Specs
Quick Specs
1U rack server
Processor | Max: 2 to 8 Cores1x Intel Xeon E-2400
Memory | Max: 128 GB4x ECC DDR5 UDIMM 4400 MT/s
Embedded NIC (LOM):2 x 1 GbE LOM
Storage | Max: 61.44 TBUp to 8x 2.5" SAS/SATA (SSD) Max: 61.44 TB
Storage controllers:S160 SW RAID
HBA355i Adpt, PERC H355 Adpt, PERC H755 Adpt, HBA355i front, H355 front, H755 front, HBA355e
Up to (2) PCIe Gen4 slots on the Gen4 Riser
--Slot 1: 1 x8 with x8 bandwidth, HL/LP
--Slot 2: 1 x16 with x8 bandwidth, HL/LP
--One dedicated internal PERC Slot
BOSS-N1
Internal USB
iDRAC9 with lifecycle controller
Ideal for:
- Collaboration and sharing
- Database
- Edge Servers
- Small to mid-sized businesses
The Dell PowerEdge R360 addresses evolving compute demands with an easy to manage rack server designed for businesses looking for affordable enterprise features.
Elevate your enterprise to new heights with PowerEdge R360
Powered by the latest Intel® Xeon® E-2400 processors, Dell PowerEdge R360 is designed for productivity and data intensive applications, making it ideal for your growing business. With 4400/MT DDR5 and advanced NVMe BOSS-N1, it supports reduced latency and seamless scalability to bring the computing capability to the next level. Beyond the computing power, the Dell PowerEdge R360 is equipped with energy-efficient power supply, hot-plug storages, air cooling fans to make it a reliable, responsible, and secure choice.
The PowerEdge R360 supports NVIDIA A2 GPU to meet the growing demand in video and audio computing. It provides cost-effective solutions for ROBO and Near-Edge customers from retail, manufacturing, and logistics. This makes the PowerEdge R360 a powerful and versatile server for small to mid-sized businesses to enable a variety of workloads ranging from business-critical to cloud infrastructure. It is also widely used for point-of-sale transactions and enterprise level requirements for data analysis and virtualization.
The Dell OpenManage systems management portfolio tames the complexity of managing and securing IT infrastructure. Using Dell Technologies’ intuitive end-to-end tools, IT can deliver a secure, integrated experience by reducing process and information silos in order to focus on growing the business. The Dell OpenManage portfolio is the key to your innovation engine, unlocking the tools and automation that help you scale, manage, and protect your technology environment.
Need assistance with customization? Our sales experts are here to help you.
Start Customizing Today!
Base Standard Capabilities
Ports
| Feature | Technical Specifications | |
|---|---|---|
| Processor | One Intel Xeon E-2400 series processor with up to 8 cores or One Intel Pentium G7400/G7400T processor with 2 cores | |
| Memory |
| |
| Storage controllers |
| |
| Drive Bays | Front bays:
| |
| Power Supplies |
| |
| Cooling Options | Air cooling | |
| Fans | Up to 4 fans | |
| Dimensions |
| |
| Form Factor | 1U rack server | |
| Embedded Management |
| |
| Bezel | Security bezel or Optional Filter bezel | |
| OpenManage Software |
| |
| Mobility | OpenManage Mobile | |
| OpenManage Integrations |
| |
| Security |
| |
| Embedded NIC | 2 x 1 GbE LOM | |
| GPU Options | 1 x 60 W single-width GPU | |
| Ports | Front Ports
| Rear Ports
|
Internal Ports
| ||
| PCIe | Up to two PCIe Gen4 slots on the Gen4 Riser
| |
| Operating System and Hypervisors |
| |
Spec Sheet 4
| Features | PowerEdge R360 | PowerEdge R350 | |
|---|---|---|---|
| Processors | One Intel Xeon E-2400 series processors with up to 8 cores or one Intel Pentium processor with up to 2 cores | One Intel Xeon E-2300 series processor with up to 8 cores or one Intel Pentium processor with up to 2 cores | |
| Memory | Up to 4 x DDR5 ECC UDIMMs DIMM Speed: Up to 4400 MT/s | Up to 4 x DDR4 UDIMMs DIMM Speed: Up to 3200 MT/s | |
| Storage Controllers | Internal Controllers: PERC H355, PERC H755, PERC H355f, PERC H755f, HBA355i, HBA355i (front) | Internal Controllers: PERC H355, PERC H355f, PERC H345, PERC H755, PERC H755f, HBA355i, PERC H345f, HBA355f | |
| External Controllers: HBA355e | External Controllers: HBA355e | ||
| Software RAID: S160 | Software RAID: S150 | ||
| Drive Bays | Front: Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) |
Front: Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) |
|
| Power Supplies | 600 W Mixed Mode Platinum 100 V-240 V AC
or 240 V DC. Hot Swap
redundant 700 W Mixed Mode Titanium 200 V-240 V AC or 240 V DC. Hot Swap redundant |
600 W Mixed Mode Platinum 100 V-240 V AC or 240
V DC. Hot Swap
redundant 700 W Mixed Mode Titanium 200 V-240 V AC or 240 V DC. Hot Swap redundant |
|
| Cooling Options | Air cooled | Air cooled | |
| Fans | Up to 3 STD fans and 1 HPR fan | Up to 3 STD fans and 1 HPR fan | |
| Dimension | H x W x D: 1U x 482 mm x 563.3 mm | H x W x D: 1U x 482 mm x 534.59 mm | |
| Form Factor | 1U | 1U | |
| Embedded Management | iDRAC9, iDRAC Direct, iDRAC RESTful API with Redfish, iDRAC Service Manual | iDRAC9 Enterprise, iDRAC Direct, Datacenter license options; iDRAC Service Module, iDRAC RESTful API with Redfish | |
| OpenManage Software |
|
|
|
| Mobility | OpenManage Mobile | OpenManage Mobile | |
| Integrations and Connections | OpenManage Integrations
|
Integrations:
|
Connections:
|
| Security |
|
|
|
| Embedded NIC | 2 x 1 GbE LOM | 2 x 1 GbE LOM | |
| Networking Options | Optional Network Card | Optional Network Card | |
| GPU Options | Up to 1 x 60 W SW | None | |
| Ports | Front: 1 x USB 2.0, 1x iDRAC Direct (MicroUSB) Rear: 1 x VGA, 1 x USB2.0 + 1 x USB 3.2 Gen1 Internal : USB 3.2 Gen1 |
Front: 1 x USB 2.0, 1 managed (micro USB) + front VGA Rear: 1 x Gen2 + 1 x Gen3 USB Optional Internal USB |
|
| PCIe | Up to 2 x PCIe Slots Gen4 | Up to 2 x PCIe Slots Gen4 | |
| Operating System and Hypervisors |
|
|
|
