w/o Retainer (P38517-B21). Selection is based on quantity of Graphics Option selected
- − This option cannot be selected if more than 8NVMe Drives are selected.
DL380 Gen10 Plus Notes:
- − Max = 3
- − This GPU requires Pwr Cable Kit (P39102-B21) to also be selected.
- − This option requires the Max Performance Fan Kit (P14608-B21) to be selected.
- − This option requires the selection of the High Performance Heatsink (P27095-B21)
- − Max of 8 NVMe Drives allowed for selection with this Graphics Option (All NVMe Drives selected must be below 11W).
- − This Graphics option and SAS4 Drives cannot be selected together.
- − If Qty 1 of this GPU is selected, then Qty 1 of PRI/SEC wo Retainer Kit (P38771-B21) must be selected.
- − Graphics Option and 40Gb or above PCIe Networking/ Infiniband/ Smart IO (HW) Cards cannot be selected together.
- − This option cannot be selected with 12LFF Model X.
HPE DL380 Gen 11 Notes:
- − Max = 3
- − System memory should be 2x of GPU memory.
- − This GPU requires Pwr Cable Kit (P39102-B21) to also be selected.
- − This GPU requires HPE DL380/DL560 G11 2U High Perf Fan Kit P48820-B21.
Compatible With:
- HPE DL380
- HPE Proliant DL380
(Click to View)
