-*Image may differ from actaul product

Dell PowerEdge MX750c Compute Sled Chassis (6x2.5") SAS/SATA

Price: Request a Quote

Brand:

Dell

MPN:

DPE-MX750c-6x2.5-Chassis

Type:

Chassis

Condition:

ECS Refurbished & Tested

Warranty:

ECS 1 Year Hardware Warranty

-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.

-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.

Dell PowerEdge MX750c Compute Sled Chassis (6x2.5") SAS/SATA

Quick Specs

Form Factor:

Single Width Compute Sled

Processor | Max: 40 Cores

2 x 3rd Gen Intel Xeon Scalable

Memory | Max: 2TB RDIMM | 4TB LRDIMM

- 32 DDR4 RDIMM/LRDIMM 3200Mhz
- Supports 16 Optane Pmem 200 Series Max: 7.68TB

Storage | Max: 7.68TB

6 SFF SAS/SATA/NVMe HDD/SSD

Storage Controllers:

S150 (SW RAID 6Gb/s SATA/NVMe)
PERC H755 MX, H745P MX (Jumbo), HBA350i MX, HBA330 MX Mini-Mezzanine

Boot Options:

BOSS-S1 Module
IDSDM
USB

Remote Management:

iDRAC9 with Lifecycle Controller

Ideal for:

Data Analytics
Database
Virtualization

MX7000 Supported Sled Options

Dell PowerEdge MX Series

Dell PowerEdge MX7000 Modular CTO Enclosure Chassis
Dell PowerEdge MX740c CTO Compute Sled Up to 8
Dell PowerEdge MX750c CTO Compute Sled Up to 8
Dell PowerEdge MX760c CTO Compute Sled Up to 8
Dell PowerEdge MX840c CTO Compute Sled Up to 4
Dell PowerEdge MX5016s CTO Storage Sled Up to 7 Requires a minimum of 1 compute node in a chassis with storage sleds

Each Node is a separate CTO you must configure.

MX750c Features

A fully configurable single-width compute sled powered by up to two-40 core 3rd Generation Intel® Xeon® Scalable processors. Each PowerEdge MX750c supports 32 DDR4 DIMM slots and up to six 2.5-inch SAS/SATA (HDD/SDD) or Express Flash NVMe PCIe SSDs drives. A maximum of eight MX750c servers can be installed in the PowerEdge MX7000 chassis.

Flexible memory configurations from capacities of up to 4 TB
Supports up to 16 slots for Second Generation Intel® Optane™ DC persistent memory DCPMM
Choice of optional M.2 Boot Optimized Storage Solution (BOSS) or Internal Dual microSD Module (IDSDM), to
streamline operating system and data storage
Option of Express Flash NVMe PCIe SSD for high-performing direct attached storage requirements
This makes the PowerEdge MX750 an ideal server for organizations:
looking for leading-edge performance for virtualization, containers, software-defined storage and software-defined
networking and database analytics
seeking to commit to Dell EMC’s vision that leads toward Composable Disaggregated Infrastructure (CDI)

Increase operations with autonomous collaboration

The Dell EMC OpenManage systems management portfolio tames the complexity of managing and securing IT infrastructure. OpenManage Enterprise – Modular is specifically designed to enable customers that enjoy the benefits of a multi-chassis management approach found uniquely in the MX solution. Using Dell Technologies’ intuitive end-to-end tools, IT can deliver a secure, integrated experience by reducing process and information silos in order to focus on growing the business. The Dell EMC OpenManage portfolio is the key to your innovation engine, unlocking the tools and automation that help you scale, manage, and protect your technology environment.

Built-in telemetry streaming, thermal management, and RESTful API with Redfish offer streamlined visibility and
control for better server management
Intelligent automation lets you enable cooperation between human actions and system capabilities for added
productivity
Integrated change management capabilities for update planning and seamless, zero-touch configuration and
implementation
Full-stack management integration with Microsoft, VMware, ServiceNow, Ansible and many other tools

Memory

RDIMM

Registered DIMM – Provides for higher capacity options and advanced RAS features. It is the most commonly used DIMM type, and offers the best mix of frequency, capacity, and rank structure choices.

LRDIMM

Load Reduced DIMM – Provides maximum capacity beyond that of an RDIMM but at a higher power consumption. Uses a buffer to reduce memory loading to a single load on all DDR signals, allowing for greater density

DCPMM

(also known as Intel Optane DC persistent memory): Provides a large memory capacity at an affordable price. Any application can take advantage of DCPMM in Memory Mode with a compatible operating system. Unlock more performance and persistency when using an application that supports App Direct Mode. DCPMM is used along with RDIMMs or LRDIMMs and a maximum number of 6 DCPMMs can be used per CPU. This persistent memory technology does not require a battery.

Mezzanine & PERCs

The system can support 1 Mini-Mezz and 1 Internal PERC or is can handle 1 Jumbo PERC which will do the work of both the Mini-Mezz and the Internal PERC. This Fabric C slot is how you are able to connect the MX5016s Storage Array to this compute sled.

