-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.
Building on HPE ProLiant as the intelligent foundation for hybrid cloud, the HPE ProLiant DL365 Gen10 Plus server offers the 3rd Generation AMD EPYC™ Processors, delivering increased compute performance in a 1U rack profile. With up to 128 cores (per 2-socket configuration), 32 DIMMs for memory up to 3200 MHz, the HPE ProLiant DL365 Gen10 Plus server delivers low- cost virtual machines (VMs) with increased security. Equipped with PCIe Gen4 capabilities, the HPE ProLiant DL365 Gen10 Plus server offers improved data transfer rates and higher networking speeds. Combined with a better balance of processor cores, memory, and I/O, the HPE ProLiant DL365 Gen10 Plus server is the ideal choice for Virtual Desktop Infrastructure.
What’s New for DL365 Gen10 Plus
- Increase compute performance with two processors in a single rack unit enclosure.
- Powered by the 3rd Generation AMD EPYC™ Processors with more compute performance compared to the previous generation.
- Enhanced storage management with Tri-mode storage controllers supporting
NVMe/SAS/SATA drives. - Supports 3rd Generation AMD EPYC™ processors with 3D V-cache, providing 768 MB of L3 cache per processor.
Workload Optimization
Harness major compute power: The HPE ProLiant DL365 Gen10 Plus server supports the 3rd Generation AMD EPYC™ processors with up to 64-core 280W.It provides up to 128 lanes of PCIe Gen4 improves I/O throughput and reduces latency.
Tri-mode storage controllers enhance storage management coupled with an advanced storage RAID solution.
It provides real-time operational feedback on server performance plus recommendations for fine-tuning BIOS settings to customize for changing business needs.
Know your Server - CTO Configuration Support
Need help with the configuration? Contact us today!
Spec Sheet 4
| Technical specifications | HPE ProLiant DL360 Gen10 server |
|---|---|
| Processor name | Intel |
| Processor family | Intel® Xeon® Scalable 8100/8200 series - Intel® Xeon® Scalable 3100/3200 series |
| Number of processors | 2, maximum depending on model |
| Processor core available | 4 to 28 core, depending on model |
| Processor cache | 8.25 - 38.50 MB L3, depending on processor |
| Processor speed | 3.9 GHz, maximum depending on processor |
| Expansion slots | 3, for detailed descriptions refer to the QuickSpecs |
| Maximum memory | 3.0 TB with 128 GB DDR4 6.0 TB with HPE 512GB 2666 Persistent Memory Kit |
| Memory, standard | 3.0 TB (24 X 128 GB) LRDIMM 6.0 TB (12 X 512 GB) HPE Persistent Memory |
| Memory slots | 24 DIMM slots |
| Memory type | HPE DDR4 SmartMemory and Intel® Optane™ persistent memory 100 series for HPE, depending on model |
| System fan features | Hot-plug redundant standard |
| Network controller | Embedded 4 X 1GbE Ethernet Adapter (select models) or HPE FlexibleLOM and optional PCIe stand-up cards, depending on model |
| Storage controller | HPE Smart Array S100i and/or HPE Essential or Performance RAID controllers, depending on model |
| Product Dimensions (imperial) | SFF Chassis: 1.69 x 17.11 x 27.83 in, LFF Chassis: 1.69 x 17.11 x 29.5 in |
| Weight | 28.74 lb minimum, 37 lb maximum |
| Infrastructure management | HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) Optional- HPE iLO Advanced, and HPE OneView Advanced (require licenses) |
| Drive supported |
|
