Can only be installed in Slot 2.
| Location | PCIeslot | Processor connection | Height | Length | Link width | Slotwidth |
|---|---|---|---|---|---|---|
| Expansion card riser | 1 | Processor 1 | Full height | Full length | x16 | x16 |
| Expansion card riser | 2 | Processor 1 | Full height | Full length | x8 | x8 |
| System board | 3 | Processor 1 | Low profile | Half length | x16 | x16 |
| System board | 4 | Platform Controller Hub (Mapped to Processor 1) | Low profile | Half length | x1 | x1 |
| System board | 5 | Platform Controller Hub (Mapped to Processor 1) | Low profile | Half length | x4 | x8 |
Compatible With:
- Dell R530