Mini-Mezzanine

The Mini-Mezzanine is install in the rear of the system near the Fab A and B Mezzanine Cards. This Mini Mezzanine gets connect to the Fab C in the MX7000 Enclosure. Only certain cards are supported here.

Internal PERC

This Internal PERC Module is considered the MX version of the PERC cards. This card controls the internal drives on this compute sled. There is a dedicated slot for this PERC near the front of the system. This is not supported if a JUMBO PERC is installed. They use the same SCREW to connect to the chassis.

JUMBO PERC

The Jumbo PERC is very unique it does the action of both the Mini-Mezzanin card and the Internal PERC. Not only can this control the internal drives but with also controls the External Storage Arrays that are connected to the Fab C in the back of the MX7000 Enclosure. This is one way to connect to the MX5016s Storage Array. If this is installed, the system does not support the Mini-Mezzanine or the Internal PERC.

BOOT Options & Remote Management

The MX740c has the option to install the OS with the BOSS Module. If you're trying to boot the Hypervisor you can install the IDSDM. These two cards can't be installed together. They take up the same slot. Likewise, you are able to manage the iDRAC Remote Management with One USB 2.0 management port to iDRAC.

IDSDM

The Internal Dual SD Module supported up to 2 Micro SD cards for redundancy when loading the Hypervisor OS system. This is not suitable for loading a full OS. The Boss card will do that. The IDSDM and the BOSS card can not be installed together.

BOSS

This Boot Optimized Sub System is ideal for loading the OS on to any server. It saves a drive from being allocated for this job and does not take up any PCIe slots. The BOSS and IDSDM can not be installed together.

Storage Controller

	Interface Support	Cache Memory Size	RAID Levels	RAID Support	MX750c Max Drives Supported
S150 Software RAID	6Gb/s SATA NVMe	No Cache	0,1,5,10	Software RAID	6	Internal drive support
HBA350i MX	12Gb/s SAS 6Gb/s SASSATA 3Gb/s SAS/SATA	N/A	N/A	N/A	6	Internal drive support
H745P MX	12Gb/s SAS 6Gb/s SATA	8GB NV	0,1,5,6,10,50,60	Hardware RAID	6 internal, 112 from MX5016s storage sled	For use with both internal drives and MX5016s storage sled
H755 MX	12Gb/s SAS	8 GB NV	0,1,5,6,10,50,60	Hardware RAID	6 internal, 112 from MX5016s storage sled	For use with both internal drives and MX5016s storage sled
HBA330 mini-mezz	12Gb/s SAS	No Cache	No RAID Pass-Through Only	No RAID SAS HBA	112	For use with MX5016s storage sled

Looking to Customize?

Need assistance with customization? Our sales experts will help you choose the best setup for your needs.

Start Customizing Today!

Dell PowerEdge MX750c Compute Sled Chassis (6x2.5

Manuals

Base Standard Capabilities

Feature	PowerEdge MX750c Technical Specifications
Processor	Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor Intel C620 series chipset with optional Intel QuickAssist Technology
Memory	32 DDR4 DIMM slots, supports RDIMM max 2 TB or LRDIMM max 4 TB, speeds up to 3200 MT/s
Persistent Memory	Supports up to 16 Intel Persistent Memory 200 series (BPS) slots with a maximum total capacity of 7.68 TB per sled
Availability	Supports registered ECC DDR4 DIMMs only
Controllers	Internal controllers: PERC H755 MX, PERC H745P MX, HBA350i MX, S150 Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2 x M.2 SSDs 240 GB or 480 GB or Internal Dual SD Module (IDSDM) or USB External PERC (RAID): PERC H745P MX External HBAs (non-RAID): HBA330 MMZ
Drive Bays	Front bays: Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) 7.68 TB per drive Up to 6 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) 7.68 TB per drive
Power Supplies	MX7000 chassis: Up to six 3000 W AC Platinum PSU and grid redundancy support
Fans	MX7000 chassis: 5 rear and 4 front-accessible hot-swap fans with full redundancy
Dimensions	Height: 42.15 mm (1.65 inches) Width: 250.2 mm (9.85 inches)< Depth: 594.99 mm (23.42 inches)
Form Factor	Up to 8 independent hot-swappable, 1U single-width compute sled in a MX7000 chassis
Embedded Management	MX7000 chassis: OpenManage Enterprise Modular Edition (OME-Modular); Up to 2 redundant MX9002m management modules Unified control: single management point for server, storage, and networking Intelligent automation: Operational template methodology and comprehensive RESTful API Quick Sync 2 Bluetooth Low Energy (BLE)/wireless module On compute sled: iDRAC9 iDRAC Direct iDRAC Service Module
OpenManage Software	OpenManage Enterprise OpenManage Power Manager plugin OpenManage SupportAssist plugin OpenManage Update Manager plugin OpenManage Enterprise Modular Edition
Integrations and Connections	OpenManage Integrations BMC Truesight Microsoft System Center Red Hat Ansible Modules VMware vCenter and vRealize Operations Manager	OpenManage Connections IBM Tivoli Netcool/OMNIbus IBM Tivoli Network Manager IP Edition Micro Focus Operations Manager i Nagios Core Nagios XI
Integrated Security	TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ Digitally Signed Firmware Chassis Intrusion Alert Secure Boot Secure Erase Silicon Root of Trust System Lockdown (requires iDRAC Enterprise or Datacenter)
Networking_Options (NDC)	MX7000 chassis Fabric options: up to 2 pairs redundant general purpose switch or passthrough modular bays (Fabrics A and B); redundant pair of storage specific switch bays (Fabric C) Up to 25 Gb CNA/NIC per port for Mezz A/B, 32 Gb Fibre Channel, 12 Gbps SAS for Mezz C
Ports	Front ports 1 x iDRAC Direct port (Micro-AB USB) 1 x USB 3.0	Internal Port 1 x USB 3.0
PCIe	One x16 PCIe Gen4 slot for Mezz A – connected to processor 1 One x16 PCIe Gen4 slot for Mezz B – connected to processor 2 One x16 PCIe Gen4 slot for Mini Mezz card – connected to processor 2 One x16 PCIe Gen4 slot for PERC – connected to processor 1 Two x8 PCIe Gen4 connectors for NVMe drive – connected to processor 1 One x8 PCIe Gen4 connectors for NVMe drive – connected to processor 2 Two x4 PCIe Gen3 slot for BOSS M.2 HW RAID card – connected to Platform Controller Hub (PCH)
Operating Systems and Hypervisors	Canonical Ubuntu Server LTS Citrix Hypervisor Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi/vSAN

