Dell PowerEdge T430 Tower Server Chassis (16x3.5")

SKU: DPE-T430-16x2.5-Chassis

Dell PowerEdge T430 Tower Server Chassis (16x3.5")

Name: Dell PowerEdge T430 Tower Server Chassis (16x3.5")
Brand: Dell
SKU: DPE-T430-16x2.5-Chassis
Price: 570.0 USD
Availability: InStock

Dell

| Chassis

.price-ui--loading { display: block !important; opacity: 1 !important; }

$570.00

Thanks for the request. We'll get back to you with in 24 hours.

Quick Specs

Form Factor:

Tower server 5U (Rack conversion kit)

Processor Max: 14 Cores

2x Intel E5-2600 v3 or v4 Processors

Memory Max: N/A

12 DDR4 RDIMM 2400Mhz

Storage Max: N/A

16x 2.5" Hot-Swap SAS/SATA (HDD/SSD)

Boot Options

IDSDM
Internal USB

RAID Controller:

H730, PERC H730P and PERC H830
Support for a maximum of 1 internal controller and 1 external controller

NIC/LOM

2 x 1GbE LOM

Remote Management:

iDRAC8 with Lifecycle Controller

PCIe Slots:

6 full height slots: 4 x PCIe 3.0, 2 x PCIe 2.0

GPU:

1x DW or 2x SW GPU

Other Versions

Ideal for:

Virtualization

Looking to Customize?

Need assistance with customization? Our sales experts are here to help you.

Start Customizing Today!

Base Standard Capabilities

Features	Technical specification
Form factor	Tower (5U rackable)
Dimensions	Tower H: 430.3 mm (17.04 in); with foot 443.3 mm (17.45 in); with wheel 471.3 mm (18.55 in) W: 218 mm (8.58 in); with foot 304.5 mm (11.98 in) D (without bezel): front to rear wall 542.2 mm (21.33 in); front to PSU handle 578.42 mm (22.77 in) D (with bezel): front to rear wall 558.6 mm (21.99 in); front to PSU handle 594.82 mm (23.41 in)	Rack H: 218mm (8.58 in) W: 430.3mm (16.94 in) without ear; 482.40mm (18.99 in) with ear D (minimum): 538.4 mm (21.2 in) from rack ear back side to chassis rear wall D (maximum): 584.05mm (22.99 in)
Processor	Intel® Xeon® processor E5-2600 v4 product family Chipset: Intel C610 series chipset Processor sockets: 2 Internal interconnect: Two QPI links at 9.6 GT/s Cache: 2.5MB per core; core options: 4, 6, 8, 10, 12, 14
Memory	12 DIMM slots: 4GB/8GB/16GB/32GB DDR4 up to 2400MT/s
I/O slots	Support for up to 6 full height slots: 4 x PCIe 3.0, 2 x PCIe 2.0
RAID controllers	Support for a maximum of 1 internal controller and 1 external controller PERC H730, PERC H730P and PERC H830
Network controller	2 x 1GbE LOMs
Hard drives	SAS, SATA, nearline SAS, SSD
Communications	Broadcom® 5720
Power	495W, 750W, 1100W PSU; 450W cabled non-redundant PSU
Availability	Hot-plug drives bays; high-efficiency, hot-plug, redundant power supply units; fan redundancy; extended thermal support; Dell fault- resilient memory; Internal dual SD modules
Slots	1x8 PCIe 3.0 (x16 connector) 1x4 PCIe 3.0 (x8 connector)	1x4 PCIe 3.0 (x8 connector) 1x1 PCIe 3.0 (x1 connector)
Availability	2 x 1GbE LOMs
Systems Management	Systems management: IPMI 2.0 compliant; Dell OpenManage Essentials; Dell OpenManage Mobile; Dell OpenManage Power Center Remote management: iDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade), 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)	Dell OpenManage connections: HP Operations Manager, IBM Tivoli® Netcool® and CA Network and Systems Management Dell OpenManage Plug-in for Oracle® Database Manager Dell OpenManage integrations: Dell OpenManage Integration Suite for Microsoft System Center Dell OpenManage Integration for VMware® vCenter®
Rack support	All configurations support rackable, except the 3.5" x 4 cabled chassis configuration
Optional supported hypervisors	Citrix® XenServer® VMware vSphere® ESXi™ Red Hat® Enterprise Virtualization
Operating systems	Microsoft® Windows Server® 2008 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2012 R2 Novell® SUSE® Linux Enterprise Server Red Hat Enterprise Linux
