NetApp Disk Shelf DS212C with 12x 4TB 7.2K NL-SAS SED X315A-R6 6gbps

SKU: DS212C-07-4.0-12N-QS

Netapp Ds212C Disk Shelf W/ 12X 4Tb 7.2K Nl-Sas 6Gbps Nse Hdd (X315A-R6) | DS212C-07-4.0-12N-QS

Name: Netapp Ds212C Disk Shelf W/ 12X 4Tb 7.2K Nl-Sas 6Gbps Nse Hdd (X315A-R6) | DS212C-07-4.0-12N-QS
Brand: NetApp
SKU: DS212C-07-4.0-12N-QS
Price: 3450.0 USD
Availability: InStock

NetApp

| Disk Shelves

.price-ui--loading { display: block !important; opacity: 1 !important; }

$3,450.00

-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.

-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.

Parts Included:

1x DS212C Disk shelf
12x 4TB 7.2K NL-SAS 6Gbps NSE HDD (X315A-R6)
2x X5720A IOM12 Controller 12gbps
2x X526A-R6 913W AC PSU
1x X5529A-R6 Railkit 19” 4 Post Universal (or sub)
2x X66030A .5m HD Mini SAS – HD Mini SAS (longer cables available please ask for custom order)
2x X800-42U C13-C14 Power Cables

Refurbished NetApp DS212C with 12x 4TB 7.2K NL-SAS 6Gbps NSE HDD (X315A-R6) Disk Shelf achieves both storage and performance in a 4U form factor. The DS212C has the ability to use performance SAS drives, SSD's or high-capacity SATA disk drives. This DS212C is populated with 12x 4TB 7.2K NL-SAS 6Gbps NSE HDD (X315A-R6) and comes with a 1-Year Parts Replacement Warranty and all necessary parts.

NetApp DS212C Specifications

NetApp DS212C Disk Shelf Specifications
Rack units	2U
Drives per enclosure	12
Drives per rack unit	6
Drive form factor	3.5" large form factor
Drive carrier	Single drive
High-capacity disk drives	4TB, 8TB, 10TB at 7.2K RPM
Performance disk drives	N/A
Self-encrypting drives	6TB and 10TB at 7.2K RPM AES-256, FIPS 140-2 compliant
Solid state drives (full and mixed shelf)	960GB + 4TB, 960GB + 8TB, 960GB + 10TB
Controller Support	FAS9000, FAS8700, FAS8300, FAS8200, FAS8000 series, FAS2700, FAS2600
Shelf I/O modules	Dual IOM12 modules
Power supply/cooling fans	Dual, hot-pluggable, integrated power supply/fan assemblies
AC input power voltage (autoranging, VRMS)	100–120V or 200–240V
AC input power frequency	50–60 Hz
DC input power	Not available
Weight—fully loaded	60lbs (27.2 kg)
Dimensions	Height: 3.4 in. (8.5 cm) Width: 19 in. (48.0 cm) Depth: 19.1 in. (48.4 cm)
Clearance dimensions	Front—cooling: 6 in. (15.3 cm) Front—maintenance: 12 in. (30.5 cm) Rear—cooling and maintenance: 25 in. (63.5 cm)
Operating acoustic noise	6.3 bels LwAd (2 PCMs)
Temperature	Operating: 50° F to 104° F (10° C to 40° C) Nonoperating: –40° F to 158° F (–40° C to 70° C)
Relative humidity	Operating: 20% to 80% noncondensing; Nonoperating: 10 to 95% noncondensing
Altitude	Operating: 0 to 10,000 ft (0 to 3,045 m) Nonoperating: –1,000 to 40,000 ft (–305 to 12,192 m)

NetApp DS212C Configuration

Associated Part No.	Configuration	Rack Units	Weight	Sound Power	Sound Pressure	Line Voltage Actual (Min to Max)	Amps Typical	Amps Worst	Watts Typical	Watts Worst	BTU/Hr Typical	BTU/Hr Worst
DS212C-07-10-12B-QS	12x10TB,7.2K	2	60.0 lb (27.2 kg)	6.2 Bels	45 dBA	100 (100 to 120)	2.04	3.13	199	306	680	1045
DS212C-07-10-12B-QS	12x10TB,7.2K	2	60.0 lb (27.2 kg)	6.2 Bels	45 dBA	200 (200 to 240)	1.00	1.54	196	300	669	1024
DS212C-07-10-12N-QS	12x10TB,7.2K,NSE,NL-SAS	2	60.0 lb (27.2 kg)	6.2 Bels	45 dBA	100 (100 to 120)	2.04	3.13	199	306	680	1045
DS212C-07-10-12N-QS	12x10TB,7.2K,NSE,NL-SAS	2	60.0 lb (27.2 kg)	6.2 Bels	45 dBA	200 (200 to 240)	1.00	1.54	196	300	669	1024
DS212C-07-16-12B-QS	Disk Shelf,12G,12x16TB,7.2K,-Q	2	60.0 lb (27.2 kg)	6.2 Bels	45 dBA	100 (100 to 120)	2.35	3.43	230	336	785	1147
DS212C-07-16-12B-QS	Disk Shelf,12G,12x16TB,7.2K,-Q	2	60.0 lb (27.2 kg)	6.2 Bels	45 dBA	200 (200 to 240)	1.16	1.69	226	330	772	1127
DS212C-07-4.0-12B-QS	12x4TB,7.2K	2	60.6 lb (27.5 kg)	6.2 Bels	45 dBA	100 (100 to 120)	2.32	3.41	227	334	775	1140
DS212C-07-4.0-12B-QS	12x4TB,7.2K	2	60.6 lb (27.5 kg)	6.2 Bels	45 dBA	200 (200 to 240)	1.14	1.68	223	328	762	1120
DS212C-07-6.0-12N-QS	12x6TB,7.2K,NSE	2	63.3 lb (28.7 kg)	6.2 Bels	45 dBA	100 (100 to 120)	2.33	3.42	228	335	779	1144
DS212C-07-6.0-12N-QS	12x6TB,7.2K,NSE	2	63.3 lb (28.7 kg)	6.2 Bels	45 dBA	200 (200 to 240)	1.15	1.68	224	329	765	1123
DS212C-07-8.0-12B-QS	12x8TB,7.2K	2	63.1 lb (28.6 kg)	6.2 Bels	45 dBA	100 (100 to 120)	2.36	3.45	231	338	789	1154
DS212C-07-8.0-12B-QS	12x8TB,7.2K	2	63.1 lb (28.6 kg)	6.2 Bels	45 dBA	200 (200 to 240)	1.16	1.70	227	332	775	1134
DS212C-FS-07-2.0-12B-QS	12x2.0TB,NL-SAS	2	57.8 lb (26.2 kg)	6.2 Bels	45 dBA	100 (100 to 120)	2.11	3.19	206	312	704	1065
DS212C-FS-07-2.0-12B-QS	12x2.0TB,NL-SAS	2	57.8 lb (26.2 kg)	6.2 Bels	45 dBA	200 (200 to 240)	1.04	1.57	202	306	690	1045