Spec Sheet 4

Feature	PowerEdge MX750c	PowerEdge MX740c
Processor	Up to two 3rd Generation Intel® Xeon® Scalable Processors DIMM Speed: Up to 3200 MT/s Up to 40 cores per socket Max TDP: 270 W	Up to two Intel® Xeon® Scalable Processors One or two 2nd Generation Intel® Xeon® Scalable Processors Up to 28 cores per socket Max TDP: 205 W
Chipset	Intel® C627A	Intel® C628
Memory	32 DDR4 DIMM slots 32 slots for RDIMMs and LRDIMMs Maximum capacity (RDIMM): 2 TB Maximum capacity (LRDIMM): 8 TB Intel Optane PMem 200 Series	24 DIMM slots 12 slots enabled for NVDIMM-N Maximum capacity (RDIMM): 1.5 TB Maximum capacity (LRDIMM): 3 TB Maximum capacity (NVDIMM-N): 192 GB Intel Optane PMem 100 Series
Storage Controllers	S150 Software RAID HBA350i MX H745P MX Performance RAID via PERC 10, internal and external drive connect, 8GB NV cache H755 Performance RAID, NVMe RAID HBA330 MX mini-mezz, HBA, external drive connect, no cache	S140 Software RAID HBA330 MX H730P MX Performance RAID, 2 GB NV cache H745P MX Performance RAID, internal and external drive connect, 8 GB NV cache HBA330 MX mini-mezz, HBA, external drive connect, no cache
Drive Support	2.5-inch 12 Gb SAS 2.5-inch 6 Gb SATA 2.5-inch NVMe	2.5-inch 12 Gb SAS 2.5-inch 6 Gb SATA 2.5-inch NVMe
Drive Backplanes	6 x 2.5-inch SAS/SATA 6 x 2.5-inch SATA/NVMe (universal BP) 4 x 2.5-inch SAS/SATA/NVMe (universal BP)	6 x 2.5-inch SAS/SATA 6 x 2.5-inch SAS/SATA/NVMe 4 x 2.5-inch SAS/SATA/NVMe for NVDIMM implementations
Internal Boot	Choice of BOSS (Boot Optimized Storage Subsystem) or IDSDM (Internal Dual SD Module)	Choice of BOSS (Boot Optimized Storage Subsystem) or IDSDM (Internal Dual SD Module)
I/O Slots	Two PCIe 4.0 x16 Mezz slots (Fabric A and B) One PCIe 4.0 x16 Mini-mezz slot (Fabric C)	Two PCIe 3.0 x16 Mezz slots (Fabric A and B) One PCIe 3.0 x16 Mini-mezz slot (Fabric C)
USB	One internal USB 3.0 port One external USB 3.0 port One USB 2.0 management port to iDRAC One USB 3.0 + USB 2.0 port for IDSDM	One internal USB 3.0 port One external USB 3.0 port One USB 2.0 management port to iDRAC One USB 3.0 + USB 2.0 port for IDSDM
Video	Integrated VGA controller in iDRAC, VGA over LAN 4 Gb DDR4 shared with iDRAC application memory	Integrated VGA controller in iDRAC, VGA over LAN 4 Gb DDR4 shared with iDRAC application memory
Management	iDRAC9	iDRAC9
Security	Optional TPM 1.2/2.0 Cryptographically signed firmware Silicon Root of Trust Secure Boot System Lockdown System Erase	Optional TPM 1.2/2.0 Cryptographically signed firmware Silicon Root of Trust Secure Boot System Lockdown System Erase
Fans	In chassis	In chassis
Power Supplies	Power provided by chassis	Power provided by chassis
Chassis	MX7000	MX7000
